Xenarc 1589GFP User Manual

15.6-inch sunlight readable touch display
Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL
1589GFP
15.6-inch Sunlight Readable Touch Display
Xenarc Technologies Corp.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1589GFP and is the answer not in the manual?

Questions and answers

Related Manuals for Xenarc 1589GFP

Summary of Contents for Xenarc 1589GFP

  • Page 1 USER MANUAL 1589GFP 15.6-inch Sunlight Readable Touch Display Xenarc Technologies Corp.
  • Page 2 Connecting 1589GFP Display with Your Device Remove the 12 screws (circled in red below image P1) and remove the input compartment cover to reveal the input compartment as show below in image P2. P1. Remove 12 Screws holding the cover P2.
  • Page 3 4. Repeat step 1 through 3 to connect the rest of the cables. (Included USB Cable is Size #4 and DC cable is Size #3 and the respective Rubber Grommets are already pre-installed in the monitor. Other sizes can be found in plastic bag that came with the monitor if you would like to use your own cabling) P5.

  • Page 4: Turning On The Display

    Turning On the Display 1. Connecting the DC power cable to DC input. Pick one of 3 pin terminal block or DC plug power input to connect your power source. * Do not connect the positive and negative poles in reverse. 2.
  • Page 5 Operation Instruction 1. Power LED Light 2. Auto/Exit 3. Menu/Enter 4. On/Off 5. Up 6. Down OSD Menu Press the MENU-button to activate the OSD window. Press Up or Down to select the navigate through the functions. Once the desired function is highlighted , press the Menu-button to activate it. If there is a sub-menu, press Up or Down to navigate through the sub-menu functions.
  • Page 6 Main Menu Sub-Menu Description Default Default=100 Adjust the Value of Backlight. Min. / Max : 0/100 Default=50 Adjust the Value of Brightness. Min. / Max : 0/100 Default=50 Adjust the Value of Contrast. Min. / Max : 0/100 Default=2 Adjust the Value of Sharpness. Min.
  • Page 7 Main Menu Sub-Menu Description Default Auto Adjust the VGA Signal. Default=50 Adjust H. Position of VGA Signal. Min. / Max : 0/100 Default=50 Adjust V. Position of VGA Signal. Min. / Max : 0/100 Default=50 Adjust Clock of VGA Signal. Min.
  • Page 8 Main Menu Sub-Menu Description Default Select DDCCI (On/Off) Default=On Exit the Sub-menu Exit Main Menu Sub-Menu Description Default Select VGA Input Select DP Input Auto Select Select HDMI Input Main Menu Sub-Menu Description Default Default=50 Adjust the Value of Volume. Min.
  • Page 9 Main Menu Sub-Menu Description Default Return to Factory Default Default=10 Adjust OSD Menu Time. Min. / Max : 10/60 Default=50 Adjust OSD V. Position. Min. / Max : 0/100 Default=50 Adjust OSD H. Position. Min. / Max : 0/100 Select OSD Language : English、Deutsh、...

  • Page 10: Specifications

    Specifications SPECIFICATIONS Size/Panel Type 15.6” TT FLCD Panel Display Resolution 1920x1080 Brightness (cd/m²) 1000cd/m² Contrast Ratio 1000:1 Response Time 25ms Backlight LED Backlight Unit Colors 16.7M Colors Viewing Angle (H/V) 178°/178° Touch Screen Type PCAP 10 points Touchscreen, AG/AR/Anti-UV Touch Screen Surface Hardness Operating Temperature -30°C~+85˚C...

  • Page 11: Product Appearance

    Product Appearance Light Sensor IR Receiver Brightness Control *Brightness Control can only work while Light Sensor is disabled.
  • Page 12 Display Drawing...
