Global Light & Power LCC WW440117 Installation Instruction

INSTALLATION INSTRUCTION
Important Instructions. Please read first
•
Please follow instructions carefully. Failure to do so will void the
local law and applicable standards.
1. Ensure correct input v oltage is supplied to the luminaire.
2. Ensure the power is disconnected before making any connections.
3. Do not make modification nor alter the luminaire without written approv al from GLP.
4. Ensure to keep luminaire in a clean area free of debris.
INSTALLATION
•
Step 1: Find the location where the luminaire has to be installed. Install a suitable wiring from the main supply
(110-260 VAC 50/60Hz) to the luminaire.
•
Step 2: Mount the luminaire onto a hard surface using appropriate stainless steel screws as illustrated.
•
Step 3: Connect the luminaire input cable to the main supply 110-260 VAC 50/60Hz) cable either using additional
male input connector cable or cut the existing female connector and connect to the main supply. Ensure the M11
kit is installed within one meter from the luminaire. Solder the connections, wrap the connection with 3M
waterproof tape & electrical tape and fill the M11 kit with epoxy.
www.globallightllc.com
.
DO NOT
CUT MAIN
CABLE
info@globallightllc.com
warranty. Please ensure installation complies with
Tel: +971 4 340 44 58
WW440117
Fax: +971 4 341 10 90
