- Page 1 Operating and installation instructions Ventilation hood To prevent accidents and damage to the appliance, you must read these instructions before installing the appliance and using it for the first time. en-US M.-Nr. 12 800 600...
-
Page 2: Table Of Contents
Contents IMPORTANT SAFETY INSTRUCTIONS..............Caring for the environment ..................10 Description of functions ....................11 Guide to the ventilation hood..................12 Operation ........................14 Turning on the blower ....................14 Selecting the power level ....................14 Delayed shut-down......................14 Turning off the blower ....................14 Turning the overhead lighting on/off................ -
Page 3: Appropriate Use
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS This appliance complies with current safety requirements. Improper use of the appliance can lead to personal injury and material damage. Read all instructions before installing or using the appliance for the first time. Only use the appliance for its intended purpose. Keep these operating instructions in a safe place and pass them on to any future user. -
Page 4: Safety With Children
Unauthorized installation, maintenance, and repairs can cause considerable danger for the user. Installation, maintenance, and repairs must only be carried out by a Miele authorized technician. A damaged ventilation hood can be dangerous. Always check for visible signs of damage. Never use a damaged ventilation hood. - Page 5 The function and operation of the protective measures provided in the domestic electrical installation and in this Miele product must also be maintained in isolated operation or in operation that is not synchronized with the grid power supply, or these measures must be replaced by equivalent measures in the installation.
-
Page 6: Correct Use
IMPORTANT SAFETY INSTRUCTIONS Correct use WARNING: TO REDUCE THE RISK OF A COOKTOP GREASE FIRE: - a) Never leave surface units unattended. Boilovers cause smoking and greasy spillovers may ignite. Heat oils slowly on low or medium settings. - b) Always turn the hood on when cooking at a high heat. - c) Clean the ventilation hood frequently. - Page 7 IMPORTANT SAFETY INSTRUCTIONS The ventilation hood may become damaged if exposed to excessive heat from a gas cooktop. - When using the ventilation hood over a gas cooktop, ensure that any burners in use are always covered by cookware. Turn burners off when removing the cookware, even if doing so for just a short time.
-
Page 8: Proper Installation
IMPORTANT SAFETY INSTRUCTIONS Proper installation WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: - a) Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. -
Page 9: Cleaning And Maintenance
The steam can reach the electrical components and cause a short circuit. Accessories and parts Use only genuine original Miele parts. If parts or accessories from other manufacturers are used, the warranty may become void. Defective components should be replaced by Miele original parts ... -
Page 10: Caring For The Environment
Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. -
Page 11: Extraction Mode
Description of functions The following functions are available on Recirculation mode your ventilation hood, depending on the The recirculation mode requires a model: recirculation kit and OdorFree Charcoal Filter (available as optional accessories, Extraction mode see “Technical Data” for more information) The air is drawn in and cleaned by the grease filters and directed outside. -
Page 12: Guide To The Ventilation Hood
Guide to the ventilation hood... - Page 13 Guide to the ventilation hood a Telescopic extension piece b Duct cover c Canopy d Controls e Grease filter f Recirculation vents Only for recirculation mode g Overhead lighting h Charcoal filters Optional accessories for recirculation mode i Control for switching the blower on and off j Controls for setting the blower power k Button for switching the lighting on and off...
-
Page 14: Operation
Operation Turning on the blower Turning off the blower Switch the blower on as soon as you Press the On/Off control to turn start cooking. This is to ensure that the blower off. vapors are captured right from the start. The ... -
Page 15: Turning Power Management On/Off
Operation Turning power management on/off Safety shut-off You can deactivate power management. If power management has been Keep in mind that this may increase deactivated, the ventilation hood will energy consumption. switch itself off automatically after 12 hours if it has been left on (blower ... -
Page 16: Energy-Saving Tips
Energy-saving tips This hood operates in a very efficient and energy-saving manner. The following will help you to save even more energy when using it: - Ensure that there is sufficient ventilation in the kitchen when cooking. If there is insufficient air flow during extraction mode, the hood cannot operate efficiently, causing increased operating noise levels. -
Page 17: Cleaning And Care
Unsuitable cleaning agents can treating them with a stainless steel care damage the surfaces and control product (available from Miele). elements. Important information for the controls Do not use any cleaning agents containing soda, acid, chloride, or If soiling is not removed promptly, it solvent. - Page 18 Cleaning and care Unsuitable cleaning agents Heavily soiled grease filters hinder air extraction and will lead to increased Unsuitable cleaners can cause damage levels of soiling in the ventilation hood to the filter surfaces if used regularly. and in the kitchen. Do not use any of the following: - Lime removers Cleaning intervals...
