Summary of Contents for PowerFlex PF-96D-LTE
- Page 1 Electric Vehicle AC Charger Installation Instructions 客制说明书 技术要求： 线条图提供者 设计者 1.成品规格： mm； 2.印刷方式： 单面印刷 ； 双面印刷； 3.装订方式： 骑马钉； 单面对折； EVCD1 排版者 审核者 4.材质： 70g双胶纸； 108g铜板纸； 庄妍妍 2024.5 5.印刷颜色： 色； 单黑 6.有条码的话，刷码等级需达到B级； 批准者 文件翻译者 7.检验工具：卷尺，尺寸单位均为mm 替换高清图，内容不变 版本号 修订原因 修订人 修订日期 签名 日期...
- Page 2 Electric Vehicle AC Charger Installation Instructions...
-
Page 3: Table Of Contents
USER MANUAL USER MANUAL TABLE OF CONTENTS 1. IMPORTANT SAFETY INSTRUCTIONS ........1 2. PRODUCT INTRODUCTIONS............5 3. VERIFY CONTENTS..............7 4. GATHER TOOLS ................9 5. WIRE THE CIRCUIT ..............10 6. PLAN THE MOUNTING ............14 7. MOUNT THE CHARGING STATION ........15 8. OPERATE YOUR DEVICE............17 9. -
Page 4: Important Safety Instructions
USER MANUAL USER MANUAL WARNING & CAUTION WARNING & CAUTION 1. Important Safety Instructions 1.2 Installation Requirements 1.1 Overall Warnings & Cautions WARNING : Disconnect electrical power prior to installing the charging station. WARNING : To avoid fire, injury or death, carefully read and follow the instructions during WARNING: Be sure to preview the user manual and ensure local building and electrical codes are installation, operation and maintenance. -
Page 5: Consignes De Sécurité Importantes
USER MANUAL USER MANUAL WARNING & CAUTION WARNING & CAUTION 1. Consignes De Sécurité Importantes 1.2 Exigence Avant L’installation 1.1 Avertissement & Mise En Garde Généraux AVERTISSEMENT : Assurez-vous de consulter le manuel d'utilisation et assurez-vous que les AVERTISSEMENT : Pour éviter les risques d’incendie, de blessure ou de mort, il faut lire et suivre codes locaux du bâtiment et de l'électricité... -
Page 6: Product Introductions
USER MANUAL 2. Product Introductions 2.3 Specifications CAUTION: Avoid placing the charger near hot objects and at high temperature locations PF-96D-LTE Model Number and away from dangerous substances such as flammable gases and corrosive materials. Rated Input Voltage 208 / 240 VAC... -
Page 7: Verify Contents
USER MANUAL USER MANUAL 3. Verify Contents Product Name Quantity Description Check the box to ensure you have this installation guide and these parts: AC Charger Two Charging Cable User Manual Please read carefully before use Electric Vehicle AC Charger Installation Instructions For mounting the charging station to Wall-Mounted Bracket... -
Page 8: Gather Tools
USER MANUAL USER MANUAL 5. Wire The Circuit 4. Gather Tools WARNING: This device must be grounded. Disconnect electrical power prior to installing Tools required before installing the Wall-Mounted charger, gather the following tools: the charging station. 1. Wire stripper 2. - Page 9 USER MANUAL USER MANUAL Method 1: Two AC Power Cord Method 2: One AC Power Cord Circuit Breaker Options table Circuit Breaker Options table Output Amperage (A) Output Amperage (A) 32A*2 40A*2 48A*2 32A*2 40A*2 48A*2 40A*2 50A*2 60A*2 100A 120A Circuit Breaker Options (A) Circuit Breaker Options (A)
-
Page 10: Plan The Mounting
USER MANUAL USER MANUAL 6. Plan The Mounting STEP 4 Connect to 3 terminals according to the following wiring methods WARNING: In areas with frequent thunderstorms, add surge protection at the service panel image: L1 is connected to L1, L2 is connected to L2, and PE is connected to PE. for all circuits. -
Page 11: Mount The Charging Station
USER MANUAL USER MANUAL 7. Mount the Charging Station STEP 1 STEP 4 (Holster is optional) STEP 5 (Holster is optional) Use 4 sets Hexagonal Expansion Screws to secure the wall-mounted bracket on the wall.Then level Install the Holster as shown in the figure Tighten one M5 anti-theft screws to the brackets. -
Page 12: Operate Your Device
USER MANUAL USER MANUAL 8. Operate Your Device STEP 2 Plug the Charging Connector: WARNING: This device should be supervised when used around children. Please plug the charging connector into the vehicle charging inlet. CAUTION: Please use the charger properly. Do not hit or press hard on the enclosure. If the case is damaged, please contact a professional technician. - Page 13 USER MANUAL USER MANUAL STEP 3 Swipe the RFID Card: 8.2 Operating Steps with RFID (Optional) Swipe the RFID card first and plug in the charging CAUTION: Please keep your RFID card properly to avoid unnecessary loss. connector within 120 seconds, otherwise you need to swipe the RFID card again.
-
Page 14: Light Codes
USER MANUAL USER MANUAL 9. Light Codes 10. FCC Declaration 9.1 After Start UP (e.g.AC1) This device complies with part 15 of the FCC Rules. Waiting to Operation is subject to the following two conditions: Standby, charge, Charging in Finished waiting to plug Fault communicating... -
Page 15: Warranty And Maintenance
USER MANUAL USER MANUAL 11. Warranty and Maintenance • The warranty period for this charger is three years. • During the warranty period for any malfunction under normal use according to the User Manual (to be determined by certified maintenance technicians of sellers), the product shall be repaired free of charge.
