PART NAMES AND LOCATIONS IN ACCESSORY BAG: USER MANUAL, WARRANTY CARD,Ice Scraper As the manufacturer holds the authority to redesign or modify its products without notice: Any modifications or upgrades of our products will result in this Freezer varying slightly from this manual but the functionality will remain the same to that as set out within this manual.
• Report any notable defects with the appliance to Chiq or retailer as soon as it is noted. Failure to do so can result in a non-warranty claim. Keep all packaging materials in a safe location until the unit has been installed properly.
Page 4
R600a WARNINGS NOTE: This model uses R600a flammable refrigerant in its sealed system. The following must be observed for your safety: R600a Refrigerant Warning • This appliance contains 0.068KG R600a refrigerant which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect.
INSTALLATION INSTRUCTIONS Before Using the Freezer • Remove the exterior and interior packing. • Before connecting the Freezer to a power source, let the unit stand upright for approximately 4 hours to mitigate the possibility of a malfunction in the cooling system from improper handling during transportation.
Page 6
OPERATING INSTRUCTIONS STARTING Do not load the appliance immediately after it is switched on. Wait for about 4-6 hours until the freezer reaches correct temperature. Control panel When the system is powered on for the first time, all LED indicators and the digital display light up, and will restore to normal display in 2s.
Page 7
Fast Freeze When the “Fast Freeze” function is activated, the freezer temperature is automatically set at -32 ℃, and after running for 26 hours, the Fast Freeze function will be turned off. Cooling down the freezer temperature in a rapid manner is beneficial to the prevention of food nutrition against loss and the preservation of freshness.
Page 8
Frost or ice on the top cabinet edge area or near the door hinge The appliance has special design on the seal design. There are small holes on the door seal near the hinge area. They will release the air pressure quickly and the door can be opened again quicker if need to.
GENERAL CARE AND MAINTENANCE Cleaning the Freezer • Upon installation of your new appliance, it is recommended that it be cleaned thoroughly and properly maintained thereafter. • Turn off the Freezer and then unplug the unit from the wall outlet. •...
TROUBLESHOOTING GUIDE Problem Solution Power cord isn’t plugged in properly. The freezer has no power The circuit breaker tripped or a blown fuse. Try a different power point. The room temperature is hotter than normal. A large amount of food has been added to the Freezer. ...
Page 11
The doors will not close Clean the seals and make sure they are dry before properly. closing the door/s. The storage basket and/or shelves are out of position. For any enquiries, please call the CHiQ Cusotmer care on: 1300 796 688...
