LP35

探照广播一体机

Searchlight and Broadcasting System

用户说明书

V1.1

2024.5

Table of Contents

Need help?

Do you have a question about the LP35 and is the answer not in the manual?

Questions and answers

Summary of Contents for Czi LP35

Page 1 LP35 探照广播一体机 Searchlight and Broadcasting System 用户说明书 V1.1 2024.5...
Page 3: Table Of Contents
二、产品概述................ 01 三、安装-拆卸教程 ..............03 四、 czi Pilot App控制 ............05 五、音频文件上传与固件升级..........10 Contents: I. Product Precautions ............19 II. Product Overview............19 III. Installation - Disassembly Tutorial .......22 IV. czi Pilot App Control ............24 V. Audio File Upload and Firmware Upgrade ....30...
Page 5: 一、产品注意事项
警告事项 LP35 探照广播一体机属于精密设备，如遇硬件问题，请返厂联系售后服务，切勿自行拆卸维修，否则将失去保修、维修资格。注意事项 1、近距离或者室内使用喊话功能会对人耳听力造成永久性伤害 ! 请谨慎使用 ! 2、探照灯内含精密光学设备，请勿自行拆卸 ! 光照强度高，请勿直视出光口 ! 二、产品概述成至 LP35 探照广播一体机，适配大疆 M350RTK 无人机。使用快拆支架固定在飞机上，通过 OSDK 接口与飞机连接。内置红蓝爆闪警示灯，有效提升警用无人机的识别度。探照灯出光角度 13°，功率 60W，在 150m 高度下，中心照度 6.3lux，探照面积 917 ㎡，拥有良好的照射效果，同时可以和云台相机联动，完美配合相机作业。喊话器声音穿透力强，一米处声压 126dB，有效扬声距离 400 米，支持实时喊话、TTS 等功能，操作方便快捷。 OSDK电气接口状态指示灯广播喇叭...
Page 6 技术参数 LP35 参数尺寸/mm L235*W220*H85 重量/g ≤550 总功率/W 96(最大值) 电气接口 DJI OSDK Bluetooth v4.2 BR&EDR 和 Bluetooth Low 蓝牙协议 Energy 蓝牙工作频段/MHz 2400‒2483.5 工作温度/°C -20~+50 警示灯模式红蓝爆闪、红灯爆闪、蓝灯爆闪警示灯可视距离 200m 喊话器声压 126dB@1m 喊话器最大功率/W 有效广播距离 400m 实时喊话录音上传广播方式音频文件播放（音频格式MP3）...
Page 7: 三、安装-拆卸教程
俯仰 -55°~+65° 云台控转动范围水平 ±35° 横滚 ±25° 常亮模式爆闪模式亮度调节探照灯功能云台角度调节自动跟随相机 AI光斑居中无人机平台支持 M350 czi Pilot （大疆经纬系列遥控器）、 DJI Pilot （大 APP支持疆经纬系列遥控器）、智声（Android）、成至助手上位机（PC）三、安装-拆卸教程 1、在DJI经纬M350无人机上安装快拆支架。使用H2.0六角螺丝刀以及M3X6螺丝，将快拆支架安装在M350无人机上。...
Page 8 2、 ①安装负载：将LP35探照广播一体机，沿着快拆架滑轨，滑动至滑轨尽头，并晃动LP35底部确保安装到位。 ②把负载OSDK线接入飞机OSDK接口，等待指示灯变为绿灯慢闪说明连接成功。状态指示灯把负载的电气接口插入此接口...
Page 9: 四、 Czi Pilot App控制
3、拆卸负载：先将负载OSDK线拔出飞机OSDK接口，然后沿箭头方向转动手柄，转动至尽头，最后将LP35探照广播一体机滑出滑轨,待LP35滑出后再松开手柄。注意： LP35不支持热拔插，请先安装好全部负载，开启遥控器后，再开启飞机。四、czi Pilot App 控制 1、首先在成至智能官网下载最新 czi Pilot，将其安装在大疆遥控器上，将 LP35 负载装载在 M350 无人机上，打开无人机电源，打开遥控器中的 czi Pilot 软件进入首页，可见如下界面。...
Page 10 2、点击进入设备，进入相机画面，点击LP35控制面板按钮，可弹出如下界面，警灯控制面板控制红蓝灯的闪烁进行警示，可选择红蓝快闪、红红爆闪、蓝蓝爆闪三个模式。 1）红蓝快闪：红蓝灯按照红蓝灯先后亮的顺序快速闪烁。 2）红红爆闪：只有红灯进行快速闪烁。 3）蓝蓝爆闪：只有蓝灯进行快速闪烁。 3、探照灯控制面板控制探照灯的照明，可进行爆闪、AI 光斑居中、云台锁定、云台微调、灯光亮度调节等操作。 1）爆闪：灯光以较快的速度进行闪烁。 2）AI 光斑居中：当灯光的光斑不在遥控器屏幕图像中心时，根据算法计算，自动调整云台的角度，将光斑移动到屏幕中心。（此功能需要搭配相机，建议在光斑完整且边缘明显的情况下使用） 3）云台锁定：当云台锁定按钮按下时，探照灯不再随着相机的云台转动。（此功能需要搭配相机使用） 4）云台旋转：控制云台俯仰、偏航轴旋转以及云台一键回中 / 向下功能。 5）云台微调：云台回中后，可把云台俯仰、横滚以及偏航旋转轴调节到中立位。 6）重置云台参数：点击确认会清除云台参数，并进行校准，校准前请把负载放平，并耐心等待。...
Page 11 4、语音广播包含实时广播与录音广播功能，点击红框内按钮可切换实时广播和录音广播。实时喊话可以进行实时采集遥控器麦克风声音并且传输到负载设备播放;录音广播可以录制遥控器麦克风声音上传到负载设备播放（同时可以调节循环模式/单次模式），还可以保存在遥控器录音列表内，保存录音列表的音频可以随时点击再次播放。 5、 TTS控制面板可在文本输入框中输入想要播报的文本内容，选择相应的语言，以及相应播放的速度，点击播放， LP35会根据输入的内容以及选择的语言和速度进行语音合成，播放文本的内容。播放过的文本可以选择保存为常用，下次打开软件可以直接选择该内容进行合成播放。在遥控器联网状态下点击扫码输入，使用手机扫描二维码，在手机上输入文字，可快捷输入文字到遥控器的TTS文本框。注意：朗读人声和输入语言需对应，某些语种无法进行中英文混合播放。...
Page 12 语种能否读英文能否读英文字母广东话否否湖南话否能四川话否能东北话否能河南话否能陕西话能能普通话男否否普通话女能能...
Page 13 6、文件列表控制面板可以显示LP35中储存的音频文件，点击想要播放的音频文件可进行一键播放。拖动音量调节拖动条可调节播放的声音大小。点击播放/停止按钮可控制音频的播放和停止。点击列表循环按钮，可打开或关闭音乐循环播放。 7、设备信息展示点击左上角的图标可显示当前设备的固件版本号、激活时间及使用模式等信息。...
Page 14: 五、音频文件上传与固件升级
五、音频文件上传与固件升级 1、智声请从手机应用商店或成至官网 - 服务与支持 - 下载中心页面下载智声并安装。 ①音频上传：打开手机蓝牙开关，在智声首页点击连接设备，点击本地查看本地音频列表，选择需要的音频，点击上传按钮。...
