PACKAGE CONTENTS
A - Solar head x 1
PLANNING FOR A SUCCESSFUL ASSEMBLY
Read all instructions before assembly and installation.
Inspect each part for defects that may have occurred during shipping.
Keep your receipt and these instructions for proof of purchase.
CHOOSING THE RIGHT LOCATION
Install your solar light in a location with full, direct sunlight. Do not install in shaded areas as these areas will not allow the batteries to fully charge and will reduce
the nighttime operating hours for your light. Ensure that the installation location is away from other nighttime light sources such as street or porch lamps. These light
sources may prevent your solar light from automatically turning on.
HOW SOLAR WORKS
The solar light has a solar panel that converts sunlight into electricity. During the day, the converted electricity is stored in the rechargeable batteries. At night, the
solar light is powered by the batteries using the electricity stored during the day. The operating time depends on geographical location, daily weather conditions, and
season. For optimal performance during the evening, allow the batteries to charge for 6 to 7 hours in direct sunlight.
Assembly and Installation
1
Preparing for installation
NOTE: The solar panel will turn the light on
automatically at dusk.
□ FOR FIRST TIME USE: Remove the pull tab at the solar head (A).
Use and Care Guide
Solar LED Path Light
A
B
B - AA 1.2V 1000mAh Ni-Mh
rechargeable battery (pre-installed) x 1
Remove pull tab
C - Battery cover x 1
2
Installing the solar path light in the ground
NOTE: Do not use a hammer. If the ground is hard,
use water to soften or a trowel to loosen the soil.
□ Attach the solar head (A) to the post (D) by inserting the bottom of the
hook (1) into the top of the post (D) and turning it clockwise until it is
tight.
□ Attach a second post (D) to the bottom of the assembly and turn it
clockwise until tight.
□ Attach the solar head (A) and posts (D) to stake (E). Push the assembly
A
firmly into the ground.
Please contact 1-855-HD-HAMPTON for further assistance.
Item #1001 586 703
Model #73415
C
D
D - Post x 2
1
D
D
E
E
E - Stake x 1
A
HOMEDEPOT.CA
Advertisement
Related Manuals for HAMPTON BAY 73415
Summary of Contents for HAMPTON BAY 73415
- Page 1 Item #1001 586 703 Model #73415 Use and Care Guide Solar LED Path Light PACKAGE CONTENTS A - Solar head x 1 B - AA 1.2V 1000mAh Ni-Mh C - Battery cover x 1 D - Post x 2 E - Stake x 1...
- Page 2 Maintenance Replacing the battery CAUTION: When replacing the battery, use one (1) 1000mAh NiMH AA 1.2V rechargeable battery. IMPORTANT: Dispose of the batteries in accordance with local, state, and federal regulations. NOTE: For best performance, replace with a rechargable 1.2V NiMH battery of 1000mAh or greater every 3 years or when performance diminishes.
- Page 3 Article nº 1001 586 703 Modèle nº 73415 Guide d’utilisation et d’entretien Luminaire à DEL solaire pour voie d’accès CONTENU DE L’EMBALLAGE A - 1 tête solaire B - 1 pile AA rechargeable au nickel-hydrure C - 1 couvercle de D - 2 montants E - 1 piquet métallique de 1,2 V, 1 000 mAh (préinstallée) compartiment à pile PRÉPARATION POUR UN ASSEMBLAGE RÉUSSI Lisez toutes les instructions avant de procéder à...
- Page 4 Entretien Remplacement de la pile ATTENTION : Lorsque vous remplacez la pile, utilisez une (1) pile AA rechargeable au nickel- hydrure métallique de 1 000 mAh et 1,2 V. IMPORTANT : Jetez les piles conformément aux réglementations locales, provinciales et fédérales. REMARQUE : Pour le meilleur rendement, remplacez par une pile rechargeable de 1,2 V au nickel-hydrure métallique d’au moins 1 000 mAh tous les trois ans ou lorsque son rendement diminue.
Need help?
Do you have a question about the 73415 and is the answer not in the manual?
Questions and answers
I purchased Laurelview Path Lights from Home Depot. Three of them work perfectly however one of them lit up as soon as I removed the orange tab to engage the battery. I charged in sunlight per the instructions but it did not work the next night. I replaced the battery with a Hampton Bay battery but once again as soon as I put in the new battery it lit up in broad daylight. Is there a way this can be fixed? Thank you!
