SYSTXBBECC01-C,
SYSTXBBWEC01-C
Evolution™ Connex™
System Control
US Patents: Carrier® U.S. Pat No. 7,243,004, Carrier® U.S. Pat No.
7,775,452, pointSET™ U.S. Pat No. 7,415,102
Owner's Manual
A240358
A240359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A240358 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bryant A240358

  • Page 1 SYSTXBBECC01-C, SYSTXBBWEC01-C Evolution™ Connex™ System Control Owner’s Manual A240358 A240359 US Patents: Carrier® U.S. Pat No. 7,243,004, Carrier® U.S. Pat No. 7,775,452, pointSET™ U.S. Pat No. 7,415,102...
  • Page 2: Table Of Contents

    Table of Contents 1. Introduction ........... . . 5 2.
  • Page 3 7. Vacation............32 8.
  • Page 4 16.Wireless ............55 17.Weather .
  • Page 5: Introduction

    (Wi-Fi® models only, when properly configured). Connectivity status to the home Wi-Fi network and the Bryant Server will also be displayed on the Home Screen. Note: You must have Wi-Fi enabled for the indicator...
  • Page 6: Wi-Fi® Connectivity Status

    Home Screen. Evolution Connex System Control is connected to the home Wi-Fi network and the Bryant Server, the signal strength bars will be displayed in white as depicted in the image below. Connection strength to the home Wi-Fi network will be indicated by the number of solid white bars displayed.
  • Page 7 “X” will appear over the strength bars. If the Evolution Connex System Control is connected to the home Wi-Fi network but loses connection to the Bryant Server, a triangle will appear over the strength bars as depicted in the image below. Connection strength to the home Wi-Fi network will continue to be displayed by the number of solid bars.
  • Page 8: Information Buttons

    A240303B_Rev. B 2.3. Information Buttons On the bottom of some screens will be an information icon. By pressing the information icon, a text box will display to show what interactions are available on that particular screen. To close the text box, touch the text box.
  • Page 9: Main Screen

    A14237B Revb 3. Main Screen The Main Screen is where most interactions will take place. Touch anywhere on the Home Screen to arrive at the Main Screen. The most convenient way to interact with your control is using the SmartHome mobile app.
  • Page 10: Set Day And Time

    • If AUTO is selected, the Evolution Connex System Control automatically switches between heating and cooling to maintain your comfort during transitional seasons. NOTE: AUTO mode is intended to switch between heating and cooling modes based on temperature demand. A gradual auto transition is the energy-conscious default that will satisfy the majority of customers.
  • Page 11: Adjust Temperature (Temporary Hold)

    • To set the HOUR, MINUTE, MONTH, DAY, or YEAR touch the feature you wish to change. • Use the Up (Y) and Down (B) buttons to make the appropriate changes. • When you have completed all of the settings, touch SAVE. •...
  • Page 12: Adjusting Heating

    3.5. Adjusting Heating NOTE: If OFF is selected, the Heat, Cool, Auto and Fan Only will not be available. When changing from the OFF mode to Heat, Cool, Auto, or Fan Only, it is normal for the system to run the blower for a minute or two.
  • Page 13: Adjust Temperature (Permanent Hold)

    • To return to the scheduled program, touch HOLD UNTIL, and then select PER SCHEDULE. 3.7. Adjust Temperature (Permanent Hold) The Evolution Connex System Control allows you to permanently override your programmed schedule by adjusting the indoor temperature at any time to meet your needs. 3.8.
  • Page 14: Adjusting Cooling

    3.10. Adjusting Cooling • To adjust the cooling temperature, enter the Main Screen by touching anywhere on the Control. • With the system in either AUTO or COOL mode, use the Up (Y) and Down (B) buttons to set the desired temperature. •...
  • Page 15 • Once you have selected the desired activity for ALL ZONES, you will have the option to either permanently (HOLD) or temporarily (HOLD UNTIL) override your programmed schedule. A14239 – Selecting the HOLD option will permanently override your programmed schedule until you CANCEL ALL ZONES. –...
  • Page 16: Features

    A240358 A240359 4. Features 4.1. Adjust Fan Speed The Features function of Evolution Connex System Control allows you to adjust the fan speed during continuous fan operation. • To adjust the fan speed, enter the Main Screen by touching anywhere on the Control.
  • Page 17: View Current Humidity Level

