- Page 1 SER MANUAL VALUATION BOARD KIT FOR RADIO MODULES HYONE -III(-SPI), S ROTEUS ETEBOS 26110110240 0, 2611011021000 ERSION 28, 2025 ARCH...
- Page 2 This is especially important for Wireless Connectivity products that were not purchased directly from Würth Elektronik eiSos. A firmware update on these respective products may be required. We strongly recommend including the possibility of a firmware update in the customer sys- tem design.
-
Page 3: Revision History
Bill of materials is added in chapter 3.9 . LFXO crystal part number is updated in January chapter 3.5.5 . 2021 Input capacitance variables respectively 3.5.5 . changed to FCC exemption information is added in chapter 6 . Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... - Page 4 Added radiation characteristics in chapter 3.10 . New corporate design. Chapter Marking is added. October Chapter Legal notice is added. 2024 Chapter UART / USB is updated. March Update all to hardware version 3.1 2025 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs...
- Page 5 SubMiniature version A Serial Wire Debug Universal Asynchronous Receiver Transmitter Universal Asynchronous UART allows communicating with the module of a Receiver Transmitter specific interface. Universal Serial Bus Voltage Drain Drain Supply voltage Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs...
-
Page 6: Table Of Contents
Exemption clause ........38 7 Important notes 8 Terms of Use for Würth Elektronik eiSos GmbH & Co. KG EV-Boards, evaluation kits and evaluation modules Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... - Page 7 WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 9 Legal notice 10 License terms Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs...
-
Page 8: Supported Radio Modules
LE & 2611011024020 Setebos-I proprietary - smart antenna configuration Order code Product Name 2611019024001 Proteus-III Bluetooth 5.1 EV-Kit 2611019021001 Thyone-I EV-Kit 2611139024021 Setebos-I EV-Kit Table 1: Compatibility Figure 1: Product image Please be aware that the EV-Board can be delivered with a module containing a label or a laser marking. -
Page 9: Content Proteus-Iii Bluetooth 5.1 Ev-Kit
Kit Content 2611019024001 Quantity EV-Board with Proteus-III USB2 A to USB Micro cable Packaging: Cardboard Box, ESD safe cover Table 2: Content Proteus-III Bluetooth 5.1 EV-Kit Kit Content 2611019021001 Quantity EV-Board with Thyone-I with On-board PCB Antenna connection Thyone-I USB radio stick... -
Page 10: Functional Description
EV-Board. A typical name is "COM12" in Windows systems or "/dev/ttyUSB0" in Linux systems. The WE UART Terminal PC tool or any other serial terminal program (like hterm for Windows) has to be run and the corresponding COM port has to be opened using the default settings of the mounted radio module. -
Page 11: Development Board
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3 Development board 3.1 Block diagram Figure 2: Block diagram Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 12: Jumpers
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3.2 Jumpers Figure 3: Jumpers, defaults Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 13: Jumper Jp2 Hw-V3
Connect MODE_1 to VDD if set LED3 LED1 9,10 LED2 11,12 UART TX 13,14 UART RX 15,16 17,18 19,20 Wake_up Table 6: Jumper JP2 HW-V2 Info of table 6 corresponds to HW-V2 for users of previous version. Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 14: Jumper Jp1
Evaluation board/kit user manual Function Jumper set (default) Power bridge Table 7: Jumper JP1 CBUS Connections Jumper set (default) CBUS 0 - Reset CBUS 1 - Boot CBUS 2 - Wake-up Table 8: Jumper JP3 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 15: Connectors And Pin Headers
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3.3 Connectors and pin headers Figure 4: Connectors Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 16: Con1
CON3 Optional connection for NFC Antenna CON4 SMA connector for external antenna CON5 Optional connection for WE sensor EV-Boards Edge card connector, see table 11 CON6 Table 9: Connector overview 3.3.1 CON1 Connector CON1 is a micro-USB connector that enables connection to PC via standard micro- USB cable. -
Page 17: Con4
22pF capacitor 885012005027 and C6 should be left unpopulated. 3.3.5 CON5 Connector CON5 is used to connect the WE Sensor EV-Boards. This feature is subjected to a customized firmware and not supported by default firmware. Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025... -
Page 18: Con6
B26, B28, B30, B32 SWCLK SWCLK SWDIO SWDIO P0.03 WAKE_UP P0.02 BOOT P0.12 P0.11 P0.18 RESET P0.23 RSVD P0.21 RSVD P0.07 RSVD P1.00 RSVD P1.08 UTXD P1.09 URXD P0.19 MODE_1 P0.22 BUSY Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 19: Connector Con6
P0.23 RSVD P1.00 RSVD P0.07 RSVD P0.19 MODE_1 Table 13: Pinheader P2 nRF52840 Function P0.09 NFC1, RSVD P0.10 NFC2, RSVD P0.03 WAKE_UP P0.12 P0.11 P1.09 URXD P1.08 UTXD Table 14: Pinheader P3 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 20: Pinheader P4
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual nRF52840 Function VDD 3V VDD 5 V Table 15: Pinheader P4 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 21: Buttons
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3.4 Buttons Figure 7: Buttons Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 22: Reset Button
3.4.2 WAKE-UP button Some modules use the wake-up button connected to their WAKE-UP pin to exit from sleep mode of the module. Please refer to the module specific manual for detailed information. Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 23: Function Blocks
When a baud rate is configured in the FTDI chip, the prescaler is chosen that meets the closest baud rate. In that case, the real baud rate differs from the configured one, introducing a UART clock error, which may lead to UART communication issues. Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 24: Uart Direct
For higher LFCLK accuracy (better than ±250 ppm) a low frequency crystal oscillator of 32.768 kHz (LFXO) shall be used. A crystal, 3.2 ×1.6 mm package, for example 830009706, can be placed Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 25: Lfxo Mounting
C9 and C10 results in 12 pF which was also tested on the evauation board. Depending on parasitic capacitance of Host PCB, a capacitance of 12 pF may be a good start- ing value for C9 and C10. Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 26: Nfc
To apply this, remove the flash adapter connection. Make sure a jumper at JP6 is placed. Unplug and replug the USB connection of the device. Press the reset button on the EV-Board. Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 27: Long Range Measurement - Thyone-I
(2611017221001) is connected to the module In order to use the module’s onboard PCB antenna, the capacitor connection to SMA connector should be made according to the chapter 3.3.4 and figure 6 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 28: Schematic
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3.7 Schematic Figure 10: Schematic sheet-1 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 29: Schematic Sheet-2
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual Figure 11: Schematic sheet-2 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 30: Layout
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3.8 Layout no metal antenna CON4 PCB edge Figure 12: Assembly diagram Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... - Page 31 WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual Figure 13: Top Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs...
