Model 66305 - 3 Ton Long Reach Floor Jack
Max. Capacity: 3 Tons
Application: Designed to lift a wide range of motor vehicles.
WARNING
!
Read this material before using this product. Failure to do so can result in serious injury. The owner and/or operator
shall have an understanding of the product, its operating characteristics, and safety operating instructions before
operating the PALD. Safety information shall be emphasized and understood. If the operator is not fluent in English, the
product and safety instructions. shall be read to and discussed with the operator in the operator's native language by
the purchaser/ owner or his designee. making sure ther operator comprehends their contents. SAVE THIS MANUAL.
Visit our website at: www.jackco.com
Email our technical support at: techsupport@jackco.com
Ver. 0722
Advertisement
Table of Contents
Related Manuals for Jackco 66305
Summary of Contents for Jackco 66305
- Page 1 Model 66305 - 3 Ton Long Reach Floor Jack Max. Capacity: 3 Tons Application: Designed to lift a wide range of motor vehicles. WARNING Read this material before using this product. Failure to do so can result in serious injury. The owner and/or operator shall have an understanding of the product, its operating characteristics, and safety operating instructions before operating the PALD.
-
Page 2: Specifications
For Your Safety Read these safety instructions carefully and keep this manual in an easy to find place as you may need to use it again. Non-compliance with these rules may result in injury or damage to the jack or vehicle. Do not modify the jack in any way. - Page 3 Assembly Please refer to the exploded view drawing in this manual in order to identify parts: 1. Assemble the two handle halves together by depressing the spring-loaded button on the knurled handle section (#17) and inserting the upper handle section into the lower section (#18). The spring-loaded button should engage with the hole in the lower handle section.
-
Page 4: Maintenance
Maintenance Important: Both the maintenance and repair of the jack may only be performed by qualified persons, who have suffcient knowledge of the hydraulic system used in these jacks. Lubrication: Put grease in fitting on base. Regularly lubricate the moving parts in the wheels, arms, handle and pump roller pin ever 3 months. -
Page 5: Troubleshooting
Troubleshooting Caution: To prevent personal injury, all inspection, maintenance, and repair procedures must be performed when the jack is free of load. Trouble Solution 1. The release valve is not closed. Turn the valve clockwise tightly. If this does not work, remove handle, lubricate handle receptacle and handle end, then retry. -
Page 6: Parts List
Parts List PART NO. QUANTITY DESCRIPTION PART NO. QUANTITY DESCRIPTION RETAINING RING CONNECT ROD WASHER HANDLE YOKE ROLLER FRONT WHEEL RETAINING RING M12 FRAME SPRING WASHER M18 RETAINING RING M25 BOLT-HANDLE YOKE SPRING WASHER M16 COVER PLATE NUT M16 RETURN SPRING SPRING WASHER M12 POWER UNIT ASSEMBLY SCREW M12X25... - Page 7 Model 66305 Power Unit *Part numbers are for your reference only, not all parts are available separately. Note: Default unit of measurement is metric, in mm. PART NO. QUANTITY DESCRIPTION PART NO. QUANTITY DESCRIPTION LOWER GASKET CUP SEAL RESERVOIR BACKUP WASHER UPPER GASKET O-RING 10.2MM X 2.65MM...
-
Page 8: Limited One Year Warranty
No other warranties, expressed or implied, including those of merchantability or fitness for particular purpose shall be applicable to Jackco except as specifically stated herein. In no event shall Jackco be liable to any party for any special, direct, indirect, consequential, punitive damage of any nature caused by the sale or use of the equipment or tool.