Page 15 ②智声上传音频需要在 czi pilot 里实现播放。 ③升级固件：在设置里面点击设备详情跳转至设备详情界面，即可选择在线升级或者离线升级。点击更新检查即可获取最新固件（需联网），如果当前设备固件版本小于最新固件版本，则可进行在线升级。离线升级则是选择本地已有的 bin 文件（可通过成至官网下载保存至手机本地）进行升级。...
Page 16 2、电脑软件 - 成至助手 ①打开成至官网 -LP35 页面 - 下载中心，下载并安装成至助手，按照图示方法用附赠 Type-C 线连接 LP35 与电脑。等待 20s~1min （不同设备有差异）后，软件会提示负载已连接并跳转至相应操作界面。...
Page 17 ②离线升级：用户在官网下载对应负载的固件到 PC 本地，升级此指定固件。点击离线升级按钮，再选择在官网下载好的固件，点击选择固件或拖拽固件开始升级。开始将固件传输到设备。...
Page 18 传输完成后，设备会重启并开始升级。（注意：这个时候仅将固件传输到设备，升级流程仍未完成，需要等待设备自行升级并重新连接至成至助手后才可以断开 USB 连接线！）设备升级完成后会重新连接到成至助手并提示升级成功。此时可以点击设备信息按钮查看固件版本，检查是否成功升级。...
Page 19 点击”设备信息”按钮，可以查询版本，激活时间等通用设备信息。 ③音频传输查询媒体目录 : 点击”刷新目录”按钮，等待设备响应媒体目录...
Page 20 选中要删除的媒体文件，点击”删除选中”删除目标文件。...
Page 21 点击音乐传输按钮弹出待选窗口，将要上传的音频文件复制并粘贴入目标窗口以待上传。仅支持以下 mp3、ﬂac、wav、aac 四种格式，上传后保存格式为 mp3。点击开始上传，音频开始批量上传 , 等待上传完成。...
Page 23: Product Precautions
Warnings LP35 is a precision device. In case of hardware problems, please return to the manufacturer and contact the after-sales service, do not disassemble and repair by unauthorized personnel, otherwise you will lose the warranty and repair eligibility.
Page 24 OSDK Electrical interface Status indicator light Loudspeaker Searchlight Red and blue ﬂashing lights Quick release slide rail Reset button...
Page 25 Speciﬁcation LP35 Parameters L235*W220*H85 Dimensions / mm Weight / g ≤550 Total power / w 96 （ Max） Electrical interface DJI OSDK Bluetooth v4.2 BR&EDR and Bluetooth Low Bluetooth Protocol Energy Bluetooth operating frequency band / MHz 2400‒2483.5 Operating temperature / ℃...
Page 26: Installation - Disassembly Tutorial
Automatically following camera AI spot centered Drone platform support M350 czi Pilot、 DJI Pilot、 czi Audio （Android）、 APP support czi Assistant （ PC） III. Installation - Disassembly Tutorial 1. Install quick release bracket on DJI M350RTK. Install the quick release bracket on the...
Page 27 ① Installation load: Slide the LP35 Searchlight and Broadcasting System along the quick release bracket slide rail to the end of the slide rail, and shake the bottom of the LP35 to ensure installation is in place. ② Connect the load OSDK line to the OSDK interface of the drone and wait for the indicator light to turn green and slowly ﬂash, which indicates a successful connection.
Page 28: Czi Pilot App Control
LP35 to slide out before releasing your hand。 Ⅳ. czi Pilot App Control 1. Firstly, download the latest czi Pilot from the oﬃcial website of czi, install it on the DJI remote control, load the LP35 load onto the M350 drone, turn on the drone power supply, and open the czi Pilot software in the remote control to enter the homepage, and then you can see the following interface.
Page 29 2. Click to enter the device, enter the camera screen, click the LP35 control panel button, and the following interface will pop up. The alarm light control panel controls the ﬂashing of red and blue lights for warning, and three modes can be selected from: red and blue blinking, red blinking, and blue blinking.
Page 31 LP35 will be based on the input content as well as the selected language and speed of speech synthesis, playback of the text content. The played text can be selected to be saved as frequently used, and the next time you open the software, you can directly select the content for synthesis and playback.
