Economical Humidity Monitoring
C
ONTENTS
This package contains:
• 1
HA-1
• 2
Wire nuts
• 2
Lead wires
• 1
Owner's Manual
S
PECIFICATIONS
Power Requirement
Sensing Range
Sensing Element
Response Time
Output Contact Ratings
Operating Temperature
Optimum Operating Temperature
Accuracy:
Weight
Dimensions
Case Material
Mounting
• 1
Rubber mounting gasket (duct mounting only)
• 1
Adhesive mounting template/instructions (duct mounting only)
• 2
Mounting screws (for use with single-gang wall box)
None
20-80% R.H. ±10% R.H.
Nylon band
TC = 12 min.
1A @ 24VAC/VDC, resistive
60 to 90° F (15 to 32° C); non-condensing environment
Indoor use only.
70° F (21.1° C)
±10% R.H. @ 20-80% R.H., 77° F (25° C)
8 oz (0.23 kg)
5 x 3.18 x 2.43" (12.7 x 8.1 x 6.2 cm)
ABS
Wall, wall box, or duct surface
Tech Support 8:00am - 5:00pm Central Time
(800) 635-4269 • +1-507-625-7231 P
www.winland.com
https://manual-hub.com/
HA-1
© 2012 Winland Electronics, Inc.
Z1902 Rev D (08/2012)
