AutomationDirect T1F-08DA-1 Installation Manual

1 - 8 0 0 - 6 3 3 - 0 4 0 5
Analog Current Output Module
T1F-08DA-1 $446.00
8-channel
analog current output module
The 8-channel current output module uses
a T1K-08B or T1K-08B-1 base, which is
purchased separately.
w w w . a u t o m a t i o n d i r e c t . c o m
T1F-08DA-1 Analog Output Specification
Channels Per Module
Output Ranges
Output Type
Resolution
Max. Loop Supply
Peak Output Voltage
Load Impedance
Max. Load (ohm) / Power Supply
Min. Load (ohm) / Power Supply
Linearity Error (end to end)
Conversion Settling Time
Full Scale Calibration Error
Offset Calibration Error
Accuracy vs. Temperature
Max. Full Scale Inaccuracy (% of full scale);
all errors included
Master Update Rate
Output Points Required
Base Power Required
External Module Power Required
Weight
NOTES:
1: Shields should be connected to the 0V terminal of the module or the 0V of the power supply.
2. Unused current outputs should remain open (no connections) for minimum power consumption.
