DANGER
Ultraviolet radiation. Follow instructions. Avoid overexposure. As with
natural sunlight, overexposure can cause eye and skin injury and
allergic reactions. Repeated exposure may cause premature aging of the skin and skin cancer.
WEAR PROTECTIVE EYEWEAR; FAILURE TO MAY RESULT IN SEVERE BURNS OR
LONGTERM INJURY TO THE EYES. Medications or cosmetics may increase your sensitivity
to the ultraviolet radiation. Consult physician before using sunlamp if you are using medications
or have a history of skin problems or believe yourself especially sensitive to sunlight. If you do
not tan in the sun, you are unlikely to tan from the use of this product. Children, the elderly, or
fair skinned people who always burn easily and either never tan or tan minimally should not use
this equipment.
To use, lie down under canopy and pull down as far as adjustment will allow. Do not use without
clear plastic panels in place. Untanned persons should not tan on consecutive days during their
first week of tanning. Never tan more than once a day. Tanning normally appears after the first
few sessions and maximizes after approximately four weeks. Tan once or twice per week there-
after to maintain appearance. Persons already having a base tan may begin at advanced levels
corresponding to the extent of their base tan.
Skin Type:
I
Sensitive Skin (Burns easily and severely and does not tan.)
II Light Skin
(Burns easily and severely and tans minimally.)
III Normal Skin
(Burns moderately and tans average.)
IV Dark Skin
(Burns minimally, tans easily and above average.)
RECOMMENDED EXPOSURE TIMES IN MINUTES
Level 1/Week 1
Skin Type: 1st-3rd Sessions
I Sensitive
II Light
4
III Normal
6
IV Dark
8
MAXIMUM EXPOSURE TIME IS 20 MINUTES
New lamps emit approximately 10% more ultraviolet radiation during the first 50 hours of
Operation. Recommended tanning times should therefore be reduced by approximately 10%
during that period.
WARNING: • Read all instructions before using this sunlamp product. All persons in the room should wear
protective eyewear when lamps are on. Required eyewear: Ultra SunGlobes®, special-eyez, or other dark-
tinted eyewear that meet 21 CFR 1040.20 guidelines. Other eyewear may not provide adequate protection.
The following lamps have been certified for use in the Lumagen™ 26C:
Velocity® Wolff® Model VEL 71-T12-100W
Lumalite C™ Wolff® P/N 27743-01
DermaSun™ Wolff® P/N 27744-01
DISCONNECT POWER CORD BEFORE ATTEMPTING TO CLEAN, RELAMP,
OR ENGAGE IN THE MAINTENANCE OF THIS PRODUCT.
THIS EQUIPMENT MUST BE EARTH GROUNDED.
This product is in conformity with performance standards for sun lamp
products under 21 CFR PART 1040.20 and ANSI/UL Standard 482.
Electrical Requirements
Your sunbed operates from a 220V AC source. The 26C requires a NEMA
6-20R electrical outlet (below) on a dedicated circuit capable of pro-
viding 20 Amp service, installed in the room in which you will use the
unit. We recommend installation by a professional electrician. The out-
let must be earth grounded.
Level 2
Level 3
Level 4
Level 5
NOT RECOMMENDED FOR TANNING
8
12
16
10
15
20
12
16
20
20 AMP NEMA #6-20R
RECEPTACLE
Shock hazard.
Disconnect power before servicing or removing any protec-
tive covers.
Do not operate this device near water or while you are wet.
Some medications may increase your sensitivity to ultraviolet light. It
is recommended that you consult a physician before using this
sunbed if taking any medication or if you suspect that your skin might
be especially sensitive to sunlight.
Wear protective eyewear.
Failure to may result in severe burns or longterm injury to the eyes.
Use of a voltage source above 230V AC may prevent proper operation
of the sunbed and could cause damage and void the warranty.
Air from the room is used to cool the sunbed. Maximum ambient room
temperature should be 80°F. Place your sunbed no closer than 6" from
any wall. Make sure nothing obstructs the airflow into the sunbed's
endcaps or out of the fan openings. A poorly ventilated room may
cause the unit to become hot and cause discomfort to the user.
Unpacking and Inspection
20
20
The canopy box contains the canopy and a pair of gas springs. The
20
bench box contains the bench, assembly hardware, stand legs and skirt.
Inspect the items and make sure they are free from any visible damage.
Report the extent of any damage to the transportation company.
Hardware Inventory
Allen-head Bolt 5/16" x 1"
Quantity 2
5/16" Metal Washer
Quantity 2
Bushing
Quantity 2
Allen-head Bolt 5/16" x 1 1/2"
Quantity 2
Nylon Washer
Quantity 2
88465
Screw #10-32 x 1/2"
Quantity 4
Nut #10-32 Locking
Quantity 4
DANGER
DANGER
WARNING
CAUTION
(These items and a small pillow)
Skirt Top Bracket
Quantity 3
Hinge Brackets
(1) left, (1) right
Hex (Allen) Wrench
Quantity 1
Safety Goggles
Quantity 1
Skirt Mounting Bracket
Quantity 2
Skirt Reinforcing Plate
Quantity 2
27771-01A - Page 1
