TABLE OF CONTENTS

SAFETY CONSIDERATIONS...................................................1
INSTALLATION CONSIDERATIONS....................................1
INTRODUCTION.....................................................................1-2
INSTALLATION ......................................................................2-8
• Check Equipment And Job Site..................................................2
• Install Components...................................................................2-3
• Install Zone Dampers...............................................................3-4
• Install Barometric Bypass Damper .............................................5
• Final Wiring..................................................................5-7, 19-25
• Understanding Sequence Of Operation ...................................7-8
SYSTEM CONFIGURATION ..............................................8-11
• Equipment Controller Configuration ..........................................8
• User Interface Configuration .................................................8-11
SYSTEM STARTUP AND CHECKOUT..........................11-12
• Enable Installer Setup Mode ...............................................11-12
• Check Damper And Sensor Operation .....................................12
• Quick Check Of Equipment Operation ....................................12
• Longer Check Of Equipment Operation...................................12
FINAL INSTALLATION SETTINGS ...............................12-14
OPERATIONAL INFORMATION .........................................14
SMART SENSOR OPERATION.............................................15
QUICK START ..........................................................................16
COMFORT SCHEDULES ..................................................16-17
HOLD, OFF, OUT AND ALL ZONE.....................................17
TROUBLESHOOTING .......................................................17-18
NOTE: Read the entire instruction manual before starting the
installation.
This symbol → indicates a change since the last issue.

SAFETY CONSIDERATIONS

Improper installation, adjustment, alteration, service, maintenance,
or use can cause fire, electrical shock, or other conditions which
may cause personal injury or property damage. Consult a qualified
installer, service agency or your distributor or branch for informa-
tion or assistance. The qualified installer or agency must use
factory-authorized kits or accessories when modifying this prod-
uct. Refer to the individual instructions packaged with the kits or
accessories when installing.
Follow all safety codes and wear safety glasses. Have fire
extinguisher available. Read these instructions thoroughly and
follow all warnings or cautions attached to the unit. Consult local
and state building codes and Sheet Metal and Air Conditioning
National Association (SMACNA) for special installation require-
ments.
Recognize safety information. This is the safety-alert symbol
When you see this symbol on the unit or in instructions and
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and CAU-
TION. These words are used with the safety-alert symbol. DAN-
GER identifies the most serious hazards which will result in severe
installation instructions
ZONE PERFECT PLUS
Page
.
-1-
Cancels: II ZONEKIT-0-7
personal injury or death. WARNING signifies hazards which
could result in personal injury or death. CAUTION is used to
identify unsafe practices which would result in minor personal
injury or product and property damage.

INSTALLATION CONSIDERATIONS

Before the actual installation of a zoning system can begin,
decisions need to be made to determine the number and location of
zones and sensors. This affects duct and damper selections. For
assistance with these decisions, consult the Design Guide available
from your distributor or branch.
This instruction covers the physical installation and start up of the
Zone Perfect Plus system. Use this instruction to guide the actual
installation process after all the air side decisions have been made.
1. Install User Interface and Remote Sensors in non-
condensing areas with ambients between 32°F and 120°F.
Install Dampers and Equipment Controller in non-
condensing areas with ambients between 32°F and 158°F.
2. Dampers may need to be vibration isolated to reduce noise.
3. TXV is required in air conditioning and heat pump appli-
cations.
4. Use separate isolated transformer to supply power to Zone
Perfect Plus System (40 va minimum, class 2, field sup-
plied).
5. Proper equipment and duct sizing are important in a zoned
system. Be sure to refer to the Design Guide for assistance
in making these selections.
CAUTION: TXV on indoor coil is required on all
zoning installations.

INTRODUCTION

The Zone Perfect Plus System allows air conditioning and heating
equipment to control temperatures and humidity in up to 8 distinct
spaces or Zones within a building. Each zone has independent
temperature settings.
The comfort temperature settings can change automatically
through the use of schedules. This allows Zone Perfect Plus to
change temperature settings in zones to reflect occupancy or usage.
For example, you can condition the bedrooms in a home from 5:00
PM through 7:00 AM or the kitchen from 3:00 PM through 6:00
PM. The Zone Perfect Plus System uses motorized air volume
control dampers (also called zone dampers) to regulate flow of
conditioned air into zones. In this manner Zone Perfect Plus can
selectively heat or cool certain portions of a building depending
upon space temperature requirements.
Each zone requires a motorized zone damper to control the air
supplied to it and a zone sensor to sense zone temperature. There
are 3 types of zone sensors available and they may be used in
combination:
• User Interface - Each installation has only 1 User Interface.
This is the command center for the entire system, and it will
typically be located in Zone 1 to sense and control the
ZONEBB2KIT
ZONEBB4KIT
ZONEBB8KIT
II ZONEKIT-0-9
3-98
