Arbortech MINI-GRINDER Owner's Instruction Manual

Hide thumbs Also See for MINI-GRINDER:

Advertisement

Quick Links

Download this manual
MINI-GRINDER
OWNER'S INSTRUCTION MANUAL
Thankyou for purchasing an Arbortech Product.
Your Arbortech Mini Grinder has been designed & manufactured to
provide you with the highest satisfaction in performance, durability
TO SAVE TIME AND MONEY
and safe operation.
READ THIS MANUAL
TM
Double
Insulated

Advertisement

loading
Need help?

Need help?

Do you have a question about the MINI-GRINDER and is the answer not in the manual?

Questions and answers

Related Manuals for Arbortech MINI-GRINDER

Summary of Contents for Arbortech MINI-GRINDER

  • Page 1 MINI-GRINDER OWNER’S INSTRUCTION MANUAL Thankyou for purchasing an Arbortech Product. Your Arbortech Mini Grinder has been designed & manufactured to provide you with the highest satisfaction in performance, durability and safe operation. Double Insulated READ THIS MANUAL TO SAVE TIME AND MONEY...
  • Page 2 TABLE OF CONTENTS Rules for safe operation of electrical equipment Knowing your tool Unpacking and Assembly Operation Maintenance Accessories & Spare Parts Other Products Technical Information Please read these instructions before you use your Mini-Grinder.
  • Page 3 Rules for safe operation of electrical equipment 2 The Arbortech Mini Grinder is designed and built to meet and exceed Australian and International Safety Standards. Use only Arbortech approved or other qualified service centres for the servicing and/or repair of this tool. For further assistance contact Arbortech.
  • Page 4 3 Rules for safe operation 10. Secure the workpiece: to avoid serious personal injury. 11. Do not remove guards or shields: these are designed to increase operator safety. 12. Store idle tools in dry, out of reach places: When not in use the tool should be stored in a dry, frost free location not within the reach of children.
  • Page 5 30. Outdoor extension cords: when using the Mini Grinder outdoors, use only approved extension cords. 31. Use only correct blades: use only Arbortech replacement blades with this tool. Only use correct sized and intact washers. Use blades which are suitable for the purpose.
  • Page 6 Note: text, diagrams and data are correct at time of printing. In the interests of continuous improvement of our products, technical specifications are subject to alteration without prior notice. *WARNING: DO NOT REMOVE THE MINI-GRINDER EXTENSION ARM FROM THE MOTOR. See Warranty Card For Conditions...
  • Page 7 Knowing your tool (cont’d) 6 *Spindle Lock *Mini-Grinder Spindle Lock On/off switch *Belt Tensioning Mounting plate Unpacking and assembly 1. Remove the Mini Grinder from its box. Inspect to ensure that no damage has occurred during shipping. If damaged, report to the retailer immediately.
  • Page 8 Place top washer over blade and secure using the cutter clamping bolt (as shown in fig.6). Check that the blade is sitting flat against the small pulley. • Also packed with the Mini-Grinder is a set of 4 assorted Mini-Sanders (40, 60, 80 & Fig.6 120 grit).
  • Page 9 • Ensure the machine is running BEFORE contacting the material, to be worked on. • To sand, polish or scrub, hold the Mini-Grinder horizontally. (as shown in fig.9). Fig.9 • Use the Mini Woodcarver Blade to cut or remove wood and plastics.
  • Page 10 9 Operation To trench cut, hold the Mini-Grinder vertically and simultaneously lower into the wood and pull towards you. (as shown in fig.10) SHOWING ANGLE & DIRECTION OF CUT 25-30 is a comfortable working angle. 25-30 Angle ✓ Fig.10 • Use the bottom edge of the blade (as shown in fig.10)
  • Page 11 (as shown in fig.14) Sharpening Angle • Checking adaptor plate Ensure that the Mini-Grinder adaptor plate is Fig.14 always mounted securely. If loose, tighten the three adaptor plate screws as shown in fig.15.
  • Page 12 DO NOT OVER TENSION THE BELT If replacing the belt ensure that the “V” shape sides of the belt are on the inside (as shown in fig.19). Replacement belts (MIN003) are available through Arbortech Pty Ltd (see address on back).
  • Page 13 If so use a soft brush to remove any accumulated dust. Wear safety glasses when doing this. Accessories & Spare Parts MIN001 Accessories Available for the Mini-Grinder MIN001 Mini-Woodcarver Blades x 2 MIN002 4mm Sharpening File MIN006 MIN003 Replacement Pulley Belt MIN004 Bearing &...
