Electric Heat Kit
Installation Manual
Indoor Unit
MODELS:
ENVBR24HPJ1IB
ENVBR36HPJ1IB
ENVBR48HPJ1IB
ENVBR60HPJ1IB
Thank you for choosing our product.
Please read this Quick Start Guide carefully before operation
and retain it for future reference.
If you have lost the Quick Start Guide, please contact the local
agent or visit www.borealsplits.com or send email to
info@borealsplits.com for electronic version.
CAT NO: EnerMaxx_Heater_Installation_11242022
Advertisement
Related Manuals for Boreal ENVBR36HPJ1IB
Summary of Contents for Boreal ENVBR36HPJ1IB
- Page 1 Please read this Quick Start Guide carefully before operation and retain it for future reference. If you have lost the Quick Start Guide, please contact the local ENVBR24HPJ1IB agent or visit www.borealsplits.com or send email to ENVBR36HPJ1IB info@borealsplits.com for electronic version. ENVBR48HPJ1IB ENVBR60HPJ1IB CAT NO: EnerMaxx_Heater_Installation_11242022...
-
Page 2: Attention Installing Personnel
ATTENTION INSTALLING PERSONNEL Prior to installation, thoroughly familiarize yourself with this Installation Manual. Observe all safety warnings. During installation or repair, caution is to be observed It is your responsibility to install the product safely and to educate the customer on its safe use... - Page 3 CAUTIONS ENSURE THAT ALL POWER IS DISCONNECTED PRIOR TO ATTEMPTING INSTALLATION OF THIS HEATER KIT. THERE MAY BE MORE THAN ONE DISCONNECT SERVICING THE UNIT. REMOVE LINE VOLTAGE FROM L1 and L2 TERMINALS IN THE CONTROL BOX. FAILURE TO DO SO CAN RESULT IN FIRE. ...
- Page 4 1. Remove the front panel and upper access panel from the air handler. 2. Disassemble the electrical box.
- Page 5 3. Remove the electrical box 4. Disassemble the metal plate at the mounting hole of the electric heater...
- Page 6 5. Install the electric heater to the metal plate position which disassembles in step 4. (Notes: There are two holes circled below which are used to fasten the electric heater bracket during installation)
- Page 7 6. Install breaker (Notes: When installation, you need to lift up the buckle first, hold the breaker bracket and then put down the buckle to fix the breaker) 7. Disconnect line voltage from L1 and L2 terminals in control box if applicable. Connect the electric heater molex plug.
- Page 8 8. After installation, the schematic diagram is as follows: 9. Install the electrical box back to the original position 10. Install the front panel and upper panel back to the air handler. Electric heater installation is completed.
- Page 9 Single Point Wiring Kit Installation Remove this middle partition...
- Page 10 Single Point Wiring Kit Installation Attach single point kit...
- Page 11 Single Point Wiring Kit Installation Connect properly sized wire to lugs as shown...
- Page 12 Single Point Wiring Kit Installation Reinstall safety cover Add field-supplied ground lug...
- Page 13 Electric Heater Kits Model Cooling capacity(ton) Optional electric heater Optional electri 2.0 / 3.0 ENERMAXXHTR5KW ENVBR24, 36 2.0 / 3.0 ENERMAXXHTR8KW ENVBR24, 36 3.0 / 4.0 / 5.0 ENERMAXXHTR10KW ENVBR36, 48, 60 3.0 / 4.0 / 5.0 ENERMAXXHTR15KW ENVBR36, 48, 60 4.0 / 5.0 ENERMAXXHTR20KW ENVBR48, 60...
- Page 14 U.S. CONTACT INFORMATION TRADEWINDS CLIMATE SYSTEMS, LLC. E-mail: info@borealsplits.com BOREALSPLITS.COM...