Page 32 5. File ListControl panel displays the audio ﬁles stored in LP35, click on the audio ﬁle you want to play for one-click playback. Drag the Volume Adjustment drag bar to adjust the sound level of the playback. Click the Play/Stop button to control the audio play and stop.
Page 33 6. Device Information Display Clicking on the icon in the upper left corner, the information including the ﬁrmware version number, activation time, and usage mode of the current device can be displayed.
Page 34: Audio File Upload And Firmware Upgrade
Ⅴ. Audio File Upload and Firmware Upgrade 1. Smart Sound Please download and install SmartSound from your mobile phone application shop or from the oﬃcial website of ChengZhi - Service and Support - Download Centre page. ① Audio upload: Turn on the Bluetooth switch of your mobile phone, click Connect Device on the home page of Smart Sound, click Local to view the local audio list, select the desired audio and click Upload button.
Page 35 ②The uploaded audio needs to be played in czi pilot. ③Upgrade Firmware: Click Device Details inside Settings to jump to the device details interface, you can choose online upgrade or oﬄine upgrade. Click update check to get the latest ﬁrmware (requires internet connection), if the current device ﬁrmware version is smaller than the latest ﬁrmware version, then you can upgrade online.
Page 36 2. Computer Software - Sungji Assistant ① Open the oﬃcial website of LP35 - LP35 page - Download Centre, download and install the LP35 Assistant, and then connect the LP35 to the computer with the supplied Type-C cable as shown in the picture.
Page 37 ② Oﬄine upgrade: Users download the ﬁrmware of the corresponding load to PC locally from the oﬃcial website and upgrade this speciﬁed ﬁrmware. Click the Oﬄine Upgrade button, then select the ﬁrmware you have downloaded from the oﬃcial website, click Select Firmware or drag and drop the ﬁrmware to start the upgrade. Starts transferring ﬁrmware to the device.
Page 38 ChengZhi assistant before you can disconnect the USB cable!) When the upgrade is completed, the device will reconnect to czi Assistant and indicate that the upgrade was successful. At this time, you can click the device information button to...
Page 39 Click the "Device Information" button to check the version, activation time and other general device information. ③Audio Transmission Query Media Catalogue: Click "Refresh Catalogue" button and wait for the device to respond to the media catalogue. Click the "Refresh Catalogue" button and wait for the device to respond to the media catalogue.
Page 40 Select the media ﬁles you want to delete.
Page 41 Click the Music Transfer button to bring up the pending window, copy and paste the audio ﬁles to be uploaded into the target window for uploading. Only the following four formats of mp3, ﬂac, wav and aac are supported, and the format is saved as mp3 after uploading. Click Start Upload to start the audio batch upload, and wait for the upload to complete.
Page 44 成至技术支持 www.czi.com.cn 服务热线：400-008-8306 如您对说明书有任何疑问或者建议请通过以下电子邮箱联系我们： czzn@czi.com.cn ChengZhi Support www.czi.com.cn Service Hotline: 400-008-8306 If you have any questions or suggestions regarding the manual, please contact us at: czzn@czi.com.cn Made in China...
