- Page 1 Translated from Spanish to English - www.onlinedoctranslator.com AVENAR detector 4000 FAP-425 / FAH-425 isOperation Guide...
-
Page 3: Table Of Contents
AVENAR detector 4000 Index | en Table of contents Product Description System Description Functional description of sensor technology Optical sensor 2.1.1 (smoke detector) 2.1.2 Thermal sensor (heat detector) 2.1.3 Chemical sensor (gas sensor) System description Flash frequency and error detection Features Accessories 2.5.1... - Page 4 | Index AVENAR detector 4000 Waste disposal Technical data 2014.10 | 1.0 | F.01U.304.690 Operation Guide Bosch Security Systems GmbH...
-
Page 5: Product Description
AVENAR detector 4000 is suitable for surface and flush mounting and includes separate mounting points for false ceilings and interior sockets. AVENAR detector 4000 is available in different versions of single sensor and multi-sensor detectors. Identifier Description Material No. -
Page 6: System Description
| System Description AVENAR detector 4000 System Description Figure 2.1: Detector configuration Smoke measuring chamber with optical Single screen sensor Thermal sensor Card with electronic evaluation elements Chemical sensor (hidden in side view) Detector base MS 400 / MS 400 B Functional description of sensor technology 2.1.1... -
Page 7: Chemical Sensor (Gas Sensor) System
AVENAR detector 4000 System Description | en Depending on the specified detector class, the thermal sensor triggers the alarm state when the maximum temperature of 54°C or 69°C (thermal maximum) is exceeded, or if the temperature rises by a defined amount within a given time period (thermal differential). - Page 8 | System Description AVENAR detector 4000 – Active threshold adjustment (bias compensation) in case the optical sensor becomes contaminated. – Active threshold adjustment (bias compensation) of the chemical sensor. – EMC safety is 50 V/m and therefore much higher than that required by regulations.
-
Page 9: Accessories
(with or without detector module) from contamination. The dust protection cover made of polypropylene (PP) is mounted over the installed detector base. Bosch Security Systems me GmbH Operation Guide 2014.10 | 1.0 | F.01U.304.690... -
Page 10: Remote Indicators
| System Description AVENAR detector 4000 MK 400 Detector Console The MK 400 detector console is used to install detectors on door frames or similar, in accordance with DIBt. The console is supplied with a pre-assembled MS 400 detector base (detector shown is not included in the delivery parts). - Page 11 AVENAR detector 4000 System Description | en 3. Mount the motherboard directly to a smooth, dry surface with two or four screws. 1. For surface wiring, remove pre-drilled cable entries. 2. For recessed wiring, route the cable through the opening under the connection plate.
- Page 12 | System Description AVENAR detector 4000 FAA-420-RI-ROW Wiring 1. Connect the remote indicator as shown. 2. Place the cover on the base plate so that the two hooks fit into the slots. 3. Gently press the cover onto the base plate until the snap hook engages.
- Page 13 AVENAR detector 4000 System Description | en Mode Connection terminal Alarm condition The remote indicator shows a steady red light. The current must be limited to a maximum of 30 mA. The remote indicator shows a steady red light. Input voltage range: 8.5 VDC to 33 VDC.
-
Page 14: Design
| Design AVENAR detector 4000 Design Note! The FAP-425/FAH-425 automatic fire detectors are not designed for outdoor use. Basic Notes for Installation/Configuration – The multi-sensor fire detector must be designed in accordance with the guidelines for optical detectors until a guideline for its planning is developed in cooperation with VdS (see also DIN VDE 0833, Section 2, and VDS 2095): –... -
Page 15: Programming
AVENAR detector 4000 Programming | en Programming Programming is done via a desktop or laptop computer connected to the fire panel with FSP-5000- RPS (Remote Programming System) for fire panels with the LSN line technology version The FAP-425/FAH-425 series detectors are programmed by entering the operating zone. The selection of the operating zone determines the optimum characteristic field for the evaluation of the disturbance and fire variables. - Page 16 | Programming AVENAR detector 4000 Selectable installation locations in Type of Sensitivity programming software detector Thermal Optical Chemical (FSP‑5000‑RPS) maximum (EITHER) High High Office (after closing) O, T High (A2) Low* Offices (smoking)/waiting O, T High (A2) rooms/restaurants/meeting rooms...
