drew & jonathan P392DJ261 Manual

Wood back arm chair

Advertisement

Quick Links

A
x1 Back Frame
x1 Cadre arrière
x1 Marco trasero
G
*
x4 Allen bolt Ø5/16xL75mm
x4 Vis à tête creuse hexagonale Ø5/16"x75mm
x4 Perno Allen Ø5/16"x75mm
L
*
x2 Allen bolt Ø1/4xL32mm
x2 Vis à tête creuse hexagonale Ø1/4"x32mm
x2 Perno Allen Ø1/4"x32mm
Page 1 of 3
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
PRODUCT NUMBER(S): P392DJ261
B
*
x1 Left Arm Rest
x1 Seat Frame
x1 Cadre de siège
x1 Repose-bras gauche
x1 Reposabrazos izquierdo
x1 Estructura del asiento
H
*
x1 Allen bolt Ø5/16xL50mm
x1 Vis à tête creuse hexagonale Ø5/16"x50mm
x1 Perno Allen Ø5/16"x50mm
M
*
x2 Lock washer Ø1/4"
x2 Flat Washer Ø1/4"
x2 Rondelle de blocage Ø1/4"
x2 Rondelle plate Ø1/4"
x2 Arandela de Seguridad Ø1/4"
x2 Arandela plana Ø1/4"
C
D
*
x1 Right Arm Rest
x1 Repose-bras droit
x1 Reposabrazos derecho
I
*
x2 Allen bolt Ø5/16xL38mm
x2 Vis à tête creuse hexagonale Ø5/16"x38mm
x2 Perno Allen Ø5/16"x38mm
N
O
*
x4 Hex nut Ø5/16"
x4 Écrou hexagonal Ø5/16"
x4 Tuerca hexagona Ø5/16"
Assembly Instructions-Instructions d'assemblage-Instrucciones para el ensamblaje
Made in VietNam / Fabrique en VietNam / Hecho en VietNam.
E
*
*
x1 Left Front Leg
x1 Jambe avant gauche
x1 Jambe avant gauche
J
*
x11 Lock washer Ø5/16"
x11 Rondelle de blocage Ø5/16"
x11 Arandela de Seguridad Ø5/16"
P
*
*
x1 Allen Key 4mm
x1 Clé hexagonale 4mm
x1 Llave Allen 4mm
*
Replaceable part
F
*
x1 Right Front Leg
x1 Jambe avant droite
x1 Pata delantera derech
K
*
x11 Flat Washer Ø5/16"
x11 Rondelle plate Ø5/16"
x11 Arandela plana Ø5/16"
Q
*
x1 Open Wrench Ø5/16"
x1 Clé à fourche Ø5/16"
x1 Llave de boca Ø5/16"
