Lift-top coffee table
Hide thumbs

Advertisement

Available languages

Available languages

Table of Contents

CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Lift-Top Coffee Table
Palladia Collection | Model 424817
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-523-3987
.
It's addicting.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-25
Français pg 26-29
Español pg 30-33
Lot # 572592
Purchased: __________________
09/10/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 424817 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder 424817

Summary of Contents for Sauder 424817

  • Page 1 Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays) It's addicting. Lift-Top Coffee Table NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Palladia Collection | Model 424817 PLEASE READ AND KEEP FOR FUTURE REFERENCE. Sauder.com English pg 1-25 Français pg 26-29 Español pg 30-33...
  • Page 2 H2 FRONT/BACK BASE (2) UPPER PLINTH (4) TOP (1) SIDE BASE (2) STRETCHER (1) UPRIGHT (1) COLUMN (4) PLINTH CAP (4) BOTTOM (1) BASE MOLDING (2) LOWER PLINTH (4) SHELF (1) MOLDING (4) HALF DISK (8) Page 2 424817 www.sauder.com/service...

  • Page 3: Part Identification

    Now you know Part Identification our ABCs. www.sauder.com/service 424817 Page 3...

  • Page 4: Hardware Identification

    SILVER 5/8" FLAT HEAD SCREW - 4 30S BLACK 1-9/16" FLAT HEAD SCREW - 4 BLACK 3/4" PAN HEAD SCREW - 2 BLACK 3/4" MACHINE SCREW - 4 BLACK 1-1/4" MACHINE SCREW - 4 113S BLACK 1-15/16" FLAT HEAD SCREW - 12 Page 4 424817 www.sauder.com/service...
  • Page 5 Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
  • Page 6 (6 used in this step) S u r f a c i t h H I D D E N S u r f a c i t h o u t H I D D Finished edge Finished edge Page 6 424817 www.sauder.com/service...
  • Page 7 Edge with holes h o l i t h f a c S u r Edge with holes o l e u t h i t h o f a c S u r www.sauder.com/service 424817 Page 7...
  • Page 8 Step 4 å Insert two METAL PINS (1R) into the exact holes shown in the SHELF (F). å Push the UPRIGHT (D) onto the METAL PINS (1R) in the SHELF (F). Page 8 424817 www.sauder.com/service...
  • Page 9 Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. å Fasten the MOLDINGS (L) to the ENDS (A and B). Tighten (8 used) Arrow eight HIDDEN CAMS. Metal end Surface with HIDDEN CAMS Surface with HIDDEN CAMS www.sauder.com/service 424817 Page 9...
  • Page 10 UPRIGHT (D). Use six BLACK 1-15/16" FLAT HEAD SCREWS (113S). å NOTE: You should start each SCREW a few turns before completely tightening any of them. 113S BLACK 1-15/16" FLAT HEAD SCREW (6 used in this step) Page 10 424817 www.sauder.com/service...
  • Page 11 BASES (H2 and I). Use sixteen BLACK 9/16" LARGE HEAD SCREWS (1S). å NOTE: Be sure the edges of the ANGLE BRACKETS are even with the edges of the BASES. BLACK 9/16" LARGE HEAD SCREW (16 used in this step) (16 used) www.sauder.com/service 424817 Page 11...
  • Page 12 S u r f a c i t h o u t h o l e BROWN 1" FLAT HEAD SCREW These edges (6 used for the FRONT/BACK SMALL BASES) must be even. Page 12 424817 www.sauder.com/service...
  • Page 13 BACK BASES (H2) to the SIDE BASES (I). Use four BLACK BLACK 9/16" LARGE HEAD SCREW 9/16" LARGE HEAD SCREWS (1S) . (16 used in this step) These surfaces should be even. These surfaces should be even. www.sauder.com/service 424817 Page 13...
  • Page 14 HALF DISK, through the PLINTH CAP, and into the LOWER PLINTH. å Repeat this step for the other PLINTH CAPS (R) and LOWER PLINTHS (S). The larger hole BLACK 1-9/16" FLAT HEAD SCREW should be facing up. (4 used in this step) (8 used) Page 14 424817 www.sauder.com/service...
  • Page 15 Fasten the LOWER PLINTHS (S) to the FRONT/BACK BASES (H2) exactly as shown. Use eight BLACK 1-1/4" Now might be a FLAT HEAD SCREWS (7S). good time to refresh your drink. BLACK 1-1/4" FLAT HEAD SCREW (8 used in this step) www.sauder.com/service 424817 Page 15...
  • Page 16 Now, fasten the FRONT/BACK PANELS (G) to the ENDS (A and B). Tighten four HIDDEN CAMS. å Using your hammer, gently tap a CAM COVER (75P) onto each HIDDEN CAM in the FRONT/BACK PANELS (G). (4 used) First, tighten these four HIDDEN CAMS. Page 16 424817 www.sauder.com/service...
  • Page 17 Step 13 å Fasten four HALF DISKS (U) to the COLUMNS (J). Use four SILVER 5/8" FLAT HEAD SCREWS (23S). SILVER 5/8" FLAT HEAD SCREW (4 used in this step) The larger hole should be facing up. www.sauder.com/service 424817 Page 17...
  • Page 18 BLACK 1-1/4" FLAT HEAD SCREW COLUMN. Do not overtighten the screws. (8 used in this step) å NOTE: The COLUMN (J) will rest on the lower HALF DISK. The COLUMN should rest on the lower HALF DISK. Page 18 424817 www.sauder.com/service...
  • Page 19 Fasten the UPPER PLINTHS (N) to the FRONT/BACK PANELS (G). Use eight BLACK 1-1/4" FLAT HEAD SCREWS (7S). Finished edge BLACK 1-1/4" FLAT HEAD SCREW (8 used in this step) Finished edge Finished edge Finished edge www.sauder.com/service 424817 Page 19...
  • Page 20 NOTE: Be sure to position the LIFT TABLE MECHANISMS on the TOP exactly as shown. å Push four BUMPERS (2M) into the TOP (C). BLACK 9/16" LARGE HEAD SCREW (6 used in this step) The holes are closer to this edge. (4 used) Page 20 424817 www.sauder.com/service...
  • Page 21 Fasten the SUPPORT BRACKETS (37G) to the LIFT TABLE MECHANISMS (23M). Use four BLACK WASHERS (13M), four NUTS (24M), and four BLACK 3/4" MACHINE SCREWS (92S). å NOTE: Use the Adjustable Wrench in this step. BLACK 3/4" MACHINE SCREW (4 used in this step) www.sauder.com/service 424817 Page 21...
  • Page 22 ENDS as to not damage any parts. You should start each SCREW a few turns before completely tightening any of them. This hole is used in the next step. Do not use. Page 22 424817 www.sauder.com/service...
  • Page 23 NOTE: The BUSHINGS allow the LIFT TOP to close lightly. Over time, after opening and closing the LIFT TOP, the BUSHING will allow the LIFT TOP to close completely. BLACK 3/4" PAN HEAD SCREW (2 used in this step) www.sauder.com/service 424817 Page 23...
  • Page 24 NUTS (24M), and four BLACK 1-1/4" MACHINE SCREWS (93S). celebrate! With a nap. å NOTE: Use an Adjustable Wrench and a Phillips Screwdriver in this step. BLACK 1-1/4" MACHINE SCREW (4 used in this step) Page 24 424817 www.sauder.com/service...
  • Page 25 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or www.sauder.com/service 424817 Page 25...

