MINI-GRINDER
OWNER'S INSTRUCTION MANUAL
Original instructions provided by Arbortech Industries
Thank you for purchasing an Arbortech Product.
Your Arbortech Mini Grinder has been designed & manufactured to
provide you with the highest satisfaction in performance, durability
FOR SAFETY READ THE MANUAL
BEFORE USING THIS TOOL
and safe operation.
MIN.PK.BOOK300
Double
Insulated
REV_060417

Advertisement

loading
Need help?

Need help?

Do you have a question about the MIN.FG.300.00 AU and is the answer not in the manual?

Questions and answers

Summary of Contents for Arbortech MIN.FG.300.00 AU

  • Page 1 MINI-GRINDER OWNER’S INSTRUCTION MANUAL Original instructions provided by Arbortech Industries Thank you for purchasing an Arbortech Product. Your Arbortech Mini Grinder has been designed & manufactured to provide you with the highest satisfaction in performance, durability and safe operation. Double...
  • Page 2: Table Of Contents

    Please read this manual carefully to ensure your safety and correct operation and care of the machine. If you are using the Power Chisel correctly, it will provide you with years of reliable service and save you time and money. TABLE OF CONTENTS Page No.
  • Page 3: Rules For Safe Operation Of Electrical Equipment 2

    The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. The Arbortech Mini Grinder is designed and built to meet and exceed Australian and International Safety Standards. Use only Arbortech approved or other qualified service centres for the servicing and/or repair of this tool.
  • Page 4 ELECTRICAL SAFETY • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. • Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
  • Page 5 • Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations • Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
  • Page 6: Knowing Your Tool

    1.233 m/s2 120V, AC, 60Hz Noise emission: 100.7 dB(A) Model: MIN.FG.300.00 AU | MIN.FG.300.00.20 US | MIN.FG.300.00.40 UK | MIN.FG.300.00.20 EU AUST. APPROVAL SGSEA/120903 CE-Declaration of Conformity: We declare under our sole responsibility that this product is in conformity with the CE Standards.
  • Page 7: Unpacking And Assembly

    Knowing your tool (cont’d) 6 Spindle Lock Mini-Grinder Spindle Lock On/off switch Belt Tensioning Fig.4 Mounting plate Unpacking and assembly 1. Remove the Mini Grinder from its box. Inspect to ensure that no damage has occurred during shipping. If damaged, report to the retailer immediately.
  • Page 8: Operation

    7 Operation BLADES 1 To change blades place a flat head screwdriver into the Mini Grinder spindle lock and hold (seen in fig .5) then unscrew the cutter clamping bolt by using the Allen key provided and Fig.5 remove blade ( as shown in fig 6) 2 Place new blade securely on the small pulley.
  • Page 9 8 Operation (cont’d) DIAMOND BLADE & MINI INDUSTRIAL BLADE Step Washer Required Stepwasher To change blades with Diamond or Mini Industrial Blade follow step 1 as for Fig.8 BLADES on OPERATION ( page 7 ) to remove blade (seen in fig .5) then unscrew the cutter clamping bolt by using the Allen key provided and remove blade (as shown in fig 6)
  • Page 10 Operation (cont’d) 9 Warning: Always wear correct safety clothing, including ear, eye and lung protection. • The Mini Grinder should always be used with two hands, placing the left hand on the auxiliary handle and the right on the tool body.
  • Page 11 10 Operation (cont’d) To trench cut, hold the Mini-Grinder vertically and simultaneously lower into the wood and pull towards you. (as shown in fig.13) SHOWING ANGLE & DIRECTION OF CUT 25-30° is a comfortable working angle. 25-30 Angle Fig.13 • Use the bottom edge of the blade (as shown in fig.13) And not as in fig.14.
  • Page 12: Maintenance 11

    Maintenance 11 Sharpening Angle Fig.15 Fig.16 Cleaning the grills and switch Regulary check to see if any dust or foreign matter has entered the grills positioned on the front and back of the motor or under the switch (as shown in fig.17). If so use a soft brush to remove any accumulated dust to clean grills and Fig.17 switch.
  • Page 13 DO NOT OVER TENSION THE BELT If replacing the belt ensure that the “V” shape sides of the belt are on the inside (as shown in fig.20). Replacement belts (MIN.FG.003) are available through Arbortech Pty Ltd (see address on back).
  • Page 14: Accessories & Spare Parts

    Other Products 13 Accessories & Spare Parts Accessories Available for the Mini-Grinder Mini Wood Carver Blade MIN.FG.001 Mini-Woodcarver Blades x 2 MIN.FG.002 4mm Sharpening File MIN.FG.003 Replacement Pulley Belt MIN.FG.004 Bearing & Spindle Assembly Sanding MIN.FG.006 Mini-Sanders 4x assorted sanders Disk MIN.FG.008 4 x 40 Grit Mini-Sanders MIN.FG.009 4 x 60 Grit Mini-Sanders...
  • Page 15 The Arbortech Mini TURBO Kit is a revolution in wood sculpting. It can be used either directly on the Arbortech Mini GrinderTM or fitted to an angle grinder using the supplied extension adapter. This is an ideal tool to be used freehand or with guides and templates for accuracy.
  • Page 16 Other Products 15 Product Features Contour Random The Arbortech Contour Random Sander Sander is a revolutionary tool for sanding deep profiles, contours and detail work. It is designed to be used directly on any standard 100mm (4”) or 115mm (4 1/2”) angle grinder. Areas that previously could only be sanded by hand can now be finished rapidly.
  • Page 20 NOTE: Motor may differ from that shown on box depending on specifications required for your country. ARBORTECH PTY LTD • 67 WESTCHESTER ROAD • MALAGA • 6090 PERTH • WESTERN AUSTRALIA TEL: 08 9249 1944 • FAX: 08 9249 2936 U.S.A.
