A
x1 Side Table
x1 Table D'appoint
x1 Mesa Auxiliar
D
x2 Table Base
x2 Base de table
x2 Base de mesa
G
x24 Lock washer Ø5/16"
x24 Rondelle de blocage Ø5/16"
x24 Arandela de Seguridad Ø5/16"
Page 1 of 3
PARTS LIST/ LISTE DES PIÈCES/ LISTA DE PIEZAS
PRODUCT NUMBER(S): P392DJ240
x1 Middle Table
x1 Table du milieu
x1 Mesa Media
E
x12 Allen bolt Ø5/16xL22mm
x12 Vis à tête creuse hexagonale Ø5/16"xL22mm
x12 Perno Allen Ø5/16"x22mm
*
x24 Flat Washer Ø5/16"
x24 Rondelle plate Ø5/16"
x24 Arandela plana Ø5/16"
P392DJ241
B
*
x12 Allen bolt Ø5/16xL38mm
x12 Vis à tête creuse hexagonale Ø5/16"xL38mm
x12 Perno Allen Ø5/16"x38mm
H
*
Assembly Instructions-Instructions d'assemblage-Instrucciones para el ensamblaje
Made in VietNam / Fabrique en VietNam / Hecho en VietNam.
C
x2 Mount Plate
x2 Plaque de montage
x2 Placa de montaje
F
I
*
x1 Allen Key 5mm
x1 Clé hexagonale 5mm
x1 Llave Allen 5mm
*
Replaceable part
*
