Limited Lifetime Warranty, contact ETS, Inc. at 1-800-449-3605, and ask for the Technical Service Department. ETS, Inc. shall not be liable for loss of use, loss of time , inconvenience, rental or substitute products, loss of business, loss of income, or any other incidental or consequential damages.
elcome Congratulations on your purchase of this technologically advanced sun tanning unit. It has been designed to provide years of dependable service for you. Please read all the instructions in this booklet before installing and using the unit. Always be sure to observe all safety precautions.
Page 4
afety Information DANGER Ultraviolet radiation. Follow instructions. Avoid overexposure. As with natural sunlight, overexposure can cause eye and skin injury and allergic reactions. Repeated exposure may cause premature aging of the skin and skin cancer. WEAR PROTECTIVE EYEWEAR; FAILURE TO MAY RESULT IN SEVERE BURNS OR LONGTERM INJURY TO THE EYES. Medications or cosmetics may increase your sensitivity to the ultraviolet radiation.
Safety Information DANGER Rayonnement ultraviolet. Veuillez suivre les instructions. Évitez une exposition excessive : tout comme pour les rayons du soleil, une exposition excessive peut causer des blessures aux yeux et à la peau et provoquer des réactions allergiques. Une exposition répétée peut causer le vieillissement prématuré de la peau et provoquer le cancer de la peau. PORTEZ DES LUNETTES PROTECTRICES: LE NON-RESPECT DE CETTE CONSIGNE DE SÉCURITÉ...
nstallation Unpacking and Inspection Record the serial numbers of the canopy and bench in the area provided at the back of this manual. This information will Your sunbed comes in two cardboard car- be required whenever you call customer tons, one for the bench and one for the service.
Installation - Pre-Installation Planning Pre-Installation Planning Before you begin to assemble your sunbed, you should observe the following pre- installation considerations. WARNING CAUTION Shock hazard. Use of a voltage source above 230V AC may prevent proper operation of the sunbed and Disconnect power before servicing.
Installation - Assembly Procedures Assembly Procedures Allen-head Bolt 5/16” x 1” Hardware Inventory Quantity 2 Use the utility knife to cut open the hard- ware box and remove the small bag of hardware. In addition to a small Allen 5/16” Metal Washer wrench and pillow, make sure you have Quantity 2 the following hardware items.
Page 9
Installation - Assembly Procedures Attaching Legs to Bench 1. Using six 5/16” x 1” bolts and the six larger 5/16” washers (pre-installed), Lay the bench upside down on the floor. attach the stand legs with the skirt Locate the two stand legs and attach to the mounting holes toward the back of bench as shown below.
Page 10
Installation - Assembly Procedures Assembling Skirt on 24S series (for 28LE series, see next page) 1. Position the side skirts at either end of the base. Install two #8 x 1/2” screws (packaged with the skirt kit) through the Install screws here pre-drilled holes of the side skirt into the back of the leg support.
Page 11
Installation - Assembly Procedures Assembling Skirt on 28LE series (for 24S series, see previous page) 1. Position the side skirts at either end of the base. Install two #8 x 1/2” screws through the pre-drilled holes of the side Install screws here skirt into the back of the leg support.
Page 12
Installation - Assembly Procedures Attaching Hinge Brackets to Bench (All) 2. Place the bushings into the hinge brackets as shown below. Turn bench right side up on the floor. Place so that the electrical connector is facing toward the wall outlet. Locate the two hinge brackets and identify the left and right brackets.
Page 13
Installation - Assembly Procedures Attaching Canopy to Bench 1. Lift the canopy and hold it between the hinge brackets. You may want to use some of the cardboard packing, laid across the bench, to support the canopy. 2. Insert the 5/16” x 1 1/2” bolts with the nylon washers into both hinge brackets.
Page 14
Installation - Assembly Procedures Attaching Gas Springs 3. Lift and lower canopy a few times to lubricate gas springs for optimum 1. The gas springs are shipped with performance. locking clips installed. Use a screw- driver to pry back the locking clips on the gas springs as they are installed.
Installation - Making Electrical Connections Making Electrical Connections WARNING Shock hazard. Be sure AC power is disconnected before connecting cables. 1. Your sunbed is designed to communicate with remote control devices. The remote control is optional and is not included with your sunbed.
Installation - Remote Connections Remote Connections T-Max® Products The T-Max® remote systems offer the ultimate in sunbed control, while allowing the tanner Your sunbed incorporates advanced circuitry easy straightforward operation. Your sunbed is allowing it to connect and communicate with configured to directly connect to this system.
