Summary of Contents for Heatsail LEAF
- Page 1 LEAF® UNIQUE SHADING SOLUTION WITH HEATING FOR YOUR GARDEN OR TERRASS RUSTPROOF & LOW ENERGY CONSUMPTION MINIMAL WEATHERPROOF NO CO2 EMISSIONS MAINTENANCE Heatsail LEAF®...
- Page 2 Electrical safety regulations & requirements The use of the LEAF requires an electrical system with sound safety grounding. The electrical safety of the device is only assured if it is cor- rectly connected to a grounding system built in accordance with safety regulations.
- Page 3 The LEAF will remain hot for a considerable period of time after it has been switched off. Do not touch the LEAF for a period of 40 minutes after it has been switched off. Caution should be exercised at all times.
-
Page 4: Maintenance
The LEAF is not allowed for use in greenhouses or construction sites. Always keep the LEAF free of snow. Whenever the LEAF is not in use, the cover must be used, to protect the LEAF Heatsail will not be held responsible for damage resulting from non-compliance with the instructions regarding use and maintenance. - Page 5 3.2. Replacing the lamp Your LEAF is supplied with 6 G4 halogen bulbs of 12V with a maximum output of 40 Watt as standard. The maximum permitted output power is 320 Watt. The electrical supply must be disconnected via the installation’s breaker switch or by unplugging the device before the bulb can be replaced.
- Page 6 3.4. Fabric maintenance: Heatsail works with Sunbrella®, the world leader in best quality outdoor fabrics. Sunbrella® fabrics are made of 100% acrylic fibre and are thermoplastic or heat-sensitive. General or light cleaning: To clean the fabric, first remove the fabric from the frame.
- Page 7 after using a bleach solution. Note: Remember to protect the area around your cloth if you are using a bleach solution as this has an adverse effect on other fabrics. Re-treating Sunbrella fabrics: All the cloths come with a water and dirt repellent after treatment which is designed to last for several years.
- Page 8 Check if the inside of the pump looks clean and normal. Special maintenance for winter or if not used for over two months • Take out the fittings and dry them out by sunshine • Drain all water from the system Heatsail LEAF®...
- Page 9 User manual 6.1 Touchscreen ON/OFF To turn your LEAF on or OFF, you need to press 3 seconds on the Heatsail logo on top of the touch- screen The colour will change from red to white. OPEN/CLOSE To open the shading function of the LEAF, you press on the sec- ond icon.
- Page 10 If you want to more heat, you need to press the second icon on the second row. Please note: to guarantee the safety of your product, the heating is enabled only when the LEAF is in an open position. User manual...
- Page 11 To deactivate the lighting, you need to press the first icon. You can dim or boost your lighting by long-pressing the first icon (to dim) or the second icon (to boostà. Heatsail LEAF®...
- Page 12 6.2 Turning you LEAF You can rotate your LEAF on the base provided. Locate the locking pin on the back of the LEAF. Lift it and gently rotate until the LEAF is in your desired position. Please note: Ensure the stability of your product at all times.
- Page 13 6.5 Use of the cover After using the LEAF, the cover should be used at all times to ex- tend the life of the LEAF and avoid damage. Heatsail LEAF®...
- Page 14 6.6 Activate the misting system After plugging the pump into a suitable outlet and turning the water tap halfway open, you can turn on the pump. You have two options to use the fogging system of your BEEM; either you use the APP or you use the buttons below.
- Page 15 LEAF, after pairing the LEAF with your smartphone, you can click on the wheel on the “SHADING” field. The lower the value: the faster the LEAF will close in windy con- ditions. Please note: this feature only works if the LEAF is connected to the mains and can only be used at your own risk.
- Page 16 6.8 Connecting the filter and the pump (A) Tap (B) Limescale filter - NOTE this should be replaced regularly. (C) Coupling piece (NOTE if it doesn’t fit you need to buy the right one from your local dealer, there are local differences worldwide). (D) Garden hose coupling (E) Pre-filter (F) Rubber hose with quick fitting (G) Misting pump...
-
Page 17: Troubleshooting
The quality of the oil is not suitable for the machine. The machine has to work too hard lower the pressure. The pump and connectors are leaking Replace the oil. Check if a nut and/or bolt is loose. Heatsail LEAF®... - Page 18 Before doing any work on the LEAF, disconnect the power supply via the main switch of the installation or by unplugging the LEAF. One of the lights does not work Raise the glass, turn and remove. Now you have access to the halogen bulb.
- Page 19 Thank you for your purchase! This manual is inextricably linked to the misting system of the LEAF® and must always be kept by the user or by the responsible person. Read the user instructions carefully. It contains essential information about safety, use, cleaning and maintenance of the pump of the LEAF.
