- Page 1 C2424F Instruction Book Digital LED TV Model: C2424F...
- Page 2 Contents Unpacking the TV/ Accessories Installing / Removing the Base Stand Front / Right Side View and Controls Rear View and Sockets Remote Control Installing Batteries in the Remote Control Remote Control Operation Range Making Video and Audio Connections Connecting an AV Device with an HDMI Cable Connecting to an AV Device with a Component (YPbPr) Cable Connecting a Digital Audio Receiver Turning the TV on for the First Time...
- Page 3 Read all the safety instructions carefully before use and keep this instruction manual for future reference. Unpacking the TV/ Accessories ST4x12 Stand TV Set Remote Control Batteries ST4x12 Adapter Stand ST4x12 ST4x12 Adapter Stand Adapter Stand ST4x12 ST4x12 ST4x12 Adapter Adapter Stand Stand Adapter Stand Stand Adapter Quick Start Guide Warranty Card C2424F Instruction Book...
- Page 4 The Unit is VESA-Compliant and designed to be wall mounted with a VESA-Compliant 100 x100 mm mounting kit. 75 x 75 Mount this unit according to the instructions of the wall bracket (not supplied) 75 x 75 100mm Four Mounting Holes Screw size M4 x 8 C2424F Instruction Book...
- Page 5 TV is in standby mode. The LED will alternate between red and green when the PVR timer programming has started in the standby mode. 3. STANDBY Switches the TV on from standby mode. Switches the TV back to standby mode. 4. DVD Insert the DVD disc. C2424F Instruction Book...
- Page 6 USB storage device. 8. Mini YPbPr To connect to a DVD player, Digital Set-Top-Box, or other AV devices with component (YPbPr) video and audio output sock- ets. 9. CI(Common Interface) Allows the insertion of a Common Access Module. Slot C2424F Instruction Book...
- Page 7 Switch to Satellite Mode * Prev Track, File, Day. Prev Track, File, Day. (Medoia, PVR, EPG) (Medoia, PVR, EPG) Pause / Play Pause / Play PVR & Multimedia Show the keyboard in Android mode * PVR & Multimedia DVD Eject C2424F Instruction Book...
- Page 8 Press to Press to enter, press again to exit. enter, press again to exit Fast Reverse Fast Forward Stop PVR and Multimedia Show the OSC menu in blu-ray DVD* Start recording C2424F Instruction Book...
- Page 9 TV and within 60° in front of the TV. The operating distance may vary depending on the brightness of the room. Remote Code: 0156 To use your sky remote control with this TV follow the instructions given with the sky remote to programme different codes. C2424F Instruction Book...
- Page 10 HDMI and then press the OK button to confirm. Game Console Set-top Box Blu-ray Player/DVD Player/Recorder Although this TV is able to connect to an HDMI device, it is possible that some devices may not operate correctly. C2424F Instruction Book...
- Page 11 Video Camera Game Console Set-top Box Antenna button on the remote control to display the Source List. cable ▲▼ buttons to select YPbPr and then Press the Use the OK button to confirm. Satellite Receiver Blu-ray Player/DVD Player/Recorder C2424F Instruction Book...
- Page 12 SOURCE button on the remote control to display the Source List. Use the ▲▼ buttons to select AV and then press the OK button to ocnfirm. DVD Player/Recorder Video Camera Game Console Set-top Box Satellite Antenna cable Satellite Receiver C2424F Instruction Book...
- Page 13 Long-term exposure to loud music may cause hearing damage. It is best to avoid Mini YPbPr Mini AV extreme volume when using earphones, especially for extended periods. Rear View of TV Mini YPbPr Mini AV Earphones Cable (not included) C2424F Instruction Book...
- Page 14 If this is the first time you are turning on the TV and there are no programs in the TV memory, the Quick Start menu will Start menu will appear on the screen. There are 4 steps as follow: appear on the screen. There are 4 setups as follow: C2424F Instruction Book...
- Page 15 Press the VOL +/- button on the TV or on the remote control to adjust the volume. • If you wish to switch the sound off, press the Mute button. Press the Mute button again or the VOL+ or - button to resume audio listening. Mute Mute Mute Mute Mute Mute Mute Mute C2424F Instruction Book...
- Page 16 • Cool: Increases the blue tint • Warm: Increases red tint Aspect Ratio Press the buttons to cycle among aspect ratio: 4:3 / 16:9 ▲▼ Auto / Zoom1 / Zoom2 and then press the OK button to confirm. C2424F Instruction Book...
- Page 17 Press the ◄► buttons to select to reduce the noise level of the connected Reduction device: Off / Low / Middle / High and then press the Menu button to confirm. 3. Press the Menu button to return to the previous menu. Press the Exit button to exit the menu. C2424F Instruction Book...
- Page 18 Press the buttons to select an audio language or audio format if ▲▼ available and then press the ◄► buttons to select sound track between Left, Right and Stereo. Press the OK button to confirm and exit. C2424F Instruction Book...
- Page 19 3. Press the Menu Button to return back to the main menu. 3.Press the Menu button to return back to the main menu. 4.Press the Exit button to exit the menu. 4. Press the Exit button to exit the menu. 4.Press the Exit button to exit the menu. C2424F Instruction Book...
- Page 20 Press ◄► buttons to start the manual training. Fine-Tune Press ◄► buttons to make manual fine tuning adjustments. 3. Press the Menu button to return back to the main menu. 4. Press the Exit button to exit the menu. C2424F Instruction Book...