-
Page 17: Fap-425-Dot-R / Fap-425-Ot-R / Fap-425-Ot
AVENAR detector 4000 Programming | en FAP‑425‑DOT‑R / FAP‑425‑OT‑R / FAP‑425‑OT Note! The default setting for detector types FAP-425-DOT-R, FAP-425-OT-R and FAP-425-OT is "Office (Day Mode)". For a description of this setting, see the table below. Selectable installation locations in programming... -
Page 18: Fap-425-Do-R / Fap-425-O-R / Fap-425-O
| Programming AVENAR detector 4000 FAP‑425‑DO‑R / FAP‑425‑O‑R / FAP‑425‑O Note! The default setting for detector types FAP-425-DO-R, FAP-425-OR and FAP-425-O is "Medium". For a list of possible installation locations with their corresponding sensitivity settings, see the table below. - Page 19 AVENAR detector 4000 Programming | en Sensitivity classes A1R, A2R and BR indicate that in addition to the thermal differential unit, the maximum thermal unit is also active. These sensitivity classes are particularly suitable for use in unheated buildings where the ambient temperature can experience large changes but increases in maximum temperature do not last long.
-
Page 20: Connection
MS 400 The MS 400 is the standard detector base and has seven terminals. MS 400 B Bosch branded MS 400 standard detector base. FAA-420-SEAL To use the FAP/FAH detectors in wet environments, you can complement the MS 400 and MS 400 B detector bases with the FAA-420-SEAL moisture-proof seal. -
Page 21: Base
AVENAR detector 4000 Connection | is FAA‑MSR 420 The FAA-MSR 420 is a detector base with a changeover contact relay (type C). The FAA-MSR 420 detector base with relay can only be used in conjunction with the enhanced local safety network version (FPA‑5000 modular fire panel). -
Page 22: Connection
AVENAR detector 4000 en | Connection Ø 120 Ø 100 Connection Note! Keep the cable shielded or as short as possible and isolate it. 2014.10 | 1.0 | F.01U.304.690 Operation Guide Bosch Security Systems GmbH... -
Page 23: Connecting The Ms 400/Ms 400 B
AVENAR detector 4000 Connection | is 5.3.1 Connecting MS 400/MS 400 B LSN +/L..b max. 30 V DC a1/a2 (LSN -/L..a) bk rd – - RI Yellow, connectionna b1/b2 (LSN + White, connection to a1/a2 (LSN -) Red, connection to +V... -
Page 24: Detector Bases With Sounder
AVENAR detector 4000 en | Connection max. 30 V DC 1 A / 30 V DC NC NO b1 | b2 (LSN +) a1/a2 (LSN -) max. 3 m – FAA-420-RI Yellow, connection to b1/b2 (LSN + White, connection to a1/a2 (LSN -) FAA‑420‑RI: red, connection to b1... -
Page 25: Installing The Detector Module
AVENAR detector 4000 Connection | is – MSS 300 Detector base with white siren for conventional line technology and with activation via point C of the detector in use. – MSS 300 WS-EC Detector base with white sounder for conventional line technology and with external activation (via an interface module). -
Page 26: Removing The Detector
AVENAR detector 4000 en | Connection Figure 5.1: Activation of the extraction protection mechanism Element either Locking piece (X) before removing it Locking piece (X) built in, but disabled Lock activated Removing the detector Unlocked search heads are removed by turning them counterclockwise and pulling them away from the base. -
Page 27: Address Settings
If a classical LSN element is present, it is only present in 127 elements. Note that only the loop. They can use the loop or branch structures for the configurations with classic or enhanced LSN elements. Bosch SYo cherheits systeme GmbH Operation Guide 2014.10 | 1.0 | F.01U.304.690... -
Page 28: Ordering Information