    4.2. View Current Humidity Level The Features function of Evolution Connex System Control allows you to view the current humidity level within the conditioned space. • Enter the Main Screen by touching anywhere on the Control. • Touch FEATURES on the top left of the screen. •...
  • Page 18 activity. In zoned systems, the activity settings will apply to the selected zone only. A14241 – For example to change your HOME comfort profile, touch the HOME icon. – Use the Up (Y) and Down (B) buttons to change the fan settings, heating and cooling temperatures.
  • Page 19: Home Comfort Profile Humidity Control

    which you choose to keep your home conditioned while you are away. The Advanced Smart Setback function will maintain your temperature within this range. • Set your desired humidity and fresh air (if applicable) using the HUMIDITY AND FRESH AIR PROFILES for each activity. A14242 5.2.
  • Page 20 A14243 • If you have a humidifier installed for your system, touch HEATING HUMIDITY to set the desired humidity level within the home. – You will have the option to turn ON or OFF your humidifier from this screen. A14244...
  • Page 21: Home Comfort Profile Fresh Air Control

    – Once your Humidifier is turned ON, use the Up (Y) and Down (B) buttons to set the desired humidity level between 5-45%. – Press SAVE when finished, or CANCEL to discard any changes. • Next, select your desired humidity level during cooling by touching COOLING HUMIDITY.
  • Page 22 A14246 • You will have the option of choosing among AUTO, MANUAL, or OFF. NOTE: This option may not be available with the ERVXXNVA ventilator due to its simplified Control design. – The AUTO setting will allow the user to choose the maximum fresh air that the ventilator will provide.
  • Page 23: Away Comfort Profile Humidity Control

    • If applicable, next select the amount of fresh air to circulate during cooling mode by touching COOLING FRESH AIR. Again, you will have the option of choosing among AUTO, MANUAL and OFF. – Use the Up (Y) and Down (B) buttons to set the desired ventilator speed level.
  • Page 24: Away Comfort Profile Fresh Air Control

    – Use the Up (Y) and Down (B) buttons to set the minimum humidity level between 5%-45%. – Press SAVE when finished, or CANCEL to discard any changes. • To set the desired humidity level during cooling, touch COOLING HUMIDITY. –...
  • Page 25: Vacation Comfort Profile Humidity Control

    several selections available: Off, Low 25%, Low 50%, Low 75%, Low 100%, Medium, and High. The percent values are percent of an hour. – Use the Up (Y) and Down (B) buttons to set the desired ventilation level. – Press SAVE when finished, or CANCEL to discard any changes. •...
  • Page 26 A14248 • If you have a humidifier installed for your system, touch HEATING HUMIDITY to set the desired humidity level when you are away from home. – Use the Up (Y) and Down (B) buttons to set the minimum humidity level between 5%-45%.
  • Page 27: Vacation Comfort Profile Fresh Air Control

    5.7. Vacation Comfort Profile Fresh Air Control • If a ventilator is installed in your home, select the amount of fresh air to circulate during heating mode by touching HEATING FRESH AIR. • You will have the option of choosing between AUTO, MANUAL, or OFF.
  • Page 28: View Or Edit Schedule

    A14249 6.1. View or Edit Schedule • To set a specific day use the Left (A) and Right (") buttons beside the day names. – If you wish to copy this schedule to other days, touch COPY above the day. –...
  • Page 29: Guided Scheduling

    6.2. Guided Scheduling The Guided Scheduling feature will prompt you with simple questions to help set a schedule that meets your desired comfort level and lifestyle. If you are satisfied with your comfort settings, proceed to the next screen. If you are not, go through the process outlined under Comfort Profiles (page 17).
  • Page 30 • Use the Up (Y) and Down (B) buttons to set the time you return home. • After you have selected the correct time, touch NEXT to continue. 5. If you select YES or have completed the previous steps, the next question will ask if you want different sleep settings.
  • Page 31: Upload My Schedule

    USB C device, and upload the schedules into the Evolution Connex System Control. NOTE: Use a 4GB to 32GB USB C device. • To download the my.bryant application for your computer, go to my.bryant.com. – Click on the Downloads tab.
  • Page 32: Vacation

    • On the Evolution Connex System Control, select Schedules from the Menu screen, then select the Upload Schedule option. • If the folder and file have been placed correctly on the USB C, you will be asked if you wish to upload the schedule. –...
  • Page 33: Reminders

    SAVE to complete your vacation schedule. A12110 8. Reminders NOTE: When you connect your system to the Internet and register on the my.bryant.com website, you can receive alerts and reminders via email. See the WIRELESS section for more information.
  • Page 34: Operating Status

