Jensen PS2130 - Amplifier Installation & Operation Manual

Audiovox Electronics Corporation
150 Marcus Boulevard
Hauppauge, NY 11788
1-800-323-4815
www.jensen.com
© 2004 Audiovox
v.030204
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Indicators and Controls . . . . . . . . . . . . . . . . . . . . . 9
Testing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Audio Precision . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
R
Amplifier
Installation &
Operation Manual
PS260
PS285
PS2130
PS2180
Introduction
Thank you for purchasing a Jensen amplifier. PS series amplifiers offer extreme value and performance. Proper installation is
essential for optimal performance and long-term reliability. Please read through this manual to familiarize yourself with your
amplifier and its functions.
Warranty Service
If your Jensen amplifier should ever require service, you will need to have the original dated receipt. If you need to return the unit
for any reason, always include the receipt with the product.
Installation Assistance
For installation assistance, call 1-800-323-4815 during normal business hours, or visit www.jensen.com at any time.
Features
• Continuously variable high pass/low pass crossover
• State-Variable crossover design for precision frequency adjustment
• 12dB/octave Butterworth alignment
• 40Hz – 400Hz crossover frequency range
• iX² Bass with continuously variable 0dB to 18dB bass boost centered at 45Hz
• Input level control with a 300mV to 8V input range
• High level inputs for interfacing with OEM/factory head units
• Full range pre-amp output for installation flexibility
• Dual status LED diagnostic indicator
• Thermal, short circuit and low impedance protection circuitry
• Unregulated Pulse Width Modulated (PWM) power supply for extended dynamic range
• Balanced driver circuitry and complementary output stage design for low distortion and unparalleled stability
• High current output stage easily drives 2 ohm loads
• Bridgeable for mono operation
