ReelCraft 7000 Series Operating Instructions And Parts List

Hose Reel w/ Hose - 7850-OLP-SW57
IMPORTANT
READ THIS MANUAL CAREFULLY
BEFORE INSTALLING, OPERATING, OR
SERVICING THIS EQUIPMENT
DIMENSIONAL DATA
A
B
C
D
E
20 1/4"
19"
7 7/8"
3 7/8"
6 3/4"
Reelcraft Industries, Inc. • (800) 444-3134 / (260) 248-8188 • Fax: (260) 248-2605
E-mail: reelcraft@reelcraft.com • Internet: www.reelcraft.com
OPERATING INSTRUCTIONS
PERSONNEL SAFETY
Personal injury and/or equipment damage may result if
proper safety precautions are not observed.
• Ensure that reel is properly installed before connecting input and
output hoses.
• Bleed fluid/gas pressure from system before servicing reel.
• Before connecting reel to supply line, ensure that pressure does not
exceed maximum working pressure rating of reel.
• Remember, even low pressure is very dangerous and can cause
personal injury or death.
• Be aware of machinery and personnel in work area.
• If a leak occurs in the hose or reel, remove system pressure
immediately.
• A high tension spring assembly is contained within the reel.
Exercise extreme caution.
• Pull hose from reel by grasping the hose itself, not the control
valve.
• Ensure that reel, hose, and equipment being serviced are properly
grounded. Use an ohmmeter to check ground continuity.
• If reel ceases to unwind or rewind, remove system pressure
immediately. Do not pull or jerk on hose!
• Treat and respect the hose reel as any other piece of machinery,
observing all common safety practices.
AND PARTS LIST FOR
SERIES 7000
HOSE REELS
HJC - 275836
Form No: 571-491
Rev: 12/08/a