    With the Evolution Connex System Control, there are accessory messages to remind you when it is time for maintenance. Select the REMINDERS icon from the menu screen. A12123 • You have the option of choosing a pop-up reminder for your air filter, humidifier, UV lights, or ventilator pre-filter.
  • Page 35: Equipment Operating Status

    9.1. Equipment Operating Status Within the operating status, you can view which function your system is performing, and at which stage the heating or cooling equipment is operating. A message stating, “System Check in Progress” means that the system is performing its normal 1 p.m. Filter check. This also happens any time the system mode is changed from Off to Auto, Heat, Cool, or Fan Only.
  • Page 36: Temperature Control Status

    A12108 9.3. Temperature Control Status The Temperature Control Status allows you to take a quick look at the actual temperatures, and temperature set points for each zone in your system. • When you are done looking at your zone status, press DONE. The system will indicate which mode is running by showing flashing arrows towards either the heating or cooling set point.
  • Page 37: Display

    A160187 10. Display The following display preferences can be adjusted for Evolution Connex System Control, Temperature Units (°F or °C), Backlight Levels, Sound Settings and Screen Saver Settings. A14256...
  • Page 38: Temperature Units

    10.1. Temperature Units Select the desired temperature units, either °F for Fahrenheit, or °C for Celsius and touch SAVE. Temperatures will be displayed with half-degree resolution for Celsius, or full degree resolution for Fahrenheit. A14257 10.2. Set Backlight Levels • Backlight levels are programmable for each Comfort Profile setting HOME, AWAY, WAKE, or SLEEP.
  • Page 39: Sound Settings

    A14258 10.3. Sound Settings The control can emit a ”click” sound in response to each screen touch. Select ENABLED to turn this sound on; or DISABLED to turn it off. A14259...
  • Page 40: Activate Screen Lock

    10.4. Activate Screen Lock • A message will pop up asking if you want to proceed with the screen lock. Selecting Yes will lock the screen and take you back to the home screen. A13247 • To unlock the screen, press and hold UNLOCK in the bottom left hand corner for 10 seconds.
  • Page 41: Energy Tracking

    A13248REVB • The screen will change and the Control will then be accessible. If the screen is to be locked again, return to the menu, select the screen lock and touch YES. 11. Energy Tracking The Evolution Connex System Control has the ability to monitor and estimate the energy consumption of certain models of your Evolution System.
  • Page 42: Time / Date

    energy consumption in units (kWh for electric and selected unit for gas heat), or in dollars. • If a gas furnace is installed, you can SELECT FUEL TYPE (natural gas or propane), and also SELECT FUEL DISPLAY UNITS. • Touch ENTER ENERGY PRICES to enter the current electric and gas utility rates.
  • Page 43: Set Time And Date

    A14250 12.1. Set Time and Date The time and date can either be set manually or can be synchronized with the web server (only for Wi-Fi connected units). From the Main Screen, touch MENU, on the bottom of the Control. The TIME/DATE icon will bring up the time and date menu.
  • Page 44: Setup Daylight Savings Time

    • Use the Up (Y) and Down (B) buttons to make the appropriate changes. • When you have completed all of the settings touch SAVE. 12.3. Setup Daylight Savings Time You can program your Evolution System Connex Control to automatically adjust for daylight saving time. From this screen, you can also choose to override the preprogrammed start and end dates for daylight saving.
  • Page 45: Enable Time Synchronization

    A14217 12.5. Enable Time Synchronization For systems with Wi-Fi® capability, after setting up the time zone, the time synchronization can then be done. Both must be done in order to enable time synchronization. A14253...
  • Page 46: Service

    13. Service Selecting the SERVICE icon from the menu screen will allow you to view service contact information, set-up or modify service reminders and update the software for your wall Control. A170237B Rev. B 13.1. Service Information Your dealer information is easily accessible and may already be pre-programmed in your Control by your dealer.
  • Page 47: Service Reminder Update

    A13250B 13.2. Service Reminder Update Setup option will allow you to setup routine service reminders. Once the reminder option is enabled, you can select the frequency of these reminders (3 to 18 months). A13251...
  • Page 48: Software Update

