Cisco MERAKI MV93 Instruction Manual

Hide thumbs

Advertisement

Table of Contents

MV93X-HW ; MV93-HW
MV93/93X Overview
The Cisco Meraki MV93/93X is a network fisheye camera that is exceptionally simple to deploy and
configure due to its integration into the Meraki Dashboard and the use of cloud augmented edge storage.
The MV family eliminates complex and costly servers and video recorders required by traditional solutions
which removes the limitations typically placed on video surveillance deployments.
Before mounting to any surface, ensure you have read through the
placement guidelines
below to ensure
best field of view.
Package Contents
In addition to the MV camera, the following are provided:
20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV93 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cisco MERAKI MV93

Summary of Contents for Cisco MERAKI MV93

  • Page 1 MV93X-HW ; MV93-HW MV93/93X Overview The Cisco Meraki MV93/93X is a network fisheye camera that is exceptionally simple to deploy and configure due to its integration into the Meraki Dashboard and the use of cloud augmented edge storage. The MV family eliminates complex and costly servers and video recorders required by traditional solutions which removes the limitations typically placed on video surveillance deployments.
  • Page 2 From top-left to bottom-right: • 1 x MV93/93X • 1x Allen wrench with T10 Torx head • 3x Phillips head mounting screws and anchors • 1x Mount plate...

  • Page 3: Pre-Install Preparation

    You should complete the following steps before going on-site to perform an installation: Configure Your Network in Dashboard The following is a brief overview only of the steps required to add an MV93/93X to your network. For detailed instructions about creating, configuring and managing Meraki Camera networks, refer to the online documentation (https://documentation.meraki.com/MV).

  • Page 4: Assigning Ip Addresses

    Google public DNS. Assigning IP Addresses At this time, the MV93/93X does not support static IP assignment. MV93/93X units must be added to a subnet that uses DHCP and has available DHCP addresses to operate correctly.
  • Page 5 1. First route the Ethernet cable through the ceiling surface or ceiling tile hole. Position the mounting template such that the "Meraki MV93" or “Meraki MV93X” text is aligned with your desired image orientation. This could mean orienting the image to align...
  • Page 6 It is important that care is taken during this step! The image sensor on the fisheye camera is fixed. Once physical installation is complete, the image can only be rotated by 180 degrees in software and no other adjustments can be made. Note: Never attempt to open the camera dome to adjust the lens rotation.
  • Page 7 2. Follow this in-depth cable gland assembly guide to connect the PoE cable to the camera cable gland and ensure seal is water-tight. This step is very important and may result in damage to the camera if done improperly.
  • Page 9 3. Slide camera over top of mount plate and rotate onto mount plate hooks. 4. Remove the protective cover to expose the dome, security screw hole, status LED, and microphone.
  • Page 10 5. Secure Torx safety screw with provided Torx key.
  • Page 11 6. Observe the status LED on the left side of the camera lens assembly and ensure the camera is connected via Ethernet (solid green) or WiFi (solid blue). A MV must first be provisioned over a wired Ethernet connection before it can be deployed wirelessly. For information on how to connect via WiFi, see the setup guide here.
  • Page 12 Your MV93/93X is equipped with a LED light on the front of the unit to convey information about system functionality and performance. The various status conditions of a MV are indicated by the following colors and patterns: Rainbow (solid, rotating through colors) - MV is booting up.

  • Page 13: Regulatory Information

    Regulatory Information FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 14 If the device is going to be operated in the 5.15 - 5.25 frequency range, then it is restricted to indoor environment only. This device meets all other requirements specified in Part 15E, Section 15.407 of the FCC Rules. Industry Canada Statement This device complies with RSS -247 of the Industry Canada Rules.
  • Page 15 Industry Canada Radiation Exposure Statement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. Déclaration d’exposition aux radiations Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non con trôlé.

This manual is also suitable for:

Mv93xMv93-hwMv93x-hw
