- Page 1 MODEL 66500 5 TON HYDRAULIC FLOOR JACK USER'S MANUAL *This hydraulic jack conforms to all "ANSI / ASME" safety standards. Jackco Transnational Inc.© 2017 Azusa, CA 888-452-2526 To see more jackco products please visit our website at www.jackco.com...
-
Page 2: For Your Safety
FOR YOUR SAFETY • Read these safety instructions carefully and keep this manual in an easy to find place as you may need to use it again. • Non-compliance with these rules may result in injury or damage to the jack or the vehicle. •... -
Page 3: Specification
SPECIFICATION Capacity: 5 Ton Lift Range : 16.1 inch Max Height : 22 inch Gross Weight 222 lbs Min Height : Net Weight : 5.9 inch 191 lbs OPERATING INSTRUCTION Important: Sometimes during shipment and handling, air gets into the hydraulic system, causing poor lifting performance. -
Page 4: Maintenance
MAINTENANCE Important: Both the maintenance and repair of the jack may only be performed by qualified persons, who have sufficient knowledge of the hydraulic system used in these jacks Regularly lubricate the moving parts in the wheels, arms, handle and pump roller pin. •... -
Page 5: Troubleshooting
TROUBLESHOOTING Caution: To prevent personal injury, all inspection, maintenance, and repair procedures must be performed when the jack is free of load. Trouble Cause Solution 1) No hydraulic oil 1) Fill hydraulic oil 2) Release valve opened 2) Try again to rotate the handle to insure position Does not lift at all 3) mal-functioned delivery... -
Page 6: Parts List
PARTS LIST... - Page 7 Part No. Description Q’ty Part No. Description Q’ty Frame 2-14 Steel ball φ9 Front wheel 2-15 Spring Washer 2-16 Copper washer Snap ring 2-17 Bolt M12x20 Grease fitting 2-18 Steel ball Rod link 2-19 Valve seat Bolt 2-20 Spring Saddle 2-21 Screw Lock washer...
- Page 8 No other warranties, expressed or implied, including those of merchantability or fitness for particular purpose shall be applicable to Jackco except as specifically stated herein. In no event shall Jackco be liable to any party for any special, direct, indirect, consequential, punitive damage of any nature caused by the sale or use of the equipment or tool.
