Taylor 3804-44 Instruction Manual

One Year Limited Warranty
Taylor® warrants this product to be free from defects in material or
workmanship for one (1) year from date of original purchase. It does not
cover damages or wear resulting from accident, misuse, abuse, commercial
use, or unauthorized adjustment and/or repair. If service is required, do not
return to retailer. Should this product require service (or replacement at our
option), please pack the item carefully and return it prepaid, along with store
receipt showing the date of purchase and a note explaining reason for return
to:
Garantie limitée d'un an
Taylor® garantit que ce produit est libre de tout défaut de matériaux ou de
main d'œuvre pour une période d'un (1) an à partir de la date d'achat
original. Elle ne couvre pas les dommages ou l'usure suite à un accident, une
mauvaise utilisation, tout abus, utilisation commerciale ou réglage interdit
et/ou réparation interdite. Si l'appareil doit être réparé, ne le retournez pas
au détaillant. Si ce produit doit être réparé (ou remplacement à notre
discrétion), veuillez l'emballer avec soin et le retourner à frais prépayés avec
la facture du magasin indiquant la date d'achat et une note expliquant la
raison du retour à l'adresse suivante:
Garantía limitada por un año
Taylor® garantiza este producto contra defectos en los materiales y en la
mano de obra durante 1 (un) año a partir de la fecha de compra original. No
cubre daños ni desgastes que sean consecuencia de accidentes, uso
inadecuado, abuso, uso comercial, ni ajustes y/o reparaciones no
autorizadas. Si necesita mantenimiento, no la devuelva al vendedor minorista.
Si este producto requiere mantenimiento (o cambio a nuestro entender),
sírvase empacar el artículo cuidadosamente y envíelo con el franqueo
pagado, junto con el recibo de la tienda en el que aparezca la fecha de
compra y una nota explicando el motivo de la devolución a:
TAYLOR Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico 88001 USA
www.taylorusa.com
Email: taylorusa@lifetimebrands.com
There are no expressed warranties except as listed above. This warranty gives
you specific legal rights, and you may have other rights which vary from state
to state.
Il n'y a aucune garantie expresse sauf celle indiquée précédemment. Cette
garantie vous donne des droits précis, mais vous pouvez aussi avoir d'autres
droits qui varient d'une juridiction à l'autre.
No existen garantías expresas excepto las enunciadas anteriormente. Esta
garantía le otorga derechos legales específicos y es posible que usted tenga
otros derechos que varíen de un estado a otro.
Battery Installation
1. This scale operates on 4 "AA" batteries (not included). Always replace all
batteries at the same time; do not combine old and new batteries. Do not
mix alkaline, standard (carbon-zinc) or rechargeable (ni-cad, ni-mh, etc.)
batteries. Do not dispose of batteries in fire, as batteries may explode or
leak. Remove the batteries if the scale will not be used for a long period of
time.
2. Open the battery compartment on the bottom of the scale by sliding the
cover in the direction of the "open" arrow and remove cover.
3. Place the batteries into the battery compartment as indicated by the
polarity symbols marked in the compartment.
4. Slide the battery compartment cover back into place until it clicks shut.
5. Replace the batteries if "LO" appears on the display, or the readings grow
dim or irregular.
NOTE: Please recycle or dispose of batteries per local regulations.
WARNING: Batteries may pose a choking hazard. As with all small items, do
not let children handle batteries. If swallowed, seek medical attention
immediately.
PRECAUTION: Do not dispose of batteries in fire. Batteries may explode or
leak. Remove the batteries if the scale will not be used for a long period of
time.
General Weighing Operation
1. Place the scale on a hard, level surface.
2. Press the "ON/OFF" button to turn the scale on. The display first shows
"8888", then "0.0" when it is ready for use. If the display does not show "0.0",
press the "TARE" button to reset (tare) the scale to zero.
