AG-168V SIP GATEWAY User Manual (V1.42)
AG-168V SIP GATEWAY User Manual
AG-168V SIP GATEWAY Appearance Introduction: ...................................................... 2
Features ................................................................................................................................ 2
Function Keys of AG-168V SIP GATEWAY Introduction
........................................... 3
Standard and Protocol......................................................................................................... 4
Operating requirements ...................................................................................................... 5
Electric requirements........................................................................................................... 5
Size ........................................................................................................................................ 5
Installation ............................................................................................................................. 6
Configuration......................................................................................................................... 6
GATEWAY Keypad set ........................................................................................................ 6
Configured by WEB ............................................................................................................. 7
Configured by PalmTool .................................................................................................... 23
Telnet Configuration........................................................................................................... 23
Use AG-168V Gateway ..................................................................................................... 41
Upgrade AG-168V SIP GATEWAY................................................................................ 43

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AG-168V and is the answer not in the manual?

Questions and answers

Related Manuals for PalmMicro AG-168V

Summary of Contents for PalmMicro AG-168V

  • Page 1: Table Of Contents

    AG-168V SIP GATEWAY User Manual (V1.42) AG-168V SIP GATEWAY User Manual AG-168V SIP GATEWAY Appearance Introduction: ............2 Features ..........................2 Function Keys of AG-168V SIP GATEWAY Introduction ........... 3 Standard and Protocol......................4 Operating requirements ...................... 5 Electric requirements......................5 Size ............................

  • Page 2: Features

    AG-168V SIP GATEWAY User Manual (V1.42) Gateway Front Illustration: Features...
  • Page 3 “local ip ” , refer to “GATEWAY Keypad set” chaptor set different way of internet connection, refer to “GATEWAY Keypad set” chaptor Set static ip address when in “static mode ” enable AG-168V into “setting mode ”, refer to “GATEWAY Keypad set” chaptor Hardware Main chip—pa1688PQ 50MHz Data Memory—1MB SDRAM...

  • Page 4: Standard And Protocol

    AG-168V SIP GATEWAY User Manual (V1.42) Dynamic voice jitter buffer G.168/165 compliant 16ms echo cancellation Tone generation and Local DTMF re-generation according with ITU-T E.164 dial plan and customized dial rules 100 entries for quick dial Voice prompt Hotline Standard and Protocol Gateway supports following standard and protocol: IEEE 802.3 /802.3 u 10 Base T / 100Base TX...

  • Page 5: Size

    PBX or HUB or ADSL and Cable Modem’s lan port.. Connecting to phone: Insert one side of RJ11 line to the Tel port of AG-168V , the other side to the phones’ interface. Connecting the Line’s port of...

  • Page 6: Configuration

    AG-168V SIP GATEWAY User Manual (V1.42) Configuration Two different ways can be used to configure AG-168V H323 phone: phone web browser, Telnet commands on computer. Phone Keypad setup Using the keyboard of the normal phone connecting to AG-168V FXS port and the “IP key” , which can preset and enter into “Setting mode” ,...