- Page 32 WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual Figure 14: Layer 2 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs...
- Page 33 WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual Figure 15: Layer 3 Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs...
- Page 34 WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual Figure 16: Bottom Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs...
-
Page 35: Bill Of Materials
EV Order code 2611017221001 (SMA Connection) CON1 Micro_USB Würth Elektronik 629105150521 CON2 2x10 Würth Elektronik 61002021121 CON3 BLLPSMD4S CON4 Würth Elektronik 60312102114405 CON5 Würth Elektronik 610106249221 CON6 not mounted DFLS130L-7 DFLS130L-7 LDO, 3V3 FT232RQ Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... - Page 36 0402 not mounted not mounted 180R 0402 not mounted not mounted not mounted not mounted 430152043826 Würth Elektronik 430152043826 430152043826 Würth Elektronik 430152043826 not mounted Figure 17: BOM Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs...
-
Page 37: Internal Antenna Radiation Characteristics
Figure 18: Antenna characteristic from integrated antenna measured on official EV-Board Radiation characteristic shown is valid for the module on the EV-Board. It is important to be aware that size of groundplane and placement of module has influence on the radiation pattern Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 38: Hardware History
WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 4 Hardware history Version 3.2 "Release" 3.0 Layout change JP2 3.1 Internal change production 3.2 silkscreen on bottom deleted, R2 changed to 1 k Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 39: Marking
The currently installed firmware can be requested from the module using the cor- responding product specific command. The firmware version as well as the hardware version are restricted to show only major and minor version not the patch identifier. Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025 www.we-online.com/wcs... -
Page 40: Regulatory Compliance Information
Equally, the national laws and restrictions may vary with the country. In case of doubt or uncer- tainty, we recommend that you consult with the authorities or official certification organizations of the relevant countries. Würth Elektronik eiSos is exempt from any responsibilities or liabili- ties related to regulatory compliance. -
Page 41: Important Notes
-kits or -modules (hereinafter jointly referred to as "EVB") in accordance with the terms and conditions contained here. The EVB is provided in the "as is" state. WE disclaims all express and implied warranties, in particular those concerning the suitability for a certain purpose, the absence of defects or non-violation of third-party rights. - Page 42 The use of the EVB is your full and independent responsibility. The EVB is expressly not intended to be installed in a terminal device or to be part of a terminal device in whole or in part. WE reserves the right, at its own discretion, to make corrections, improvements, adjustments or other changes to the EVB or to discontinue the EVB.
-
Page 43: Legal Notice
Exclusion of further rights and rights of use for intellectual property of EVB The sale of an EVB does not constitute the granting by WE of any license or other right of any kind - expressly or implicitly - including, but not limited to, any patent, copyright, trademark or other proprietary rights. -
Page 44: License Terms
Applicable law to these license terms shall be the laws of the Federal Republic of Germany. Any dispute, claim or controversy arising out of or relating to these license terms shall be resolved and finally settled by the court competent for the location of Würth Elektronik eiSos registered Thyone-I, Proteus-III(-SPI), Setebos-I Version 1.7, March 2025... - Page 45 Elektronik eiSos homepage for any updates. Your continued usage of the products will be deemed as the acceptance of the change. We recommend you to be updated about the status of new firmware and software, which is available on our website or in our data sheet and manual, and to implement new software in your device where appropriate.
- Page 46 Compatibility ........Content Proteus-III Bluetooth 5.1 EV-Kit ..... . .
- Page 47 Contact Würth Elektronik eiSos GmbH & Co. KG Division Wireless Connectivity & Sensors Max-Eyth-Straße 1 74638 Waldenburg Germany Tel.: +49 651 99355-0 Fax.: +49 651 99355-69 www.we-online.com/wireless-connectivity...