  • Page 26: Liste De Pièces

    Modèle 424817 Table basse à dessus relevable Utilisez les instructions d’ a ssemblage en français avec les NOUS CONTACTER EN PREMIER schémas étape par étape du manuel d’instruction en anglais. AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN. Chaque étape en français correspond à la même étape en Nous faisons de notre mieux pour nous assurer que votre meuble anglais.
  • Page 27 Ensuite, fixer les MOULURES DE BASE (K) aux BASES AVANT/ EXCENTRIQUES ESCAMOTABLES. ARRIÈRE (H2). Utiliser six VIS TÊTE PLATE 32 mm (7S). REMARQUE : Les EXCENTRIQUES ESCAMOTABLES dans les PANNEAUX AVANT/ARRIÈRE (G) seront serrées à une étape ultérieure. www.sauder.com/service 424817 Page 27...
  • Page 28 DE LEVAGE DE TABLE (23M). Utiliser quatre RONDELLES D'EXCENTRIQUE (75P) sur chaque EXCENTRIQUE NOIRES (13M), quatre ÉCROUS (24M) et quatre VIS À ESCAMOTABLE dans les PANNEAUX AVANT/ARRIÈRE (G). MÉTAUX 19 mm NOIRES (92S). REMARQUE : Utiliser la Clé Réglable à cette étape. Page 28 424817 www.sauder.com/service...
  • Page 29 REMARQUE : Ne pas trop serrer les VIS. REMARQUE : Les BAGUES permettent le DESSUS RELEVABLE de se fermer légèrement. Au fil du temps après l'ouverture et la fermeture du DESSUS RELEVABLE, la bague permettra au DESSUS RELEVABLE de se fermer correctement. www.sauder.com/service 424817 Page 29...

  • Page 30: Lista De Partes

    EXTREMO DERECHO ..........1 TOPE ..................4 su referencia futura. Si necesita ponerse en EXTREMO IZQUIERDO ..........1 13M ARANDELA NEGRA ...........8 contacto con Sauder en PANEL SUPERIOR ............1 23M JUEGO DE MECANISMO DE cuanto a esta unidad, ELEVACIÓN DE MESA ..........1 PARAL ...................1 refiérase al número...
  • Page 31 Fije el ESTANTE (F) a los EXTREMOS (A y B). Apriete cuatro EXCÉNTRICOS ESCONDIDOS. DELANTERAS/POSTERIORES (H2). Utilice seis TORNILLOS DE CABEZA PERDIDA de 32 mm (7S). NOTA: Los EXCÉNTRICOS ESCONDIDOS en los PANELES DELANTEROS/POSTERIORES (G) se apretarán en un paso siguiente. www.sauder.com/service 424817 Page 31...
  • Page 32 PANELES DELANTEROS/POSTERIORES (G). DE ELEVACIÓN DE LA MESA (23M). Utilice cuatro ARANDELAS NEGRAS (13M), cuatro PERNOS (24M) y cuatro TORNILLOS NEGROS PARA METAL de 19 mm (92S). NOTA: En este paso, utilice la Llave Ajustable. Page 32 424817 www.sauder.com/service...
  • Page 33 NOTA: Los BUJES permiten que el PANEL SUPERIOR DE ELEVACIÓN se cierre ligeramente. Con el tiempo, después de abrir y cerrar el PANEL SUPERIOR DE ELEVACIÓN, el BUJE permitirá que el PANEL SUPERIOR DE ELEVACIÓN se cierre correctamente. www.sauder.com/service 424817 Page 33...
  • Page 34 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 34 424817 www.sauder.com/service...

  • Page 35: Year Limited Warranty

    à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 36 BEFORE MAKING ANY RETURNS TO THE RETAILER. So, how did it go? Dear Valued Customer: Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
