Page 1
MV13 camera. MV13 Overview The Cisco Meraki MV13 series are network cameras that are exceptionally simple to deploy and configure due to their integration into the Meraki Dashboard and cloud-augmented edge storage. The MV family eliminates complex and costly servers and video recorders required by traditional solutions, removing the limitations typically placed on video surveillance deployments.
Page 2
1 x T10 Torx key Mounting Equipment 1 x Small Mounting Plate 1 x Conduit Adapter MV13 series does not ship with mounting screws and anchors as an included accessory in the packaging content. Screw Recommendation: • Type: Self-Tapping Screw • Size: M4 •...
You should complete the following steps before going on-site to perform an installation: Configure Your Network in the Dashboard The following briefly overviews the steps required to add an MV13 series camera to your network. For detailed instructions about creating, configuring and managing Meraki Camera networks, refer to the online documentation (https://documentation.meraki.com/MV).
Assigning IP Addresses Currently, the MV13 series camera does not support static IP assignment. MV13 units must be added to a subnet with DHCP and available DHCP addresses to operate correctly. Installation Instructions Note: The MV13 series will automatically update to the latest stable firmware during a first-time setup. Some features may be available once this automatic update is completed.
Page 5
Installing the conduit box to MV13 series: (optional)
Page 6
Microphone Cut-off Switch & Factory Reset Button The MV13 has a new microphone cut-off switch at the camera's base. This switch can be used to disable audio and override the Dashboard Audio Settings for an added layer of security. If the regulations require disabling audio or Dashboard control for Audio enablement needs to be disabled, the microphone cut-off switch can be leveraged and set to Disabled.
Page 7
• Mount the small base plate onto the wall surface using the paper template provided. • The MV13 Series cameras have a button to engage the locking mechanism. Press the button while aligning the MV13 to the small base plate.
Page 8
• Twist the camera while holding the button until a click is heard. • The camera is locked onto the plate and secured. • Remove the protective cover...
Page 9
WiFi. MV13 LED Status Indicator Your MV13 series is equipped with an LED light on the front of the unit to convey system functionality and performance information. The following colours and patterns indicate the various status conditions of an MV: •...
Page 10
Note: Never adjust or remove the rubber lens gasket or protective lens guard.
