Grandinroad Kyler 182839 BSA Manual

105.75"w x 106.4"d x 36.2"h

Advertisement

Quick Links

GR Product Name: Kyler
GR Product Number: 182839 BSA/ 182840 BSA/ 182841 BSA
Assembled Dimension: 105.75"W x 106.4"D x 36.2"H
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 22.08.2024
Prevent accidentally discarding small parts
or hardware. Retain all carton contents until
assembly and installation are complete.
Product Specialist: 800-491-4958
Online: www.grandinroad.com
MADE IN VIETNAM
Page 1 of 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kyler 182839 BSA and is the answer not in the manual?

Questions and answers

Summary of Contents for Grandinroad Kyler 182839 BSA

  • Page 1 Product Specialist: 800-491-4958 GR Product Name: Kyler Online: www.grandinroad.com GR Product Number: 182839 BSA/ 182840 BSA/ 182841 BSA Assembled Dimension: 105.75"W x 106.4"D x 36.2"H Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete.
  • Page 2 Remove all parts, hardware and protective packaging from carton and carefully arrange on a clean, level, padded surface. ASSEMBLY TIME: Twenty minutes for assembly not including unpackaging. Ltr. Qty. Components Sleep Seat Love Seat Backrest Corner Seat Back Cushion Back Cushion (Corner) MADE IN VIETNAM Product Specialist: 800-491-4958 Page 2 of 7 Online: www.grandinroad.com...
  • Page 3 Step 1: Attach the Sleep Seat (B) to the Arm (A). Step 2: Attach the Back Rest (D) to the Love Seat (C). MADE IN VIETNAM Product Specialist: 800-491-4958 Page 3 of 7 Online: www.grandinroad.com...
  • Page 4 Step 3: Attach the Love Seat (C) to the Arm (A). Step 4: Attach the Sleep Seat (B) and Love Seat (C) to Corner Seat (E). MADE IN VIETNAM Product Specialist: 800-491-4958 Page 4 of 7 Online: www.grandinroad.com...
  • Page 5 Step 5: Place Back Cushion (Corner) (G) and Back Cushion (F) to the Backrest as shown. Step 6: Flatten the back rest by releasing it from upright position. MADE IN VIETNAM Product Specialist: 800-491-4958 Page 5 of 7 Online: www.grandinroad.com...
  • Page 6 Step 7: Using the straps as shown, pull out the bed from underneath the seat frame. Step 8: Lift up the pull out bed as shown. MADE IN VIETNAM Product Specialist: 800-491-4958 Page 6 of 7 Online: www.grandinroad.com...
  • Page 7 Clean with soft cloth only. Please contact one of our Product Specialists for assembly assistance or questions at 1-800-491-4958 or email ps@grandinroad.com. Specialists are available weekdays 8:00am to 8:00pm EST or Saturday 9:30am to 6:00pm. MADE IN VIETNAM Product Specialist: 800-491-4958 Page 7 of 7 Online: www.grandinroad.com...
