- Page 1 Patriot Multi-Color Gelcoater Operations Manual This manual is applicable to the following models: MVE-PAT-1500-X MVG-PAT-1500-X MVE-PAT-3000-X MVG-PAT-3000-X Rev. November 2020...
- Page 2 1862 Ives Ave, Kent, WA 98032 · USA · Tel (253) 854-2660 · Fax (253) 854-1666 E-mail: info@mvpind.com For a list of international distributors, visit our website at : www.mvpind.com/mvp-international Use of this product confirms that Magnum Venus Products, Inc.’s standard terms and conditions of sale apply.
-
Page 3: Table Of Contents
Patriot Multi-Color Gelcoater Operations Manual Table of Contents Section Page Table of Contents Safety & Warning Information Introduction Getting Started Charging Accumulators Changing Colors Priming the Unit Performing Daily Tasks... -
Page 4: Safety & Warning Information
MVP assumes no responsibility for loss, damage, expense or claims for bodily injury or property damage, direct or consequential, arising from the use of such chemical components. - Page 5 Patriot Multi-Color Gelcoater Operations Manual Safety Precautions Avoid skin contact and inhalation of all chemicals. Review Material Safety Data Sheet (MSDS) to promote the safe handling of chemicals in use. Restrict the use of all chemicals to designated areas with good ventilation. ...
- Page 6 An improperly loaded drum may lead to an imbalance, causing a unit to tip over Personal Protective Equipment (PPE) MVP recommends the use of personal safety equipment with all products in our catalog. Wear safety goggles, hearing protection, a respirator, and chemical resistant gloves.
-
Page 7: Symbol Definitions
Patriot Multi-Color Gelcoater Operations Manual Symbol Definitions Indicates the risk of Indicates the risk of contact with chemicals contact with voltage / that are hazardous, which amperage that may lead may lead to injury or to serious injury or death death. - Page 8 Patriot Multi-Color Gelcoater Operations Manual Polymer Matrix Materials: Advanced Composites Potential health hazards associated with the use of advanced composites can be controlled through the implementation of an effective industrial hygiene and safety program. https://www.osha.gov/dts/osta/otm/otm_iii/otm_iii_1.html#t iii:1_1 Resins Composite Component Organ System Target Known (Possible) Health Effect (Possible Target) Contact and allergic dermatitis,...
- Page 9 Patriot Multi-Color Gelcoater Operations Manual Catalyst - Methyl Ethyl Ketone Peroxide (MEKP) MEKP is among the more hazardous materials found in commercial channels. The safe handling of the “unstable (reactive)” chemicals presents a definite challenge to the plastics industry. The highly reactive property which makes MEKP valuable to the plastics industry in producing the curing reaction of polyester resins also produces the hazards which require great care and caution in its storage, transportation, handling, processing and disposal.
- Page 10 Patriot Multi-Color Gelcoater Operations Manual Never add MEKP to anything that is hot, since explosive decomposition may result. Avoid contact with skin, eyes, and clothing. Protective equipment should be worn at all times. During clean-up of spilled MEKP, personal safety equipment, gloves, and eye protection must be worn.
- Page 11 Patriot Multi-Color Gelcoater Operations Manual The reaction is unpredictable. Prior use of an HHC solvent without incident (corrosion or explosion) does NOT mean that such use is safe. These solvents can be dangerous alone (as a clean-up or flushing agent) or when used as a component or a coating material. There is no known inhibitor that is effective under all circumstances.
- Page 12 Patriot Multi-Color Gelcoater Operations Manual and follow his instructions explicitly. Preferably the supplier should premix the catalyst to prevent possible “on the job” contamination while mixing. WARNING If diluents are not used, remember that catalyst spillage and gun, hose, and packing leaks are potentially more hazardous since each drop contains a higher concentration of catalyst and will therefore react more quickly with overspray and the leak.
- Page 13 Patriot Multi-Color Gelcoater Operations Manual Toxicity of Chemicals Magnum Venus Products recommends that you consult OSHA Sections 1910.94, 1910.106, 1910.107 and NFPA No.33, Chapter 14, and NFPA No.91. Contact your chemical supplier(s) and determine the toxicity of the various chemicals used as well as the best methods to prevent injury, irritation and danger to personnel.
- Page 14 Patriot Multi-Color Gelcoater Operations Manual Precautions include: 1. Know precisely what chemicals you are using and obtain information from your chemical supplier on what to do in the event the chemical gets onto your skin or into the eyes, or if swallowed.
-
Page 15: Introduction
“Recommended Practice on Static Electrical”. Refer especially to section 7-7 titled “Spray Application of Flammable and Combustible Materials”. Introduction This manual provides information for the operation, maintenance, and simple repair of the MVP Patriot Multi-Color Gelcoater. The following procedures are included: ... -
Page 16: Air Requirements
Patriot Multi-Color Gelcoater Operations Manual Air Requirements 8. The system requires a supply of air (30 cfm) and at least 100 psi (7 bar). 9. The unit requires a ½ inch (12 - 13 mm) inside diameter air hose minimum (use caution when using quick disconnects;... -
Page 17: Overview Of Controls
Patriot Multi-Color Gelcoater Operations Manual Overview of Controls Main Air (Upper) Manifold Priming Button Pump Pressure Recirculation Gauge & Regulator Valve Ram Extraction Gauge & Regulator Filter/Water Trap Main Air Inlet and Ball Valve Catalyst (Lower) Manifold Catalyst Pump Pressure Gauge Recirculation Valve... -
Page 18: Getting Started
Patriot Multi-Color Gelcoater Operations Manual Getting Started Installation and Set Up 11. Unpack the unit and all components. 12. Assemble the frame work as needed. Note 3 mounting brackets are provided with the standard frame (enough for 2 colors). Additional mounting brackets and hardware can be ordered for each additional color and will need to be installed. - Page 19 Patriot Multi-Color Gelcoater Operations Manual For high fluid pressure applications, it may be required to charge the accumulators to between 280 and 300 psi. These are applications using filled resins or spray putties. To charge the accumulators, you will need a charging pump or similar device or a high-pressure tank and regulators.
