Summary of Contents for Toro 03618
- Page 1 Form No. 3433-307 Rev A Verticutter Reelmaster ® 5010-H Series Cutting Unit with 7in Reel Model No. 03618—Serial No. 405130001 and Up Model No. 03619—Serial No. 405130001 and Up *3433-307* A Register at www.Toro.com. Original Instructions (EN)
- Page 2 Whenever you need service, genuine Toro parts, or Serial No. additional information, contact an Authorized Service Dealer or Toro Customer Service and have the model and serial numbers of your product ready. Figure 1 This manual identifies potential hazards and has...
- Page 3 Operator’s Manual before starting the machine. (RM5010–Hybrid only) ........7 • Use your full attention while operating the 5 Installing the End-Weight Kit (Model 03618 machine. Do not engage in any activity that only) ..............8 causes distractions; otherwise, injury or property 6 Adjusting the Verticutter ........
- Page 4 • Use only accessories, attachments, and replacement parts approved by Toro. Safety and Instructional Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or missing.
- Page 5 Cotter pin O-ring Install the O-ring and the grease fitting. Straight grease fitting Install the shoulder bolt Shoulder bolt (RM5010–Hybrid only) Install the end-weight kit (Model 03618 End-weight kit (sold separately) only). – No parts required Adjust the verticutter. –...
- Page 6 Installing the Transport Installing the O-ring and Rollers the Grease Fitting Parts needed for this procedure: Parts needed for this procedure: Transport roller assembly O-ring Cotter pin Straight grease fitting Procedure Procedure Secure a transport roller bracket to each side plate pin Install the grease fitting on the reel-motor side of the with a cotter pin (Figure...
- Page 7 Installing the Shoulder Bolt (RM5010–Hybrid only) Parts needed for this procedure: Shoulder bolt Procedure For verticutters being mounted on a Reelmaster g028407 5010-H, replace the shoulder bolt on the reel-motor Figure 5 side-plate (Figure 7) with the new shoulder bolt; 1.
- Page 8 Installing the End-Weight Adjusting the Verticutter Kit (Model 03618 only) No Parts Required Parts needed for this procedure: Procedure End-weight kit (sold separately) Refer to Adjusting the Verticutter (page Procedure Buy and install the end weight kit appropriate for the...
- Page 9 03619 59.9 kg (132 lb) penetration depths are as follows: • Model 03618 is 3 mm (1/8 inch). • Model 03619 is 6 mm (1/4 inch). Place the verticutter reel on a level surface. Place 2 gauge bars, which have the desired...
- Page 10 Adjusting the Rear Grass Shield Note: When operating in turf conditions where there is excessive debris or thatch, open the rear discharge shield to help allow the debris to discharge from the reel. Loosen the bolts on the pivot of the grass shield (Figure 10).
- Page 11 (setting 9) and at the desired traction speed. • The maximum recommended blade penetration depths are as follows: – Model 03618 is 3 mm (1/8 inch). – Model 03619 is 6 mm (1/4 inch). • Power requirements to operate the verticutter reels will vary with turf and soil conditions.
- Page 12 Maintenance Lubricating the Verticutter Each verticutter has 5 grease fittings (Figure 13) that Using the Kickstand When must be lubricated weekly with No. 2 lithium grease. The lubrication points are the front roller (2), the rear Tipping the Cutting Unit roller (2), and the reel motor splines (1).
- Page 13 109 to 135 N-m (80 to 100 ft-lb). 1. Shaft 4. Small spacer 2. Nut 5. Blade (25 for model 03618; 16 for model 03619) 3. Washer 6. Large spacer (24 for model 03618; 15 for model...
- Page 14 Optional Blade Spacing 0.50-Inch Blade Spacing for Model 03618 To change the configuration of the verticutter from the standard 0.75-inch spacing to the 0.50-inch spacing requires an additional 34 spacers, Part No. 17-1580 and an additional 10 carbide blades, Part No. 106-6355, or an additional 10 regular blades and Part No.
- Page 15 Refer to your parts catalog or Roller Rebuild Tool Kit (Part No. 115-0803) (Figure contact your authorized Toro distributor for assistance. 18) are available for servicing the roller. The Roller Rebuild Kit includes all the bearings, bearing nuts,...
- Page 16 Notes:...
- Page 17 Notes:...
- Page 18 The method of transmission shall be electronic transmittal. This machinery shall not be put into service until incorporated into approved Toro models as indicated on the associated Declaration of Conformity and in accordance with all instructions, whereby it can be declared in conformity with all relevant Directives.
- Page 19 The Toro Company (“Toro”) respects your privacy. When you purchase our products, we may collect certain personal information about you, either directly from you or through your local Toro company or dealer. Toro uses this information to fulfil contractual obligations - such as to register your warranty, process your warranty claim or to contact you in the event of a product recall - and for legitimate business purposes - such as to gauge customer satisfaction, improve our products or provide you with product information which may be of interest.
- Page 20 Countries Other than the United States or Canada Customers who have purchased Toro products exported from the United States or Canada should contact their Toro Distributor (Dealer) to obtain guarantee policies for your country, province, or state. If for any reason you are dissatisfied with your Distributor's service or have difficulty obtaining guarantee information, contact your Authorized Toro Service Center.
