TOLSEN TOOLS FX Force Xpres 79966 Instruction Manual

Automatic self-priming peripheral pump
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

79966
AUTOMATIC SELF-PRIMING PERIPHERAL PUMP
INSTRUCTION MANUAL
SAVE THIS MANUAL !
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
220-230V~50Hz 370W 0.5Hp

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FX Force Xpres 79966 and is the answer not in the manual?

Questions and answers

Related Manuals for TOLSEN TOOLS FX Force Xpres 79966

Summary of Contents for TOLSEN TOOLS FX Force Xpres 79966

  • Page 1 79966 AUTOMATIC SELF-PRIMING PERIPHERAL PUMP INSTRUCTION MANUAL 220-230V~50Hz 370W 0.5Hp SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.

  • Page 2: Fluid Type

    SAFETY WARNING Before start-up, note the following The Pump must be connected to a Ground Fault Circuit Interrupter (GFCI) protected plug which has been installed according to regulations. The plug must have a supply voltage of 220-230V at 50 Hz. Caution This Pump has been evaluated for use with water only.

  • Page 3: Specifications & Setup

    SPECIFICATIONS & SETUP Compressor use and care SPECIFICATIONS Electrical Rating 220-230V 50Hz ； 1/2HP（370W） Power Cord Length 0.8m Maximum Flow @ 0’ 35L/min Maximum Head li @ 0 Flow Discharge Port 1’’ Compressor use and care INSTALLATION The pump must be installed in a stationary position with either: a.

  • Page 4: Installation Instructions

    SETUP Installation instructions This pump is designed for use as a well pump. WARNING! TO PREVENT SERIOUS INJURY FROM ELECTRIC SHOCK: Install indoors or in weather-proof well house only. This Pump is non-submersible. Do not plug in the power cord when wet or standing on damp or wet ground.

  • Page 5: Operation

    MAINTENANCE OPERATION A er reading these instructions, consider the following points before starting the pump: 1. The Compression Tank has a rubber bladder inside that has been pressurized to 23 PSI. Air can be added using a bicycle pump. 2. Make sure the intake pipe is fully submerged before continuing. 3.

  • Page 6: Troubleshoot

    TROUBLESHOOT problem possible causes Likely Solutions The Pump 1. No power. 1. Check connections, and breaker/fuse. won’t start 2. Pressure switch disconnected. 2. Check gauge. 3. Thermal Protection cut out. 3. Allow pump to cool. 4. Blocked impeller 4. Free the impeller. The Pump 1.
  • Page 7 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. TolsenWorld SCAN TO VISIT MADE IN CHINA PRODUCT LINK...
