DC PD50 Operating And Maintenance Instructions

(OPTIONAL)
REMOVE DRAIN PLUG AND SWITCH THE MACHINE
OFF TO START THE AUTOMATIC DRAIN PUMP CYCLE
POWER
SWITCH
PREPARATION
 CHECK THE DRAIN PLUG IS PUSHED FIRMLY IN PLACE AND THE FILTER BOWL IS POSITIONED INTO THE SURFACE FILTER.
 CHECK THE DETERGENT ( RED ) AND RINSE AID ( CLEAR ) SUPPLY TUBES, WITH FOOT VALVES - ARE SUBMERGED IN
SUFFICIENT PRODUCT.
 CHECK THE DOOR IS CLOSED AND PRESS THE POWER SWITCH - THE POWER GREEN LAMP WILL COME ON.
 ALLOW 30 mins FOR THE MACHINE TO FILL WITH WATER AND REACH THE CORRECT WASHING TEMPERATURE.THE MACHINE READY LAMP WILL
COME ON.
OPERATION
 REMOVE ALL DEBRIS FROM THE ITEMS TO BE WASHED BEFORE PLACING THEM INTO THE BASKET.
 CLOSE THE DOOR, SELECT THE WASHING CYCLE TIME SWITCH 2` OR 3` MINUTE - PRESS THE CYCLE START SWITCH - THE CYCLE LAMP
WILL COME ON.
 AT THE END OF THE CYCLE THE CYCLE LAMP WILL GO OUT.
 OPEN THE DOOR AND PULL OUT THE BASKET - ALLOW EXCESS WATER TO RUN OFF BEFORE REMOVING.
ROUTINE MAINTENANCE
 AT THE END OF A SESSION TURN OFF THE POWER SWITCH. DO NOT REMOVE ANY FILTERS AT THIS STAGE.
 REMOVE THE DRAIN PLUG - THE WASH TANK WILL EMPTY. MACHINES FITTED WITH DRAIN PUMP WILL AUTOMATICALLY START TO PUMP THE
WATER OUT.
 CLEAN AROUND THE WASH TANK - DOOR SURROUNDS AND HINGES WITH AN 'ADDIS'' TYPE WASHING UP BRUSH.
 COLLECT THE DEBRIS INTO THE FILTER BOWL AND REMOVE FROM THE WASH TANK. REMOVE THE SURFACE FILTER AND CLEAN THOR-
OUGHLY.
 CLEAN AROUND THE LOWER WASH TANK - DO NOT ALLOW DEBRIS TO GO DOWN THE OUTLET HOLE AS THIS MAY DAMAGE YOUR MACHINE.
 DO NOT USE CHLORIDE CONTAINING BASED CLEANING SOLUTIONS OR ABRASIVES WHEN CLEANING THE WASH TANK.
 REGULARLY CHECK RINSE JETS AND WASH JETS ARE CLEAR OF DEBRIS OR LIME SCALE - REMOVE IF NECESSARY BY UNSCREWING THE RINSE
ARM NUT THAT HOLDS THE RINSE ARM IN PLACE - REMOVE THE RINSE PIN THAT HOLDS THE WASH ARM IN PLACE - CLEAN BOTH
THOROUGHLY AND REASSEMBLE.
WATER SOFTENER
 REMEMBER TO REGENERATE THE EXTERNAL WATER SOFTENER IF FITTED REGULARLY. ENSURE THAT THE WATER VALVES ARE TURNED BACK ON
TO SUPPLY THE MACHINE WITH FULL MAINS PRESSURE SOFTENED WATER.
RINSE ARM NUT
RINSE JETS
RINSE
PIN
SERVICE CALLS TO RECTIFY FAULTS CAUSED BY `THE LACK OF ROUTINE MAINTENANCE` WILL BE CHARGED FOR
OPERATING AND MAINTENANCE INSTRUCTIONS
PD50 / PD50A / PD50A D / PG50 / PG50 D
CYCLE START
SWITCH
RINSE
ARM
WASH
ARM
WASH JETS
AND YOUR WARRANTY MAY BE AFFECTED
FOOT VALVES FOR
CHEMICAL
CONTAINER TUBES
www.directcatering.co.uk
CYCLE
SELEC-
TION
CYCLE TIME
SWITCH
DRAIN PLUG
FILTER BOWL
OUTLET HOLE
MACHINE
READY
LAMP
SURFACE FIL-
TER
