Rheem RAYPAK 019061F Service Instructions

RAYPAK SERVICE INSTRUCTIONS
OUTLET ADAPTER REPLACEMENT, KIT 019061F
FOR AVIA POOL & SPA HEATERS MODELS 264-404
IMPORTANT NOTICE: These instructions are for use by qualified personnel specifically trained and
experienced in the installation of this type of heating equipment and related system components. Installation
and service personnel may be required to be licensed in some states. Persons not qualified shall not attempt
to install this equipment nor attempt repairs according to these instructions.
DANGER - SHOCK HAZARD: Make sure the electrical power to the heater is disconnected to avoid damage
to components, potential serious personal injury or death. Make sure the gas to the heater has been shut off.
WARNING: Make sure water, gas, and power have been turned OFF before making any repairs or servicing
this equipment.
SCOPE: The components in this kit are used for
installation of the Outlet Adapter on AVIA heaters.
KIT CONTENTS:
Description
Adapter-Header Outlet (P/N 800966)
O-Ring Header (P/N 800366)
REQUIRED TOOL:
• Phillips Head Screwdriver
APPROVED
Qty
1
1
UNCONTROLLED DOCUMENT IF PRINTED
P/N 100-10000187 Rev. 00
Effective: 7-29-2022
Replaces: 9-19-2021
Figure 1. Adapter-Header Outlet