    NOTE: You will obtain best results using a USB C that is 4 GB to 32 GB in size. • From the downloads page on the my.bryant website, click on the link under the Download Latest Software • Read the End User License Agreement (EULA).
  • Page 49 • At the bottom of the EULA, choose “Yes” if you accept the agreement. NOTE: If you do not wish to accept the agreement, you will not be able to download the software update. • Use the Download link provided in the EULA document to download the software update package.
  • Page 50: Updating Software Using Wi-Fi

    A13254B • Press Yes to continue with the software upgrade. The upload and installation will take several minutes. • When the software upgrade is complete, a “successful” message will appear. Click DONE. • The Evolution Connex System Control will perform a restart after the DONE button is pressed.
  • Page 51 A250003 Touch anywhere inside the software update reminder message to install the latest software or customize your reminder messages for software updates. (Note: The version numbers shown below are examples. Actual version numbers will vary.) A150194...
  • Page 52: Model / Serial Numbers

    Selecting YES will initiate the software update process. Your Evolution Connex System Control will reboot in order to complete the software update process. All of your previously stored information and settings will be maintained. NOTE: Select DETAILS to view the release notes associated with the software to be downloaded.
  • Page 53: Heat Source (If Applicable)

    A14255 14. Heat Source (If Applicable) With the Evolution Connex System Control, you can select the desired heat source of your system, if your system is equipped as a HYBRID HEAT® System. Select the HEAT SOURCE icon from the menu screen.
  • Page 54: Zone Names (If Applicable)

    • The default is for the system to Control the heat source. • To have only the furnace Control, select FURNACE ONLY. • To have only the heat pump, select HEAT PUMP ONLY. • To have only electric select ELECTRIC ONLY. •...
  • Page 55: Wireless

    Connex System Control with the SmartHome mobile application is dependent on the compatibility of the user’s mobile device, the Evolution Connex System Control, and/or the Bryant web server with, and the availability of, the user’s Internet service provider or mobile device carrier service.
  • Page 56 will not be negatively affected by the network-related modifications, upgrades, or similar activity of the user’s Internet service provider or mobile device carrier service. To establish Wi-Fi connectivity to the Evolution Connex System Control using the in-home router or wireless access point the wireless access point SSID and password/passkey must be known for set-up.
  • Page 57 A13235 • On the next screen look for the SSID of the router/access point. After being selected, it will be outlined in faint blue and will be indicated by a checkmark. Then select NEXT. A150175 • The selected network will show. Choose an appropriate Wi-Fi security.
  • Page 58 security used. If the network has no security it will show as on the left, but a secured network will prompt for the Wi-Fi security key. A150191 • If a Wi-Fi security key is shown as on the right hand picture above then select the white bar and enter the security key, then select NEXT.
  • Page 59 A13238 • After the control has connected to the network, go to my.bryant.com, or use the SmartHome mobile app to register the unit. Registration requires the MAC address and serial number of the Evolution Connex System Control. On the wall control to find the serial number and MAC address of the Evolution Connex System Control, click on Menu, Down Arrow, Wireless and View my.bryant Registration Info.
  • Page 60: Weather

    A170285B_Rev. B • When the connection to the Bryant web server has been established, the status screen will show Connected for both Wi-Fi and the server. A13242B_Rev. B 17. Weather When the Evolution Connex System Control is connected to a Wi-Fi®...
  • Page 61 A170242B Rev. B • To enter your postal code, touch CHANGE CURRENT LOCATION. • Next, select your country (United States or Canada). • To enter your postal code, touch in the blank area; then enter your postal code using the on screen keyboard. Note that you may select a postal code other than where the system is located, if another postal code has a more relevant weather forecast for your area.
  • Page 62: Smartsave Program (Available In Select Regions)

    Regions) Your system control is pre-configured to support the SmartSave energy management program. SmartSave instructions vary based on your location and energy provider. Please refer to bryant.com for further information. 19. Statement Information This device complies with Part 15 of the FCC Rules. Operation is subject...
  • Page 63 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all...
  • Page 64 A180093...
  • Page 65 Evolution®, Touch ’N’ Go®, TrueSense™ and HYBRID HEAT® are trademarks or registered trademarks of Carrier Corporation in the United States and other countries. Other brands and product names are trademarks of their respective holders. Wi-Fi® is a registered trademark of Wi-Fi Alliance Corporation. Amazon Alexa is a trademark of Amazon, Inc.
  • Page 66 © 2025 Carrier. All rights reserved. A Proud Member of the Carrier Family Catalog No: OMSYSTXBBECC-VC-03 997-017070-31-R Edition Date: 02/25 Replaces: OM-SYSTXBBECC-VC-02 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
