- Page 1 VIDEO CONFERENCE SYSTEM SYSTÈME DE VIDÉOCONFÉRENCE SISTEMA DE VIDEOCONFERENCIA СИСТЕМА ВИДЕОКОНФЕРЕНЦСВЯЗИ 视频电话会议终端 ビデオ会議システム CS-800 Quick Guide Kurzanleitung Guide rapide Guía rápida Guia rápido Guida veloce Краткое руководство 快速指南 ZH-CN 快速指南 ZH-TW 빠른 가이드 クイックガイド...
-
Page 2: Table Of Contents
Power supply ........................11 Inserting/replacing the remote control batteries ............... 11 Pairing the device and remote control................12 Configuring to use all CS-800 functions ............13 Installing the DisplayLink® driver..............13 Selecting the device on the computer.............. 13 Using the device’s on-screen display............... 14 Displaying the device’s on-screen display................ -
Page 3: Introduction
Introduction Thank you for purchasing the Yamaha CS-800. This product is a video conferencing system for holding remote conferences in huddle spaces and meeting rooms. It can be used as an audio/video device in your unified communications setup. For comfortable remote collaboration, this device is equipped with a high-quality camera, microphone and speaker. -
Page 4: Included Items
Introduction Included items • CS-800 (device) • Safety Guide • Quick Guide (this manual) • Warranty • USB cable (Type C-A, 5 m) • HDMI cable (2 m) • Remote control • Lens cap • Terminal cover • Button battery (CR2032) × 2 •... -
Page 5: Available Manuals
This product is designed to allow the firmware of the device to be updated in order to improve operability, add functions and fix problems. Information on updating the firmware is available on the Yamaha website. For details on the updating procedure and device settings, refer to the CS-800 User’s Guide. CS-800 Quick Guide... -
Page 6: Controls And Connectors
During a call (camera/microphone operating) Red (lit) Microphone muted Monitoring off; performing factory reset; activation of all White (flashing) functions completed (notification) Blue (flashing) Pairing Green (flashing) Receiving a call Orange (flashing) Updating firmware Orange<-->Red (flashing) Firmware update failed 4 Speaker CS-800 Quick Guide... -
Page 7: Rear Panel
This enables displaying the computer screen and configuring the device. Use the included USB cable (Type C-A) for this connection. For details on the device settings, refer to the CS-800 User’s Guide. 4 [HDMI] port This port is for connecting the device to a TV. -
Page 8: Remote Control
Can be used to display the menu on the TV or pair the device with the remote control (page 12). 2 Power button Used to turn the CS-800 on/off. 3 Camera zoom button 4 Pan/tilt button 5 Camera preset 1 & 2 buttons... -
Page 9: Connections And Setup
Connect one end of the included HDMI cable to the [HDMI] port on the device, and connect the other end to the TV. Connect one end of the included USB cable to the [USB] port on the device, and connect the other end to the computer. CS-800 Quick Guide... - Page 10 Connect one end of the included HDMI cable to the computer, and connect the other end to the TV. Connect one end of the included USB cable to the [USB] port on the device, and connect the other end to the computer. CS-800 Quick Guide...
-
Page 11: Power Supply
• After the power supply has been connected, the device can be turned on or set to standby with the power button on the remote control. Inserting/replacing the remote control batteries Bottom panel Battery cover Batteries Remove the bottom panel and battery cover, and then insert two batteries (CR2032). CS-800 Quick Guide... -
Page 12: Pairing The Device And Remote Control
The status indicator on the front panel of the device flashes in blue. Long-press the menu button on the remote control for at least 2 seconds. Pairing is finished when the status indicator on the front panel of the device lights up in white. CS-800 Quick Guide... -
Page 13: Configuring To Use All Cs-800 Functions
Installing the DisplayLink ® driver When using the [HDMI] port of the CS-800 to display the computer screen on a TV, it may be necessary to install the DisplayLink driver, depending on the connected computer. Download the latest driver from displaylink.com/downloads. -
Page 14: Using The Device's On-Screen Display
The on-screen display can be displayed on a TV and operated with the remote control. Note • This function can be used in a setup where the TV is connected to the CS-800 by using the HDMI cable. It cannot be used in a setup where the TV is connected to the computer by using the HDMI cable. -
Page 15: Installing The Terminal Cover
Attach the terminal cover to the device by using the included screws. Terminal cover Installing the table stand Attach the included table stand to the device. Attach the table stand to the device by using the included screws. Device Table stand (rear panel) CS-800 Quick Guide... -
Page 16: Installing The Wall Mounting Bracket
We cannot be held responsible for accidents caused by incorrect installation. • After installation, do not lean against the CS-800 or apply a strong force to it from above. If the device falls, injuries or damage may result. -
Page 17: Installing The Monitor Mounting Bracket (Vesa)
Attach the monitor mounting bracket (vertical), monitor mounting bracket (for mounting onto wall mounting bracket) and the wall mounting bracket using the screws included with them. Monitor mounting bracket (vertical) Wall mounting bracket Monitor mounting bracket CS-800 Quick Guide... - Page 18 Attach the two monitor mounting brackets (horizontal) to the TV by using the included screws. (back) Monitor mounting bracket (horizontal) Attach the brackets assembled in step to the brackets installed in step Important Choose the appropriate mounting position for the TV. CS-800 Quick Guide...
- Page 19 When attaching the TV to a stand or wall mount, tightly secure the mounting brackets together. Spacer TV stand Important Depending on the configuration of the TV stand or wall mount, also tightly secure the spacers included with monitor mounting bracket BRK-TV1 (separately sold). CS-800 Quick Guide...
- Page 20 Hang the device on the wall mounting bracket installed in step From the underside of the device, secure it by using the included screw. CS-800 Quick Guide...
-
Page 21: Returning To Factory Default Settings (Factory Reset)
USB cable (Type C-A), HDMI cable, lens cap, terminal cover, remote control, button battery (CR2032) × 2, Included items AC adaptor with power cord (P20V2.1A-AN), table stand, wall mounting bracket, mounting screws, hexagonal wrench Separately sold items Monitor mounting bracket (VESA) BRK-TV1 CS-800 Quick Guide... - Page 22 Yamaha Global Site U.S.A. and Canada https://uc.yamaha.com/ Other Countries https://www.yamaha.com/ Yamaha Downloads U.S.A. and Canada https://uc.yamaha.com/support/ Other Countries https://download.yamaha.com/ Manual Development Group © 2022 Yamaha Corporation Published 02/2022 2022 年 2 月 发行 IPOD-A0 xxxxxxx...