3. Your scale is set at the factory to weigh in ounces. To switch to grams, move
the switch on the bottom of the scale to "g". The display will change to
grams.
4. Place the item to be weighed on the center of the platform. The weight will
display. As you add weight, the weight displayed increases.
©2019 Taylor Precision Products, a division of Lifetime Brands Inc. All rights reserved.
©2019 Taylor Precision Products, une division de Lifetime Brands Inc. Tous droits réservés.
©2019 Taylor Precision Products, división de Lifetime Brands Inc. Todos los derechos
Made to our exact specifications in China.
Fabriqué en Chine selon nos spécifications exactes.
Fabricado en China según nuestras especificaciones exactas.
Tare Operation (Cont.)
1. Choose a container that will safely balance on the platform without tipping
or falling. Do not use a heavy container, as this might reduce the maximum
capacity of the scale.
2. While the scale is off, place the empty container on the scale platform.
Turn the scale on. The display will show "8888" then "0.0". The weight of the
container has been zeroed out.
3. Add the ingredient to be weighed. The weight of the ingredient alone will display.
4. The weight of additional ingredients may be tared out as well. For example, if a
recipe calls for ½ lb rice and ½ lb beans, place the rice into the bowl. Once the
correct amount of rice is weighed, press the "TARE" button until the display is reset
to zero. Add the ½ lbs of beans. Both ingredients have been accurately weighed
in the same bowl.
5. When weights have been tared out, the display will show a negative number
when the items are removed from the scale. To reset the scale back to zero for a
new measurement, press the "TARE" button until the display resets to zero.
Precautions
1. Clean exposed parts with a soft, slightly damp cloth. To remove stains, use a
mild soap. Never use detergents, excess water, treated cloths, harsh cleaning
agents, or sprays.
2. Do not tamper with the scale's internal components. Doing so will invalidate the
warranty on this unit and may cause damage. The scale contains no user-
serviceable parts
3. Although your scale is designed to be maintenance-free, it contains sensitive
electronic parts. Avoid rough treatment. Treat it with care to ensure the best
performance.
4. This scale is intended for home/consumer use only. It is not intended for
commercial or medical use.
5. This scale is designed to read weights up to 4.4 lbs/2 kgs. To prevent damage, do
not place more than 4.4 lbs/2 kgs on it.
6. Do not store scale where you store cleaning chemicals. The vapors from some
household products may affect the electronic components of your scale. Do
not store scale on its side.
7. This scale is an extremely sensitive weighing device. In order to prevent run
down of the battery, do not store anything on the scale.
3804-44
Digital Kitchen Scale
Balance Numérique de Cuisine
Báscula de Cocina Mecánica
Thank you for purchasing a Taylor® Kitchen Scale. Your scale is an
example of superior design and craftsmanship. Please read this
instruction manual carefully before use. Keep these instructions
handy for future reference.
Merci de votre achat d'une balance de cuisine Taylor®. Votre
balance est un exemple de design et de travail supérieurs. Veuillez
lire attentivement votre manuel d'instructions avant d'utiliser
l'appareil. Conservez ces instructions à portée de la main à titre de
référence.
Gracias por comprar una báscula de cocina Taylor®. Su báscula
es un ejemplo de diseño y mano de obra superiores. Antes de
usarla, sírvase leer con atención este manual de instrucciones.
Guarde estas instrucciones en un lugar de fácil acceso para
referencia futura.
3804-44 4.19
FCC Notice
Party issuing Supplier's Declaration of
Conformity & Responsible party – U.S.
Contact information:
Taylor Precision Products
2311 W. 22nd Street, Suite 200
Oak Brook, IL 60523
We declare under our sole responsibility that the above referenced
product has been tested according to FCC requirements and this device
complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Note: This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. This equipment
has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
MANUAL DE INSTRUCCIONES
Equipment:
Product Name: Kitchen Scale
Model No.: 380444
Trade Name: Taylor