- Page 21 22KHz Satellite signal switch). Press ◄► to select Auto/On/Off. No. The current list number of the selected satellite Satellite Transponder: Press OK button to edit the transponder. name. The No. cannot be edited. C2424F Instruction Book...
- Page 22 Press Yellow button to Add a New Satellite. Add Transponder Press the Yellow button to delete the Transponder. Frequency : Set the downlink frequency. Symbol (ks/s): Set the Symbol Rate. Polarity: Set the polarity (horizontal or vertical). C2424F Instruction Book...
- Page 23 2.Press the menu button to select the CHANNEL menu. 3.Press the left/right buttons to select Software Update(USB) and then press the OK button to update software. 4.When the updating is completed,the unit will be reset to standby mode. C2424F Instruction Book...
- Page 24 ON or OFF. After selecting ON, the front panel buttons TV/AV/Menu/ CH+/CH-/VOL+/VOL- of the device will be locked. 3. Press the Menu button to return back to the main menu. 4. Press the Exit button to exit the menu. C2424F Instruction Book...
- Page 25 Press up/down buttons to select the “Default Volume” option and then press right button to set the default volume. Clear Lock Press up/down buttons to select the “Clear Lock” option and then press right button to enable it.All hotel settings will remain disabled until you enable the Hotel Lock again. C2424F Instruction Book...
- Page 26 Press up/down buttons to select the display time of the on-screen menu:5s/10s/15s/20s/ by selecting Never. 25s/30s/Nevel and then press the OK button to confirm. OSD Off Timer Press up/down buttons to select the display time of the on-screen menu:5s/10s/15s/20s/ 25s/30s/Nevel and then press the OK button to confirm. C2424F Instruction Book...
- Page 27 Allows you to test the speed of the USB device or Format the USB device. Allow you to set HDMI CEC functions. PVR File System Allows you to test the speed of the USB device or Format the USB device. C2424F Instruction Book...
- Page 28 This is normal and the starting time may vary depending on the brand and the memory size of the connected hard disk. • Disconnect the USB storage device if it is not in use. • USB output: DC 5V 500mA C2424F Instruction Book...
- Page 29 OK button to show the navigation option menu on the bottom of the screen or press stop button to return to files. C2424F Instruction Book...
- Page 30 Play: Play the photo. Play: Play the photo. Prev./Next: Go to on a picture/Go to the next picture. Prev./Next: Go to on a picture/Go to the next picture. Stop: Stop auto turning pages. Stop: Stop auto turning pages. C2424F Instruction Book...
- Page 31 Play/pause the background music of your choice. Playlist: Display the playlist on the screen. Playlist: Display the playlist on the screen. Info: Display the information of the text file. Info: Display the information of the text file. C2424F Instruction Book...
- Page 32 This is selected when the player is connected to a normal TV. Wide-screen images are shown on the screen, with black belt on the top and bottom. • Wide This is selected when the player is connected to a wide-screen TV. C2424F Instruction Book...
- Page 33 • Stereo A disc recorded multi channel soundtrack, the output signal will be incorporated to stereo. Dolby Digital Setup Dynamic This option is used to set the compression ratio in order to control the sound (Volume) contrast. C2424F Instruction Book...
- Page 34 The user can change the password that is required when the user wants to change the Age Contol Guade in the Parental Lock function. Note: Default password is 123456. Default The user can load the original factory setting by choosing Reset and press OK button. C2424F Instruction Book...
- Page 35 Clean the disc surface with a soft, dry cleaning cloth, wipe the disc surface gently and radically from cen- ter toward the outer edge. Do not apply thinner, alcohol, chemical solvent, or sprays when cleaning. such cleaning fluids will perma- nently damage the disc surface. C2424F Instruction Book...
- Page 36 • Check aerial (Change the position of the aerial.) No pictures when connecting HDMI • Check if the input source is HDMI. Picture appears in wrong ratio • Adjust the Aspect Ratio settings in the PICTURE menu. C2424F Instruction Book...
- Page 37 We suggest you have an aerial survey done before getting an aerial upgrade. • Talk to your retailer or contact your local aerial installer. C2424F Instruction Book...
- Page 38 Aspect Ratio 480i:720 x 480 480P:720 x 480 576i: 720 x 576 576P: 720 x 576 4:3 / 16:9 / Zoom1 / Zoom2 / 720P: 1280 x 720 Just Scan 1080i: 1920 x 1080 1080P: 1920 x 1080 C2424F Instruction Book...
- Page 39 The differ- ence between the power consumed when receiving a high bit rate channel with the volume at max and a low bit rate channel with volume at zero is usually less than 3 watts. C2424F Instruction Book...
- Page 40 10cm 10cm 10cm • To prevent screen burn if viewing any of the above for long periods of time, reduce contrast and brightness when viewing. Once burn-in occurs it will never disap- pear completely. C2424F Instruction Book...
- Page 41 Packaging materials are not toys. Please keep away triangle is intended to alert the user to the from children. Plastic bags can cause suffocation when presence of important operating and mainte- pulled over the head. nance (servicing) instructions in the manual accompanying the unit. C2424F Instruction Book...
- Page 42 This appliance complies with European Safety and Electrical directives. It fullfils the following EU regulations: EN 55032:2015 EN 55032:2015 EN IEC6100-3-2:2019 EN IEC6100-3-2:2019 EN 6100-3-3:2013 EN 6100-3-3:2013 EN 55035:2017 EN 55035:2017 EN 60065:2014+A11:2017 EN 60065:2014+A11:2017 C2424F Instruction Book...
