Summary of Contents for Daitsu ACCD WC8
- Page 1 USER AND INSTALLATION MANUAL WIRE CONTROLLER ACCD_WC8 WIRE CONTROLLER ACCD_WC8 09/24...
- Page 2 This manual gives detailed description of the precautions that should be brought to your attention during operation. In order to ensure correct service of the wired controllerplease read this manua l carefully before using the unit. For convenience of future reference, keep this manual after reading it. All the pictures in this manual are for explanation purpose only.
- Page 3 Table of Contents 1. Safety precautions ................1 2. Installation accessories ................2 3. Installation method ................4 4. Specification ...................9 5. Features and function of the wired controller ........10 6. Names on the LCD of the wired controller ...........11 7. Names of button on the wired controller ..........12 8.Explanation of buttons ................13...
- Page 4 1. Safety precaution WARNING • Please entrust the distributor or profressionals to install the unit. • Installation by other persons may lead to imperfect installation,electric shock or fire. • Adhere to this installation manual. • Imporper installation may lead to electric shock or fire. Reinstallation must be performed by professionals.
- Page 5 1. Safety precaution NOTE • The specified cables shall be applied in the wiring. No external force may be applied to the terminal. Otherwise, wire cut and heating may occur and result in fire. 2. Installation accessory Select the installation location Don’t install at the place where cover with heavy oil, vapor or sul- fureted gas, otherwise, this product would be deformed that would lead to system malfunction.
- Page 6 2. Installation accessory 2. Prepare the following assemblies on the site. Specification Qty.(embeded Remarks Name (only for reference) into wall) Switch box Wiring Tube(Insulating Sleeve and Tightening Screw) Precaution of installing the wire controller 1. This manual provides the installation method of wired controller. Please refer to the wiring diagram of this installation manual to connect the wire controller with indoor unit.
- Page 7 3. Installation method 1.Wired remote controller structural dimensions Fig 3-1 2.Remove the upper part of wired controller Insert a slot screwdriver into the Buckling position slots in the lower part of the wired Back cover controller (2 places), and remove the upper part of the wire Front cover controller.
- Page 8 3. Installation method NOTE: The PCB is mounted in the upper part of the wired controller. Be careful not to damage the board with the slot screwdriver. 3. Fasten the back plate of the wired controller For exposed mounting, fasten the back plate on the wall with the 3 screws (M3.5×25) and plugs.
- Page 9 3. Installation method NOTE:Put on a flat surface. Be careful not to distort the back plate of the wire controller by overtightening the mounting screws. 4. Battery installation Battery installationsite Fig 3-5 Put the battery into the installationsite and make sure the positive side of the battery is in accordance with the positive side of installationsite.(See Fig.3-5) Please set the time corrected on the first time operation.
- Page 10 3. Installation method 5. Wire with the indoor unit wiring hole Fig 3-6 1 indoor unit 2 notch the part for the wiring to pass through with nippers, etc. NOTE: Do not allow water to enter the remote control. Use the trap and putty to seal the wires.
- Page 11 3. Installation method 6.Installation Diagram Connect the wire from the master control board of the indoor unit to a connecting cable. Then connect the other side of the connecting cable to the remote control. The connective wires group 4-core wire Magnetic ring shielded wire...
- Page 12 3. Installation method 7. Reattach the upper part of the wire controller After adjusting the upper case and then buckle the upper case; avoid clamping the wiring during installation. (Fig 3-9) All the pictures in this manual are for explanation purpose only. Your wire controller may be slig- htly different .The actual shape shall prevail.
- Page 13 5. Feature and function of the wired controller Feature: LCD display. Malfunction code display: it can display the error code, helpful for service. 4-way wire layout design, no raised part at backside, more convenient to place the wires and install the device. Room temperature display.
- Page 14 6. Name on the LCD of the wired controller 10 9 1. MODE 7. CLOCK 13. WEEK 2. DUST FULL 8. SWING 14. POWER-DOWN MEMORY 3. DOOR CARD 9. WEEK TIMER 15. ERROR 4. MAIN IDU 10. TIMER ON/OFF 16. TEMPERATURE SETTING 5.
- Page 15 7. Name of button on the wired controller 1. [ON/OFF] button 6. [UP-DOWN SWING] button 7. [LEFT-RIGHT SWING] button 2. [MODE] button 8. [TIMER] button 3. [UP] button 9. [FUNC.] button 4. [DOWN] button 10. [ENTER] button 5. [FAN SPEED] button 11.
- Page 16 8.Explanation of buttons 1. [ON/OFF]button Press the button “ ” to control the power on and off of the air conditioner. 2. [MODE]button Press the button “ ”to change the air conditioner running modes cyclically:AUTO COOL DRY FAN HEAT. 3.
- Page 17 1) SLEEP: When the icon “ ”blinks, if you click the button“ ” ,you can activate or inactivate the sleep function; 2) I FEEL: When the icon“ ”blinks, if you click the button“ ”,you can activate or inactivate the i feel function; 3) HEALTH: When the icon“...
- Page 18 You can change the device function code by clicking the buttons“ ” and “ ”; if you click the button“ ”, it means that you have selected the target function, and then you can set the function parameter. At the moment, the temperature zone will blink and display the current func- tion parameter and you can change it by clicking the button“...
- Page 19 2)You can select the day of the week by clicking the button “ ” or “ ” and then you can click the button“ ”for confi- ＋ rmation; 3)You can set the hour value by clicking the button“ ” or “...
- Page 20 after selecting the target timer function, you can click the button “ ” for confirmation and access the timer function setting in- terface. The WEEK TIMER 2 allows the setting of the power-on mode, the temperaturevalue and the fan speed. 2) TIMER ON/OFF function setting (1) After you access the timer on/off function setting interface, the timer zone willblink;...
- Page 21 the function button “ ” again, if the temperature zone dis- plays “OFF”, it means that the current date setting has not gone into effect; after that, you can click the button “ ” for confirmation; (4) You can click the button“ ” or “ ”to switch between Day on and Day off, and then you can click the button“...
- Page 22 (3) You can click the button“ ” or “ ” to select the date of the week timer from sunday to saturday; after you can click the button“ ”;if the temperature zone displays“ON” , it means that the current date setting has gone into effect;...
- Page 23 the timer and then you can click the button“ ”for confirmation； (6) You can click the button“ ” or “ ”to select the minute value of the timer and then you can click the button“ ”for confirmation； (7)Repeat step (2) to (6) to set other tasks of the WEEK TIMER 2 (8)After completing the timer setting operations,you can click the button “...
- Page 24 DISPOSAL GUIDELINE This appliance contains refrigerant and other potentially hazardous mat- erials. When disposing of this appliance,the law requires special collect- ion and treatment. DO NOT dispose of this product as household waste or unsorted municipal waste. When disposing of this appliance, you have the following options: Dispose of the appliance at designated municipal electronic waste colle- ction facility.
- Page 25 Eurofred S.A. Marqués de Sentmenat 97 08029 Barcelona www.eurofred.es...