Page 17
Installation - Remote Connections T-Max® 1A and 3A Remote Systems Setting the address manually In single sunbed installations, the T-Max® 1A Before connecting your sunbed to the T-Max® and 3A can offer the same control as the T- Manager or T-Max® 1A or 3A, the address of Max®...
Page 18
Installation - Remote Connections Remote systems using a Control Relay Most non-T-Max® remote systems control the sunbed by the use of a relay. The relay oper- ates the sunbed by connecting and discon- necting a pair of wires leading from the sunbed.
peration Before You Tan DANGER Some medication may increase your Before using your sunbed, please note the sensitivity to ultraviolet light. It is rec- following important precautions. ommended that you consult a physi- cian before using this sunbed if taking •...
Operation - Using Your Sunbed Using Your Sunbed (When connected to the T-Max® Manager or T-Max® 1A or 3A.) WARNING A Timer display - Displays remaining time. Wear protective eyewear. B Timer button - Turns bed on. Timer dis- Failure to may result in severe burns or longterm injury to the eyes.
Page 21
Operation - Using Your Sunbed Using Your Sunbed (When used as a stand alone unit or when connected to a remote system using a control relay.) A Timer display 1. Press the timer button (B) to begin the tan- - Displays remaining time. ning session.
are and Maintenance Cleaning After Use Thorough Periodic Cleaning Clean and disinfect your tanning bed’s Introduction bench and canopy after each use. Use a The cooling fans draw air through the bed non-abrasive disinfectant cleaner that does and over time will cause a dust buildup on not contain ammonia or ammonia deriva- the lamps and reflectors.
Care and Maintenance - Hour Counter Hour Counter Mechanical Inspection Your tanning bed has been built for years of This sunbed incorporates an ingenious service. To ensure trouble-free operation hour counter function into the timing cir- throughout its life, inspect the unit’s cuitry.
Care and Maintenance - Replacing Lamps Replacing Lamps After changing the lamps, replace the acrylic shields by reversing the above directions. Close the hinged profile by Introduction pushing it back into place until it snaps To be assured of maximum tanning effec- tight.
Page 25
Care and Maintenance - Replacing Lamps Removing/Replacing Lamps Recommended Replacement Lamps After removing the acrylic shields, replace We recommend using the lamps specified lamps as follows. below. Use of lamps other than those specified below, or compatible replace- Step 1 Grasp a lamp at one end and at ments, is a violation of Federal regulations the middle, then turn the lamp a and will void your warranty.
Page 26
Care and Maintenance - Replacing Lamps Removing/Replacing SolarMax™ IFT Note! Never take hold of the lamp such Face Tanner Lamps on F Models that your fingers are in contact with the lamp glass. Finger oils will greatly reduce After removing the canopy acrylic shield, the lamp’s operational life.
roubleshooting Problem Solution Sunbed not tanning 1. Clean sunbed, see Thorough Periodic Cleaning. 2. Ensure supply voltage is between 208 and 230V AC. 3. Replace lamps if lamp hours are greater than 800hrs. 4. Replace acrylic. Lamps fail to light and timer dis- 1.
Page 28
Care and Maintenance - Replacing Lamps Problem Solution My bed won’t work with the T- 1. The sunbed must first be set to a unique address, see Remote Max® Manager remote system Connections. 2. The bypass plug may be installed in the series in an inappro- priate location.
Parts List This is a list of parts which may be replaced by the consumer. Care should be taken when replacing anything related to electrical wiring. We recom- mend contacting a professional electrician. When calling for parts, first state your bed model as M-24S, M-24SF, M-28LE, M-28LET, or M- 28LE2F.
Page 35
24SF Size Weight (Pounds) Minimum Room Size 6’ x 8’ 6’ x 8’ Electrical - Voltage (AC) Amperage Circuit Breaker (Amps) Outlet (NEMA standard) 6-20R 6-20R Main Lamps Velocity® 100W Velocity® 100W/80W or Golden Tan™ 100W or Golden Tan™ 100W/80W Ballasts 100W 100W/80W...
Page 36
28LE 28LET 28LE2F Size Weight (Pounds) 329 lbs 352 lbs 376 lbs Minimum Room Size 6’ x 8’ 6’ x 8’ 6’ x 8’ Electrical - Voltage (AC) Amperage Circuit Breaker (Amps) Outlet (NEMA standard) L6-30R L6-30R L6-30R Main Lamps Velocity®...
