Introduction
Use this document for quick installation and setup.
Teledyne LeCroy's PCI Express X16 Gen3 to MiniSAS HD Adapter card provides and simple means for test and debug of
®
PCIe
device/end-points using miniSAS HD connectors. It supports data rates of 2.5 GT/s, 5 GT/s and 8 GT/s. Several test
points and headers provide easy access to check status of bus signals.
The PCI Express X16 Gen3 to MiniSAS HD Adapter card works with miniSAS HD cables up to 0.5 meter in length as
defined in the PCI Express External Cabling Specification Revision 3.0, Version 0.6. If SAS compatible cables are used,
you must route the PCIe side bands and reference clock to your DUT from the host/root complex.
2
Components
The adapter package includes the following components:
•
PCI Express X16 Gen3 to MiniSAS HD Adapter
•
Differential Clock cable
•
Quick Start Guide (this document)
Inspect the received shipping container for any damage. Unpack the container and account for each of the system
components listed on the accompanying packing list. Visually inspect each component for absence of damage.
In the event of damage, notify the shipper and Teledyne LeCroy. Retain all shipping materials for shipper's inspection.
PCI Express X16 Gen3 to MiniSAS HD Adapter
PCI Express
X16 Gen3 to MiniSAS
®
HD Adapter for External Cable
Quick Start Guide