-
Page 19: Replacing The Grease Filter
Charcoal filters are available to order via Reinsert the grease filters. When the Miele Web Store, Miele Technical inserting the grease filters, make sure Service (see end of this manual for that the locking clip is facing outward. -
Page 20: Disposing Of Charcoal Filters
Bulb type........LED, GU10 Power ........... 3W The bulb will then drop downwards. Light bulbs are available from Miele or Grip the light bulb, turn it specialist dealers. counterclockwise and take it out. Screw the new bulb into the socket and push it upwards. -
Page 21: Contact In The Event Of A Fault
In the event of a fault which you cannot remedy yourself, please contact your Miele dealer or Miele Customer Service. You can book a Miele Service Call online at www.miele.com/service. Contact information for Miele Customer Service can be found at the end of this document. -
Page 22: Installation
*INSTALLATION* Installation Before installation Before installation, it is important 8 screws measuring 5 x 60 mm and to read the information contained in this chapter and in the “IMPORTANT 8 plugs measuring 8 x 50 mm SAFETY INSTRUCTIONS” chapter. for attaching to the wall Removing the protective film ... - Page 23 *INSTALLATION* Installation Conversion kit for recirculation mode The conversion kit contains an exhaust grille, hose, and hose clips (not supplied, but available as an optional accessory. See “Technical data”). 1 lever For removing the bulbs...
-
Page 24: Appliance Dimensions
*INSTALLATION* Installation Appliance dimensions The drawing is not to scale... -
Page 25: Distance Between Cooktop And Ventilation Hood (S)
Please also observe the information contained in the “IMPORTANT SAFETY INSTRUCTIONS” section. Minimum distance S Cooking appliance Miele Non-Miele appliance appliance Electric Cooktops 24" (610 mm) Electric Barbeques and Fryers 26"... -
Page 26: Installation Recommendations
*INSTALLATION* Installation Installation recommendations Drilling diagram for wall mounting - A distance of at least 26" (660 mm) is recommended above electric When drilling, please follow the cooktops to provide more workspace directions contained on the and easier cooking under the hood. accompanying installation sheet. -
Page 27: Plywood Backing
*INSTALLATION* Installation Find the studs to the left and right Plywood backing of the mounting location by tapping The majority of the weight of the the wall or using a stud finder. installed ventilation system will be Mark a vertical cutting line along the supported by the lower retaining center of each stud. -
Page 28: Air Venting
*INSTALLATION* Installation To achieve the most efficient air Air venting throughput with the lowest noise levels, WARNING: Danger of toxic fumes. please note the following: Gas cooking appliances release - The diameter of the vent ducting must carbon monoxide that can be harmful not be smaller than the cross-section or fatal if inhaled. -
Page 29: Non-Return Flap
If the exhaust is ducted through an outside wall, a Miele wall vent or roof vent (available as an optional accessory) is recommended. Both of these have a built-in non-return flap. -
Page 30: Reducing Collar
*INSTALLATION* Installation Reducing Collar (optional accessory) If you would like to reduce the environmental impact of your ventilation system by limiting the CFM output the Reducing Collar can be installed. It reduces the air flow to less than 400 CFM. Check local building codes for max. -
Page 31: Electrical Connection
If there is any question concerning accordance with CSA C22.1-12, the electrical connection of this Canadian Electrical Code, Part I. appliance to your power supply, please consult a licensed electrician or call Miele’s Technical Service Department. WARNING: THIS APPLIANCE MUST BE GROUNDED... -
Page 32: Technical Data
Technical data Fan motor 350 W Cooktop lighting DAP 1627, DAP 1727 2 x 3 W DAP 1927 3 x 3 W Total rated load DAP 1627, DAP 1727 356 W DAP 1927 359 W Voltage, frequency 120 V AC, 60 Hz Fuse rating 15 A Power supply cord length 59" (1.5 m) Weight DAP 1627 46.2 lbs (21 kg) DAP 1727 50.6 lbs (23 kg) DAP 1927 55 lbs (25 kg) Optional accessories for recirculation mode... - Page 35 Customer Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters Headquarters and Miele Centre 9 Independence Way 161 Four Valley Drive Princeton, NJ 08540 www.mieleusa.com Vaughan, ON L4K 4V8 www.miele.ca Customer Support Phone: 888-99-MIELE (64353) Customer Care Centre info@mieleusa.com...
- Page 36 DAP 1627, DAP 1727, DAP 1927 en-US M.-Nr. 12 800 600 / 00...
