- Page 1 7 0 0 T S U I N S TA L L AT I O N M A N U A L...
-
Page 2: Table Of Contents
Table of Contents Features..............03 Specifications............04 Quick-Start..............05 Remote Control............07 Hardware Installation..........10 Software Installation..........14 Touch Screen Driver Installation Additional Info............22 Owner’s Record............23... -
Page 3: Features
Features Input Signals USB input: 1 channel VIDEO (RCA) input: 2 channels AUDIO (RCA) input: 2 channels Features o Connect computer video signal with a simple USB cable o Capable of connect six USB Monitor simultaneously o 5 wires for the touch panel o 2 audio input o NTSC/PAL o 16:9/ 4:3... -
Page 4: Specifications
Specification Specification Last input memory USB2.0 Last power setting memory Auto display adjustment Mirror image flip VESA 50mm mounting holes 26 pin heavy-duty connector with connector locking Supports 10V DC~ 35V DC E-Mark certified for automotive use Display Specifications Screen Size: Diagonal 7" (16:9) Physical Resolution: 800(H) x 480(V) Pixel Pitch: 0.0025(H) x 0.0075(V) (in) Dot Resolution: 2400 x 480=1.152.000 (dots) -
Page 5: Quick-Start
Quick Start Attach the 26-Pin connector at the back of the monitor Attach the USB plug to the computer's USB receptacle connector. Plug in the second USB cable is optional. It is included as backup power source Attach your “video source 1” (e.g. VCR, Video Game Console) to the Yellow RCA connector marked Video1 Attach your “Video Source2”... - Page 6 Quick-Start Install the Touch screen driver from the included CD disk Please follow the installation on page 14 Slide Monitor into optional mounting stand Secure Height position by adjusting knob Secure Tilt position by adjusting knob Insert the power adapter as shown. (Optional) Monitor is powered by USB port.
-
Page 7: Remote Control
Remote Control POWER MIRROR DIMMER MUTE DISPLAY SLEEP PICTURE PC AUTO MENU SOURCE VOL- VOL+ 01. Power Button: Turn the monitor ON or OFF. 02. Mirror Button: Enable or Disable the mirroring of the display. Continue to press it and choose the mirroring you want. - Page 8 Remote Control Instructions for remote controller shortcuts 1. Dimmer (adjust the brightness) By pressing the Dimmer button, it will adjust the brightness level from 0, 20, 40, 60, 80 and 100. Default is 100 (Only available when auto sensor is disabled) 2.
- Page 9 Remote Control 6. MIRROR (image mirror) Enable or Disable the mirroring of the display. Continue to press it and choose the mirroring mode you wish to display Select button to go 7. Mute Mute the speaker. Press again to restore the voice of speaker 8.
-
Page 10: Hardware Installation
Hardware Installation Buttons description: Power button: press to turn on or off the monitor Select button: Press to select the input signal to display. Press or right ( ) to highlight the input source desired and then press to make the selection. Menu button: Press the button to show the OSD menu. - Page 11 Hardware Installation 1. COLOR Brightness: Adjust brightness by pressing Left or Right buttons. Press left to decrease brightness, and press Right to increase the level of brightness. Contrast: Adjust contrast by pressing Left or Right buttons. Press left to decrease contrast and Right to increase the level of contrast Sharpness: Adjust sharpness by pressing Left or Right buttons.
- Page 12 Hardware Installation 3. OSD H Position: Adjust the OSD Horizontal position by pressing the left or right buttons. V Position: Adjust the OSD Vertical position by pressing the left or right buttons. OSD Timeout: Adjust the time out of the OSD Transparent: Adjust the transparency of the OSD screen image 4.
- Page 13 Hardware Installation 5. FUNCTION Reset: Reset to Factory default setting. Display Ratio: Select the display mode to 16:9, 4:3 and Auto Sleep: Select the time to automatically turn off the monitor. The minimum is 15 minutes and the maximum is 120 minutes. Keypad: The function allows you to disable or enable the buttons at the front of the monitor.
-
Page 14: Software Installation
Software Installation Installing Driver for DisplayLink Graphic Adaptor 700TSU has build in driver for DisplayLink graphic adaptor. Your system should auto run the installation wizard when the monitor is plugged in. If you are experiencing trouble with the installation, please refer to the "DisplayLink Graphics Adapter User Manual"... - Page 15 Software Installation Press Next button to continue installation, then, a new dialog popped up as below, This dialog shows to ask user if the PS2 filter driver for touch screen to be installed. User can check this check for PS2 filter driver installation. The standard PS2 mice can still work well after this filter driver installed because eGalaxTouch PS2 filter driver can work with both standard PS2 mice and PS2 touchscreen.
- Page 16 Software Installation This dialog shows to ask user if the RS-232 driver for touch screen to be installed. User can check this check for RS-232 driver installation. After check or uncheck this check box, press Next button to continue installation. Then, it shows new dialog as below, Also, eGalaxTouch software provides user with a fast 4 points calibration.
- Page 17 Software Installation user to make sure that the eGalaxTouch USB controller devices were well connected with system USB ports to guarantee the USB eGalaxTouch device drivers updated after driver installation. Then, just press OK to continue, eGalaxTouch driver package supports multiple monitor operation. If your application is for multiple monitors system, please check the check box to support multiple monitors.
- Page 18 Software Installation A pop up window for user to choose the target path the files will be copied to. Then, Press Next to continue, A dialog popped up for user to assign the target program folder. Press Next...
- Page 19 Software Installation If install RS-232 driver check box was checked, the setup program will scan system COM ports. The setup program will scan system COM ports to detect if any eGalaxTouch serial device was connected. If yes, it also pops up a message box for user to make sure if setup program install driver for this new found device.
- Page 20 Software Installation Finally, if PS2 filter driver was installed during this software installation, a reboot dialog is popped up for system reboot request to complete driver installation...
- Page 21 Software Installation After driver installation, a shortcut will be generated and shown on the desktop. And, a new file group generated for eGalaxTouch as below, Your Touch screen is ready to use now You can click on the icon Touchkit located on your desktop to launch the Touch screen program for various settings and adjustments.
-
Page 22: Additional Info
Touch Screen device driver must be installed onto your computer in order for the Touch Screen to become functional. Xenarc Technologies uses Resistive Touch Screen panels in the 700TSU monitor. Touch Screen drivers and software for different operating systems can be found in the included CD-ROM disc. You can refer to this manual for a walkthrough of Touch Screen Driver installation under Microsoft Windows XP. -
Page 23: Owner's Record
Owner’s Records Owner’s Records The model and serial numbers are located on the rear of the unit. Please record these numbers in the spaces provided below, as well as the dealer name, address, and telephone number. Please refer to these records whenever speaking to your dealer regarding this product.
