INSTALLATION GUIDE
MODEL NUMBER: 17058
TRUCK MODEL: 2007+ PETERBILT 365/367/388/389
IMPORTANT INFORMATION
- THIS GUIDE IS ONLY APPLICABLE TO PRODUCTS AND TRUCK MODELS SPECIFIED.
- THE CORRECT SIZE AND GRADE OF HARDWARE SPECIFIED IN THIS GUIDE MUST BE USED.
- CHECK ALL MOUNTING POINTS AFTER THE FIRST 5000KM'S IN SERVICE AND PERIODICALLY THERE AFTER.
RE-TORQUE IF NECESSARY.
- RECOMMENDED ADDING THREADLOCKER (LOCTITE BLUE 242) TO ALL THREADS BEFORE INSTALLING.
- ALL MAGNUM PRODUCTS MUST BE INSTALLED ACCORDING TO THIS INSTALLATION GUIDE. ANY
DEVIATIONS MAY RESULT IN VOID OF WARRANTY.
- ANY ALTERATIONS TO THE PRODUCT MAY RESULT IN VOID OF WARRANTY.
SAFETY INFORMATION
- PROPER PERSONAL PROTECTIVE EQUIPMENT MUST BE WORN WHEN INSTALLING THIS PRODUCT.
- SOME PARTS OF THIS PRODUCT MAY BE HEAVY OR AWKWARD TO HANDLE. USE CAUTION WHEN
HANDLING.
MODEL NUMBER: 17058
DATE: 4/18/2024
REVISION: A
1
1-800-661-3406
www.magnumtrailer.com
Advertisement
Related Manuals for Magnum 17058
Summary of Contents for Magnum 17058
- Page 1 RE-TORQUE IF NECESSARY. - RECOMMENDED ADDING THREADLOCKER (LOCTITE BLUE 242) TO ALL THREADS BEFORE INSTALLING. - ALL MAGNUM PRODUCTS MUST BE INSTALLED ACCORDING TO THIS INSTALLATION GUIDE. ANY DEVIATIONS MAY RESULT IN VOID OF WARRANTY. - ANY ALTERATIONS TO THE PRODUCT MAY RESULT IN VOID OF WARRANTY.
- Page 2 17058 MOOSE BUMPER 42818 *SEE NEXT PAGE FOR LIST OF PARTS INCLUDED* 90373 94006 95023 95003 16257 ∆58148 95023 DETAIL D SCALE 1 : 4 94026 DETAIL C SCALE 1 : 4 MODEL NUMBER: 17058 DATE: 4/18/2024 1-800-661-3406 REVISION: A...
- Page 3 STOVER NUT - PLATED GR. C 1/2" NC .032 101475 95003 FLAT WASHER - PLATED GR. 8 3/4" DIA SAE .055 102169 95023 FLAT WASHER - PLATED GR. 8 1/2" DIA SAE .024 102167 MODEL NUMBER: 17058 DATE: 4/18/2024 1-800-661-3406 REVISION: A www.magnumtrailer.com...
-
Page 4: Installation Procedure
INTO THE TOW RECEIVERS. SLIDE THE PINS FROM THE FACTORY TOW YOKES THROUGH THE TRUCK FRAME AND TOW MOUNT ASSEMBLIES. DETAIL E SCALE 1 : 8 ∆58148 PINS SLIDE THROUGH HERE MODEL NUMBER: 17058 DATE: 4/18/2024 1-800-661-3406 REVISION: A www.magnumtrailer.com... - Page 5 WITH THE HOLE ON THE INSIDE FACE OF THE STEEL ASSEMBLY (SEE NEXT SHEET FOR MORE DETAIL). 5/8" NC X 2" GR.8 HEX BOLT (NOT SUPPLIED) TYP (2) DETAIL F SCALE 1 : 6 MODEL NUMBER: 17058 DATE: 4/18/2024 1-800-661-3406 REVISION: A www.magnumtrailer.com...
- Page 6 REACH OUT TO US. 16257 IF EVERYTHING LOOKS GOOD, THE INSTALL IS COMPLETE, BUT PLEASE REMEMBER TO CHECK FOR RATTLES AND UNWANTED MOVEMENTS PERIODICALLY. THANK YOU FOR CHOOSING MAGNUM. 94026 MODEL NUMBER: 17058 MODEL NUMBER: 17058 DATE: 4/18/2024 DATE: 4/18/2024...
