DC PD40A D Operating And Maintenance Instructions

(OPTIONAL)
REMOVE DRAIN PLUG AND SWITCH THE MACHINE OFF
TO START THE AUTOMATIC DRAIN PUMP CYCLE
POWER
SWITCH
PREPARATION

CHECK THE DRAIN PLUG IS PUSHED FIRMLY IN PLACE ,THE SURFACE FILTERS IS IN POSITION AND THE FILTER BOWL IS SECURED WITH THE FILTER NUT.

CHECK THE DETERGENT ( RED ) AND RINSE AID ( CLEAR ) SUPPLY TUBES, WITH FOOT VALVES - ARE SUBMERGED IN SUFFICIENT PRODUCT.

CHECK THE DOOR IS CLOSED AND PRESS THE POWER SWITCH - THE POWER GREEN LAMP WILL COME ON.

ALLOW 30 mins FOR THE MACHINE TO FILL WITH WATER AND REACH THE CORRECT WASHING TEMPERATURE.THE MACHINE READY LAMP WILL COME ON.
OPERATION

REMOVE ALL DEBRIS FROM THE ITEMS TO BE WASHED BEFORE PLACING THEM INTO THE BASKET.

CLOSE THE DOOR, SELECT THE WASHING CYCLE TIME SWITCH 2` OR 3` MINUTE - PRESS THE CYCLE START SWITCH - THE CYCLE LAMP WILL COME ON.

AT THE END OF THE CYCLE THE CYCLE LAMP WILL GO OUT.

OPEN THE DOOR AND PULL OUT THE BASKET - ALLOW EXCESS WATER TO RUN OFF BEFORE REMOVING.
ROUTINE MAINTENANCE

AT THE END OF A SESSION TURN OFF THE POWER SWITCH. DO NOT REMOVE ANY FILTERS AT THIS STAGE.

REMOVE THE DRAIN PLUG - THE WASH TANK WILL EMPTY. MACHINES FITTED WITH DRAIN PUMP WILL AUTOMATICALLY START TO PUMP THE WATER OUT.

CLEAN AROUND THE WASH TANK - DOOR SURROUNDS AND HINGES WITH AN 'ADDIS'' TYPE WASHING UP BRUSH.

COLLECT THE DEBRIS AND REMOVE FROM THE WASH TANK. REMOVE THE SURFACE FILTER AND CLEAN THOROUGHLY.

CLEAN AROUND THE LOWER WASH TANK - DO NOT ALLOW DEBRIS TO GO DOWN THE OUTLET HOLE AS THIS MAY DAMAGE YOUR MACHINE.

DO NOT USE CHLORIDE CONTAINING BASED CLEANING SOLUTIONS OR ABRASIVES WHEN CLEANING THE WASH TANK.

REGULARLY CHECK RINSE JETS AND WASH JETS ARE CLEAR OF DEBRIS OR LIME SCALE - REMOVE IF NECESSARY BY UNSCREWING THE RINSE ARM NUT
THAT HOLDS THE RINSE ARM IN PLACE - REMOVE THE RINSE PIN THAT HOLDS THE WASH ARM IN PLACE - CLEAN BOTH THOROUGHLY AND REASSEM-
BLE.
WATER SOFTENER

REMEMBER TO REGENERATE THE EXTERNAL WATER SOFTENER IF FITTED REGULARLY. ENSURE THAT THE WATER VALVES ARE TURNED BACK ON TO SUPPLY
THE MACHINE WITH FULL MAINS PRESSURE SOFTENED WATER.
RINSE ARM NUT
RINSE JETS
RINSE PIN
SERVICE CALLS TO RECTIFY FAULTS CAUSED BY `THE LACK OF ROUTINE MAINTENANCE` WILL BE CHARGED FOR
OPERATING AND MAINTENANCE INSTRUCTIONS
PD40A D / PG40 D
CYCLE START
SWITCH
RINSE ARM
WASH ARM
WASH JETS
AND YOUR WARRANTY MAY BE AFFECTED
www.directcatering.co.uk
CYCLE
SELECTION
LAMP
CYCLE TIME SWITCH
2` OR 3` MINUTE
FOOT VALVES
FILTER NUT
FILTER
OUTLET HOLE
MACHINE
READY
LAMP
DRAIN PLUG
SURFACE FILTERS
OUTLET HOLE
