  • Page 1 GL10 Gimbal Searchlight User Manual V1.0 2023.8.9...

  • Page 2: Table Of Contents

    目录 I.Disclaimers and Warnings ............. 1 II.Introduction to GL10 Gimbal Searchlight ......2 III.Activation Tutorial for GL10 Gimbal Searchlight ....5 Ⅳ.User Manual for GL10 Gimbal Searchlight......11 Ⅴ.Firmware Upgrade Tutorial for GL10 Gimbal Searchlight.16 5.1 Firmware Upgrade through Bluetooth ...... 16...

  • Page 3: I.disclaimers And Warnings

    The right for final interpretation of this article and all related documents is vested in CZI. Subject to update without notice. Please visit www.gzczzn.com for the latest product information.

  • Page 4: Ii.introduction To Gl10 Gimbal Searchlight

    The GL10 Gimbal Searchlight is the first lightest gimbal searchlight in the industry, designed specifically for the DJI Mavic 3 industrial drone, weighing less than 140g and with a rated power of 20W. The GL10 Gimbal Searchlight features an optical imaging lens structure with an emission angle of 13°. By connecting to the DJI Pilot 2 APP, you can control the power switch, switch between steady light and flashing modes, and the light will automatically...
  • Page 5 ② ① ③ ④ (1)GL10 Gimbal Searchlight (Front view) ⑤ ⑥ (2)GL10 Gimbal Searchlight (Rear view) 1) Red and blue light 2) White spotlight 4) Power and communication port 3) Anti-loose screw 6) Indicator light 5)Reset button...

  • Page 6: Technical Parameter

    Technical Parameter Model GL10 Electrical interface DJI PSDK Weight / g 130±4% Dimension / mm L107*W128*H51.5 Total power / W White LED power /W Red and blue LED power / W Supply voltage / V Luminous flux / lm 1830±3% 12.5...

  • Page 7: Iii.activation Tutorial For Gl10 Gimbal Searchlight

    III.Activation Tutorial for GL10 Gimbal Searchlight 3.1 Activate in the czi sound APP 3.1.1 Open the czi sound APP, register, and log in to your account. Enter the main interface and click on Connect Device.
  • Page 8 3.1.2 Select the Available device.
  • Page 9 3.1.3 Click on Activate Now.
  • Page 10 3.1.4 The interface displays the Product serial number (e.g., 1PNX) and Activation time (e.g., 2023-06-27), indicating that the device has been successfully activated.
  • Page 11 3.2、 Activate in the czi Pilot app 3.2.1 Properly install the GL10 Gimbal Light on the drone. Enable Bluetooth on the remote controller and open the czi Pilot APP. Search for and connect to the GL10 device. Click on Activate.
  • Page 12 3.2.2 Activation notice popup. Follow the instructions and click Agree. 3.2.3 Successfully activated.

  • Page 13: Ⅳ.user Manual For Gl10 Gimbal Searchlight

    IV.User Manual for GL10 Gimbal Searchlight 4.1. User Manual for DJI Pilot 2 4.1.1 Install the GL10 on the drone and tighten the screws securely. 4.1.2 Power on the drone correctly (short press for one second or long press for three seconds) to start the drone.
  • Page 14 4.1.5 Click the PSDK button to display the control buttons of GL10.
  • Page 15 4.1.6 Introduction to GL10 Gimbal Searchlight Control Buttons. Turn off the light Turn on the light Turn off the Turn on the flashing mode flashing mode Turn off the Turn on the warning lights warning lights Activate red Activate blue...
  • Page 16 4.2 czi Pilot User Tutorial 4.2.1 Install the GL10 on the drone and tighten the screws securely. Open the czi Pilot app on the remote controller. 4.2.2 Click on Enter the device.
  • Page 17 4.2.3 Click on the GL10 icon in the top-left corner. ZOOM 4.2.3 Click on the GL10 icon in the top-left corner.

  • Page 18: Ⅴ.firmware Upgrade Tutorial For Gl10 Gimbal Searchlight.16

    V.Firmware Upgrade Tutorial for GL10 Gimbal Searchlight 5.1 Upgrade using DJI Assistant 2 5.1.1 Install the GL10 Gimbal Searchlight on the drone and power on the drone. Open DJI Assistant 2 on your PC and use the Type-C cable provided with the drone to connect the computer and the drone.
  • Page 19 5.1.3 Download the latest firmware from the official website www.gzczzn.com to your local device. Select the latest firmware bin file and click on Upgrade. 5.1.4 Waiting for upgrade.
  • Page 20 5.1.5 Upgrade completed.

  • Page 21: Firmware Upgrade Through Czi Pilot

    5.2 Upgrade in czi sound APP. 5.2.1 Enter the czi sound APP.
  • Page 22 5.2.2 Connect the devices.
  • Page 23 5.2.3 Click on Check for upgrade.
  • Page 24 5.2.4 Select local bin file. 5.2.5 Waiting for upload.
  • Page 25 5.2.6 Waiting for upgrade. Uploaded successfully,waiting for upgrade...
  • Page 26 ChengZhi Support www.gzczzn.com Service hotline: 400-008-8306 If you have any questions or suggestions about the instructions, Please contact us through the following email address: Printed in China service@gzczzn.com...