| Order information AVENAR detector 4000 Ordering information Detector models Code Description ID of the product FAP-425-DOTC-R Dual optical, thermal and chemical multi-sensor detector, F.01U.280.451 automatic and manual direction setting FAP-425-DOT-R Dual optical multi-sensor detector, thermal, F.01U.279.989 automatic and manual direction setting... -
Page 29: Detector Accessories
AVENAR detector 4000 Order Information | en Detector Accessories Code Description ID of the product FLM-320-EOL2W 2-wire end-of-line module F.01U.083.619 TP4 400 Plate for the identification of detectors for installation 4.998.084.709 heights up to 4 m (1 pack = 50 pieces) -
Page 30: Accessories
| Order information AVENAR detector 4000 Code Description ID of the product FNM-420-A-BS-WH Detector base with white siren, LSN, power supply via F.01U.064.687 LSN, C-point activation via connected detector or external activation via LSN, for surface and flush mount wiring... -
Page 31: Maintenance And Service Detector
– Maintenance and inspection work must be carried out regularly and by specialized personnel. – BOSCH ST recommends a visual and functional inspection at least once a year. Testing Detector type... -
Page 32: Type Coding
| Maintenance and service AVENAR detector 4000 Detector type coding With the exception of the FAP-425-OR and FAP-425-O, all detectors are equipped with a coloured ring around the individual central display to identify the detector type. This facilitates inspection by service personnel. -
Page 33: Testing Instructions For Fap-425-Dotc-R / Fap-425-Dot-R / Fap-425-Ot-R
AVENAR detector 4000 Maintenance and service | en Testing outside of test mode If you want to test two-detector dependency detectors, dependencies of two zones or controls, you must do so outside of test mode. Perform the following: – FAP-425-OR, FAP-425-O and FAP-425-DO-R Activate the detector with a test spray. Depending on the sensitivity setting, it may take up to one minute for the detector to activate. -
Page 34: Diagnostic Data
| Maintenance and service AVENAR detector 4000 Diagnostic data – Module Address Module in which the detector or detector line is installed. – Logical Direction Detector installation address, for example 10-03: the detector is in zone 10 and is detector number 3. -
Page 35: Warranty
AVENAR detector 4000 Maintenance and service | en Current EMC value Average EMC value Description 0…8 0…49 Low EMC level. No action required. 9…20 50…79 Average EMC value. Consider location. > 20 80…100 High EMC level. Unsuitable location. – Operating hours counter Hours of operation since the detector was initially powered up. -
Page 36: Repair
| Maintenance and service AVENAR detector 4000 Repair In case of defect, replace the entire detector. Waste disposal Electrical and electronic modules or devices must not be disposed of with normal household waste. They must be disposed of in accordance with the relevant regulations and guidelines (e.g. -
Page 37: Technical Data
AVENAR detector 4000 Technical data | en Technical data Detector Description FAP-425- FAP-425- FAP-425- FAP-425- FAP-425- FAH-425- - OR - TR - DOTC-R - DOT-R - DO-R - OT-R Measurement of light scattering Measurement of the increase in temperature and the... - Page 38 | Technical data AVENAR detector 4000 FAP-425- FAP-425- FAP-425- FAP-425- FAP-425- FAH-425- - OR - TR - DOTC-R - DOT-R - DO-R - OT-R Chemical sensor range 40m² Control zone 120 m² maximum (respect the VdS guidelines) 16 m 7.5 m...
- Page 39 AVENAR detector 4000 Technical data | en FAP-425- FAP-425- FAP-425- FAP-425- FAP-425- FAH-425- - OR - TR - DOTC-R - DOT-R - DO-R - OT-R 135 g 125 g 115 g Approximate weight with packaging Product ID F.01U. F.01U. F.01U.