  • Page 7: Configured By Web

    AG-168V SIP GATEWAY User Manual (V1.42) input the ip address xxx.xxxx.xxx.xxx, press “ip ” button . Using the button of * for —, + IP Configured by WEB Double click icon to open the IE browser. Input the IP address of the GATEWAY...
  • Page 8 AG-168V IP GATEWAY is shipped from the factory with DHCP on. So, if you’re LAN or router is configured to use DHCP addressing, the IP GATEWAY’s LAN parameters will automatically be configured as soon as it is...
  • Page 9 With static ip selected in iptype drop down list, please enter IP address of backup DNS server here mac: MAC address is the physical address supplied by the Ethernet NIC. AG-168V GATEWAY is shipped from the factory with a unique algorism MAC address printed on the back of the base...
  • Page 10 AG-168V SIP GATEWAY User Manual (V1.42) Protocol Setting Fig 3.3 Protocol Setting use service: Enable/disable service by checking/clearing this box. To make calls through gatekeeper, please check this box; otherwise, GATEWAY can only make IP-to IP calls or calls through gateway...
  • Page 11 AG-168V SIP GATEWAY User Manual (V1.42) kaimenuse kaimen’s system mediaring: use mediaring’s system italkbb: use italkbb’s system stanaphone: use stanaphone’s system net2phone: use net2phone’s system fwd: use fwd(freeworlddialup) system ipphonex: use ipphonex’s system sipphone: use siphone’s system ngtel: use ngtel’s system ayctel: use AycTe’s system...
  • Page 12 AG-168V SIP GATEWAY User Manual (V1.42) every “nat ttl” seconds to keep the port mapping on the NAT device alive. “nat ttl” is an integer between 10 and 65535 .default value is 20. phone number: set local ID account: set aaa@bbb format account register...
  • Page 13 AG-168V SIP GATEWAY User Manual (V1.42) recommended way with SIP protocol used dtmf : Set DTMF signal sending way by selecting control string, inband audio, signal keypad or rfc 2833 ,sip infofrom list box dtmf payload: set use RTP send DTMF’s RTPthe value range is 96-101...
  • Page 14 AG-168V SIP GATEWAY User Manual (V1.42) phone Fig 3.4 Setting use dialplan: Set whether use dial plan or use dial number by selecting the corresponding item in drop down list. disable: Do not use dial plan or dial number by selecting this item.
  • Page 15 AG-168V SIP GATEWAY User Manual (V1.42) ddd prefix: With enable or dialnum selected in use dialplan drop down list, set long distance call prefix according to E.164 dial rule, such as 0. inner line: Enable/disable innerline call by selecting corresponding items from dropdown list.
  • Page 16 Dual mode set AG-168V FXS PSTN port disable AG-168V FXS Not user PSTN PSTN first set AG-168V FXS first user PSTN call IP first set AG-168V FXS first user ip call dual mode prefix set dual mode prefix IP firstset PSTN prefix Audio settings: Fig 3.5 Audio Setting...
  • Page 17 AG-168V SIP GATEWAY User Manual (V1.42) g729g7231g711ug711a and gsm. codec3: Set the priority 3of the audio compression algorithm. The options are g729g7231g711ug711a and gsm codec4: Set the priority 4of the audio compression algorithm. The options are g729g7231g711ug711a and gsm. codec5: Set the priority 5of the audio compression algorithm.
  • Page 18 AG-168V SIP GATEWAY User Manual (V1.42) Phonenumber: check phonenumber auto upgrade. upgrade addr: Put IP address or domain name obtained by ISP of FTP server supplying upgrade program into this field. nts ip: Fill IP address of time server here.

  • Page 19: Configured By Palmtool

    AG-168V SIP GATEWAY User Manual (V1.42) button to confirm the modification. phone Book: Click this button to open the speed dial settings page. Please refer to Fig 3.7. In this page, you can set and save the speed dial number by typing the name into the Name field and then entering the corresponding number following the name.

