Exalt Floor Standing
Control Module Replacement
Kit Part Number
EXRKIT134
Each Kit Includes:
• Control Module
Recommended Tools:
• Phillips Head Screwdriver
WARNING
!
Indicates a potentially hazardous situation which,
if ignored, can result in serious injury or substan-
tial property damage.
WARNING
!
For your safety, turn off electrical power supply
at service panel and allow unit to cool before pro-
ceeding to avoid possible electrical shock and
scald hazard. Failure to do so can cause severe
personal injury or death.
2022-06 Exalt FSB Control Module
Replacement Revised 1/12/2022
Description
Control Module Replacement
NOTICE
Indicates special instructions on installation, operation
or maintenance, which are important to equipment
but not related to personal injury hazards.
WARNING
!
Failure to follow instructions below can result in
severe personal injury or damage if ignored.
•
•
•
Model
All Exalt Floor
Standing Models
Instructions are for a qualified installer/ ser-
vice technician only.
Read all instructions before proceeding.
Follow instructions in proper order.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the EXRKIT134 and is the answer not in the manual?

Questions and answers

Related Manuals for IDEAL EXRKIT134

Summary of Contents for IDEAL EXRKIT134

  • Page 1 Exalt Floor Standing Control Module Replacement Kit Part Number Description Model All Exalt Floor EXRKIT134 Control Module Replacement Standing Models Each Kit Includes: • Control Module Recommended Tools: • Phillips Head Screwdriver NOTICE WARNING Indicates special instructions on installation, operation...