- Page 20 Patriot Multi-Color Gelcoater Operations Manual 35. Relieve any existing charge by inserting a blunt object (such as an Allen wrench) into the top of the charging valve. 36. Attach the charging pump by connecting the black charging hose to the charging valve on top of the resin accumulator.
-
Page 21: Changing Colors
Patriot Multi-Color Gelcoater Operations Manual 46. Relieve any existing charge by inserting a blunt object (such as an Allen wrench) into the top of the charging valve. 47. Attach the charging system to the resin accumulator by connecting the black charging hose to the charging valve on top of the resin accumulator. -
Page 22: Priming The Unit
Patriot Multi-Color Gelcoater Operations Manual 62. Release the pressure in the gelcoat accumulator by pushing a small dull rod (such as an Allen wrench) into the top of the accumulator charging valve. 63. Rotate the ball valve on the catalyst manifold to the open position to relieve catalyst pressure to the supply jug. - Page 23 Patriot Multi-Color Gelcoater Operations Manual 80. Set the flush tank pressure at 50 to 60 psi (3.5 – 4 bar). 81. Check for leaks and fix as necessary. 82. Push the flush valve on the side of the gun block to test solvent flush. Select Gelcoat Pump Color 83.
- Page 24 Patriot Multi-Color Gelcoater Operations Manual 98. With the gun locked in the open position, slowly increase pump regulator pressure until pump is running at a slow but steady rate. 99. Allow pump to run until a steady stream of gelcoat is being dispensed. 100.
-
Page 25: Performing Daily Tasks
Patriot Multi-Color Gelcoater Operations Manual Set Up the Gun External Mix 113. Use a little red grease on the O-rings and threads of the spray tip, catalyst tip, and retainer. 114. Install the gelcoat spray tip into the front of the gun block. 115. - Page 26 Patriot Multi-Color Gelcoater Operations Manual 131. Remove the pivot pin from the catalyst drive. 132. Manually pump the catalyst pump with the catalyst drive until you observe the stream returning to the catalyst jug is air free. 133. Close the recirculation valve on the catalyst manifold. 134.
-
Page 27: System Components
Patriot Multi-Color Gelcoater Operations Manual Daily Shut Down – External Mix 157. Wipe the face of the nozzle and catalyst tip with solvent. 158. Turn off the main air ball valve at the air manifold. 159. Remove the nozzle and catalyst tip and clean with solvent. 160. -
Page 28: Parts Drawings
Patriot Multi-Color Gelcoater Operations Manual Core System Parts Part Number Description PAT-CJ Cat Jug Assy – 2 Gal PA-CA-5000 Carriage Assembly PAT-BRKT-CJ-4 Cat Jug Weldment Bracket 1107-6-1 Carriage Stop Bracket Parts Drawings The illustrations on the following pages are included based on the components ordered with your system and will assist with assembly and repair. - Page 29 Patriot Multi-Color Gelcoater Operations Manual...
- Page 30 Patriot Multi-Color Gelcoater Operations Manual...
- Page 31 Patriot Multi-Color Gelcoater Operations Manual...
- Page 32 Patriot Multi-Color Gelcoater Operations Manual...
- Page 33 Patriot Multi-Color Gelcoater Operations Manual...
- Page 34 Patriot Multi-Color Gelcoater Operations Manual...
- Page 35 Patriot Multi-Color Gelcoater Operations Manual...
- Page 36 Patriot Multi-Color Gelcoater Operations Manual...
- Page 37 Patriot Multi-Color Gelcoater Operations Manual...
- Page 38 Patriot Multi-Color Gelcoater Operations Manual...
- Page 39 Patriot Multi-Color Gelcoater Operations Manual...
- Page 40 Patriot Multi-Color Gelcoater Operations Manual...
- Page 41 Patriot Multi-Color Gelcoater Operations Manual...
- Page 42 Patriot Multi-Color Gelcoater Operations Manual...
- Page 43 Patriot Multi-Color Gelcoater Operations Manual...
- Page 44 Patriot Multi-Color Gelcoater Operations Manual...
- Page 45 Patriot Multi-Color Gelcoater Operations Manual...
- Page 46 642 Barbrow Ln, Knoxville, TN 37932 · USA · Tel: (865) 684-4416 ECHNOLOGY ENTER AND ANUFACTURING 1862 Ives Ave, Kent, WA 98032 · USA · Tel (253) 854-2660 · Fax (253) 854-1666 E-mail: info@mvpind.com For a list of international distributors, visit our website at : www.mvpind.com/mvp-international...
