drew & jonathan P392DJ230 Manual

Round table base

Advertisement

Quick Links

A
x1 Round Table Top
x1 Dessus de table ronde
x1 Tablero de mesa redonda
D
x4 Allen bolt Ø5/16xL38mm
x4 Vis à tête creuse hexagonale Ø5/16"x38mm
x4 Perno Allen Ø5/16"x38mm
Page 1 of 3
PARTS LIST/ LISTE DES PIÈCES/ LISTA DE PIEZAS
PRODUCT NUMBER(S): P392DJ230
*
x4 Lock washer Ø5/16"
x4 Rondelle de blocage Ø5/16"
x4 Arandela de Seguridad Ø5/16"
P392DJ231
B
x1 Round Table Base
x1 Base de table ronde
x1 Basa de mesa redonda
E
*
x4 Flat Washer Ø5/16"
x4 Rondelle plate Ø5/16"
x4 Arandela plana Ø5/16"
Assembly Instructions-Instructions d'assemblage-Instrucciones para el ensamblaje
Made in VietNam / Fabrique en VietNam / Hecho en VietNam.
C
x1 Mount Plate
x1 Plaque de montage
x1 Placa de montaje
F
*
x1 Allen Key 5mm
x1 Clé hexagonale 5mm
x1 Llave Allen 5mm
*
Replaceable part
G
*

Advertisement

loading
Need help?

Need help?

Do you have a question about the P392DJ230 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for drew & jonathan P392DJ230

  • Page 1 PARTS LIST/ LISTE DES PIÈCES/ LISTA DE PIEZAS PRODUCT NUMBER(S): P392DJ230 P392DJ231 x1 Mount Plate x1 Round Table Top x1 Round Table Base x1 Plaque de montage x1 Dessus de table ronde x1 Base de table ronde x1 Placa de montaje...
  • Page 2 ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE PRODUCT NUMBER(S): P392DJ230 P392DJ231 STEP 1 STEP 2 ÉTAPE 1 ÉTAPE 2 PASO 1 PASO 2 Note: Save the mount plate and the bolts after removing for assembly in step 2 and step 3.
  • Page 3 REPLACEABLE PART / PARTIE REMPLAÇABLE / PARTE REEMPLAZABLE PRODUCT NUMBER(S): P392DJ230 P392DJ231 x8 RP392DJ100-LEVE- Brown Leveler x1 RP392DJ230-HWKIT- Hardware kit list - Liste des pièces de quincaillerie - Niveleur - Lista del kit de materiales - Nivelador Replaceable part Assembly Instructions-Instructions d’assemblage-Instrucciones para el ensamblaje Page 3 of 3 Made in VietNam / Fabrique en VietNam / Hecho en VietNam.

This manual is also suitable for:

P392dj231
