1725 Hydraulic Foot Pump
Instruction Sheet
Specific Safety Information
Read and understand these instructions and the
instructions and warnings for all equipment andac-
cessories being used before operating this tool to
reduce the risk of serious personal injury.
SAVE THESE INSTRUCTIONS!
• High-pressure oil can easily puncture your skin,
causing serious injury, gangrene, or death.
• Release hydraulic pressure before disconnecting
hoses or couplers.
• Do not use your fingers or hands to check for
leaks.
• Do not hold hose or couplers while operating the
pump.
• Large forces are generated during product use
that can break or throw parts and cause injury.
Keep unnecessary personnel away from work
area. Stand clear during use and wear appropriate
protective equipment including eye protection.
• Only use Greenlee hydraulic pumps with appro-
priate Greenlee or Greenlee approved attach-
ments. Other uses or modifying the pump for other
applications could result in a hazardous situation.
• Only use pump with attachments with pressure
ratings of at least 6500 psi.
• Do not modify the pump's pressure settings. This
increases the risk of tool failure and injury.
99982935 REV 13
• Do not use tool attachments on live circuits,
these tools are not insulated. Contact with live
circuits could result in severe injury or death.
• Keep proper footing and balance to maintain
better control and reduce the risk of falling.
GREENLEE™ Contact Information
If you have any questions concerning this GREENLEE
Product:
• Contact your local GREENLEE distributor.
• Visit GREENLEE.com to find your local GREENLEE
Tool contact point and additional copies of this
manual.
• Contact Professional Tools Technical Service
Department at ProToolsTechService@Emerson.com
or in the USA and Canada call 1-844-789-8665
Tool Description
The 1725 Hydraulic Foot Pump is designed for use with
Greenlee hydraulic tool attachments such as; Cable
Bender Model 800, Cable Cutter Model 750, Punch
Drivers Model 746A.
Features
• Hands-free operation
• Foot activated release lever
• Latch lever pin for securing lever for storage and
transport
• Pump support to keep pump upright and stable
Specifications
Max Pressure ............................... 6500 psi (44,818 kPa)
Dimensions (Closed) ..........8.06 in. x 5.31 in. x 16.56 in.
.......................................(205 mm x 135 mm x 421 mm)
Dimensions (Open) ..........8.06 in. x 11.69 in. x 16.56 in.
.......................................(205 mm x 297 mm x 421 mm)
Weight ...................................................................9.5 lb
Hydraulic Oil ...............................................ISO-32 Type
Approximate Oil Capacity .................0.085 gal (0.34 qt)
............................................................. (11.3 oz) (0.32 L)
Hose Assembly .............Rated for 6,500 psi or higher
All specifications are nominal and may change as design
improvements occur.
© 2025 Greenlee Tools, Inc.
01/25
