Aussie Tonneaus ATC01230 Fitting Instruction

TONNEAU COVER FITTING INSTRUCTION
Package Includes
- 1 x Tonneau Cover
- 2 x Support Bars
- 1 x Shock Cord
- 1 x Commodore Extrusion with End Cap
1. INSTALLATION PROCEDURE
NOTE Read entire instructions prior to start.
To fit the front extrusion, have the front plastic inserted into the centre rail of the extrusion.
Slide the aluminum with the end caps vertically up into the recessed notches behind the cab.
Once the extrusion is all the way up on both sides, rotate it 90 degrees so the plastic sewn into
the cover it on the top.
The extrusion then slides back towards the tailgate to lock it into position.
The Front of the Side Plastics need to be Pushed In to engage with the tub.
Use pull loops to remove cover for vehicle.
***NOTE: The plastic strip at the front of the tonneau cover is designed to slide into the middle
track of the commodore extrusion. If you are experiencing problems fitting the tonneau cover,
adjust the length by sliding the plastic strip into the front or rear track of the commodore
extrusion***
***NOTE: All parts supplied with the cover must be used for it to fit correctly. Do not use genuine
fitting kit.***
2. CARING FOR YOUR TONNEAU
Apply bee's wax or Dri-lube to stitching a few times a year, as this will maintain the Tonneaus
waterproofing ability and prevent the stitching from degrading. Use a mild detergent and soft scrubbing
Never drive without tonneau support bars in place as flapping can cause a delaminating effect on the
Holden With Factory Sport Bars
VY VZ Crewman
2003 – 2007
Part Number: ATC01230
All fitting kits are weighed to ensure accurate quantities.
brush to clean tonneau.
- 4 x Bar Brackets
- 4 x Rope Hooks
- 2 x Washers
- 1 x Fitting Instruction
material.