  • Page 20: Telnet Configuration

    If you type super password, then you will see: Password : ******** P:\> Above information indicates that IP GATEWAY is under setting mode, and then you can set the AG-168V IP GATEWAY by using the telnet commands. AG-168V Telnet Commands Explanation AG-168V Telnet Commands Comman...
  • Page 21 AG-168V SIP GATEWAY User Manual (V1.42) Display basic parameters of the AG-168V IP GATEWAY Set parameters of the AG-168V IP GATEWAY store Save current settings to designated position load Load designated settings to current position exit Exit from the setting mode without saving the configuration...
  • Page 22 Relevant usage: None Detailed description: Display basic running parameters of the AG-168V IP GATEWAY. Input ordinary password without debug being set as 0[disable], or input super password with debug set as 0[disable], then following parameters of IP GATEWAY will be displayed: AG-168V V1.39 settings...
  • Page 23 0[disable] timezone 55[(GMT+08:00)Beijing,Hong Kong,Urumqi] Command Syntax description: set keywords value Usage: Used to configure password and other running parameters of AG-168V IP GATEWAY Detailed description: set iptype X Set how IP GATEWAY gets relevant network parameters. X ranged from 0...
  • Page 24 With iptype set as 2, use this command to set ADSL pin; with iptype set as 3, use this command to set Modem pin. set ip XXX.XXX.XXX.XXX With iptype set as 0, use this command to set IP address of AG-168V IP GATEWAY. set subnetmask XXX.XXX.XXX.XXX...
  • Page 25 AG-168V SIP GATEWAY User Manual (V1.42) With iptype set as 0, use this command to set subnet mask of AG-168V IP GATEWAY. set router XXX.XXX.XXX.XXX With iptype set as 0, use this command to set router IP of network with AG-168V IP GATEWAY.
  • Page 26 AG-168V SIP GATEWAY User Manual (V1.42) 17: use Lucent system; 19: use IPN system; 20: use yayuang system; 21: use thinker system; 22: use suntek system; 28: use txtc system. set serviceaddr XXXX Set IP address or domain name of gatekeeper...
  • Page 27 Set NAT TTL XX is an integer between 10 and 65535 sec. default value is 20 sec. set GATEWAYnumber XXXXXXXX Set a GATEWAY number of AG-168V IP GATEWAY . Value xxxxx must be an Arabic numeral and no longer than 16 characters. set account XXXXXX While calling card is set, set account of chosen card;...
  • Page 28 AG-168V SIP GATEWAY User Manual (V1.42) set registerttl X Set register TTL. X is range from 10 through 65535 Sec. default value is 60 Sec. set rtptos X Set TOS segment of IP head package in RTP digital follow. set rtpport XXXX RTP port is the port transferring and receiving voice flow using UDP protocol.
  • Page 29 AG-168V SIP GATEWAY User Manual (V1.42) Set DTMF relay type. X is ranged form 0 through 3: 0:control string1:inband audio2: signal keypad3:rfc 2833. set dtmf payload X When dtmf X select 3(rfc 2833).This parameter can be used indicating type of RTP payload type. The value can be use integer 96-101.
  • Page 30 AG-168V SIP GATEWAY User Manual (V1.42) set iddprefix XX Set IDD service prefix number when set dialplan value set as 1 or 2. For example, IDD service prefix number of china is 00; IDD service prefix number of USA is 1, etc. Parameter xxx must be an Arabic numeral and no longer than 3 characters.
  • Page 31 AG-168V SIP GATEWAY User Manual (V1.42) Set types of ring. X is ranged from 0 tohrough 12: 0-9: ring as ordinary rings in different frequency; 10: do not ring; 11: ring as music shipped from factory; 12: ring as music saved by user set digitmap X Set whether to use digitmap.
  • Page 32 Set audio frames in RTP package. X is Arabic numerals between 0 and 7. With G.7231, set AG-168V IP GATEWAY to use 6.3K rate or not. X is ranged from 0 through 1: 0: use 6.3K rate; 1: use 5.3K rate.
  • Page 33 AG-168V IP GATEWAY. XXX must be ASCII characters. set superpassword XXXX Set super password of the AG-168V IP GATEWAY. XXX must be ASCII characters. set debug X Set open debugging message output grade for special tool. X is ranged from 0 through 5: 0: close debugging output;...
  • Page 34 AG-168V SIP GATEWAY User Manual (V1.42) set upgradeaddr XXX.XXX.XXX.XXX Set IP address or domain name of FTP server supplying upgraded program of AG-168V IP GATEWAY. set ntsip XXX.XXX.XXX.XXX Set IP address of time server. set daylight X Set use daylight or not. X ranged from 0 through 1: 0: do not use daylight; 1: use daylight.
  • Page 35 AG-168V SIP GATEWAY User Manual (V1.42) Syntax description: No keyword and parameter Usage: Save the configuration and restart the AG-168V IP GATEWAY. Command ping Syntax description: ping IP address Usage: ping IP address of other NAT device Relevant usage: In telnet window, input ping xx.xxx.xx.xxan IP address and return, then the result will be displayed.
  • Page 36 The usage of AG-168V FXS Receving calls No matter what calls from IP or PSTN , the phone connecting to AG-168V FXS port will ring . Mention you that there is call. You can pick up the handset or the speaker of the normal phone.
  • Page 37 Predial the prefix number in the “dual mode prefix”, AG-168V will change to PSTN line, call after the dial tone. Emergency Call When AG-168V is power off or in falure, the Normal phone would connect with the PSTN LINE, work as the “LIFELINE” and call emergency number.

  • Page 38: Upgrade Ag-168V Sip Gateway

    Upgrade AG-168V IP GATEWAY Telnet command to updating Using telnet , connecting AG-168V FXS, input SuperPassword when registered. Input ftp X command to update, the value range is 0-2 . detailed meaning is : x-0 connecting to FTP server, getting the file to updating , and save in the sdram of the phone.
  • Page 39 AG-168V SIP GATEWAY User Manual (V1.42) logins. 2. The service provider needs to upload these files to the FTP server: HardwareTag_ServiceType_Protocol_XXX.bin This file contains the phone’s firmware binary HardwareTag_ServiceType_Protocol_cfgXXX.dat This file contains the phone’s configuration settings HardwareTag_ServiceType_Protocol_mapXXX.txt This file contains the phone’s digit map configuration In the files above HardwareTag is phone’s hardware type, and is identical to the...
  • Page 40 AG-168V SIP GATEWAY User Manual (V1.42) parameter is "disable", "all", "mac", "pppid", "account", "phonenumber". When select as "disable" the terminal will NOT do the auto upgrade when select as "all" then the terminal will do the upgrade as item 2 when select as other value it will add more check based on item 2’s rule.
  • Page 41 AG-168V SIP GATEWAY User Manual (V1.42) and there are no new features of use to them in our 1.35 and 1.36 versions, then they don’t need to put these files on FTP server. The customers will continue to use version 1.34.
