ITS Telecom EK CM 8SH TC/IP User Manual

Dvb s/s2 transmodulator to tc/ip multicast

Advertisement

Quick Links

USER MANUAL
CM 8SH TC/IP
082257
DVB S/S2 TRANSMODULATOR
TO TC/IP MULTICAST
V01
ITS Partner O.B.S S.L. Av. Cerdanyola 79-81 Local C
08172 Sant Cugat del Vallés Barcelona (Spain)
Phone: +34935839543 info@ek.plus www.ek.plus

Advertisement

loading
Need help?

Need help?

Do you have a question about the EK CM 8SH TC/IP and is the answer not in the manual?

Questions and answers

Summary of Contents for ITS Telecom EK CM 8SH TC/IP

  • Page 1 USER MANUAL CM 8SH TC/IP 082257 DVB S/S2 TRANSMODULATOR TO TC/IP MULTICAST ITS Partner O.B.S S.L. Av. Cerdanyola 79-81 Local C 08172 Sant Cugat del Vallés Barcelona (Spain) Phone: +34935839543 info@ek.plus www.ek.plus...
  • Page 2 CM 8SH TC/IP USER MANUAL INDEX INTRODUCTION: ........................................... 3 Description: ............................................3 Key features:............................................3 Packaging Contents: ........................................3 CONNECTIONS AND INTERFACES: .................................. 4 INSTALLATION AND CONNECTION: ................................5 General installation and connection:................................ 5 Installing a multi-module headend: ................................6 PROGRAMMING SOFTWARE "CM Management": ..........................
  • Page 3 CM 8SH TC/IP USER MANUAL INTRODUCTION: Description: Transmodulator 4 inputs - 8 DVB S/S2 tuners. 13/18V, 22KHz, DiSEqC. USB file player and HDMI IN. IP output + 4 channels flexible programmable COFDM/QAM output. Output level 95 dBuV. MER >35dB. Intelligent service remultiplexing. Up to 64 SPTS/MPTS IP STREAMS output. Programming from PC connected to the power supply.
  • Page 4 CM 8SH TC/IP USER MANUAL CONNECTIONS AND INTERFACES: USB input IP Output HDMI input Status LED. Input tuner status information. Input connectors to each tuner. Status LED. Reports the status of the modulated output in COFDM/QAM. The output will be working properly when the LED flashes green RF mix input.
  • Page 5 CM 8SH TC/IP USER MANUAL INSTALLATION AND CONNECTION: General installation and connection: 1.- For installations of several modules (headend) or a single module, attach the transmodulator module to a wall chassis (CHM TR) or a rack chassis (CHR TR). To do this, assemble the supplied metal piece (Code: 251008) on the upper rear of the module as indicated in the image.
  • Page 6 CM 8SH TC/IP USER MANUAL 5c.- Programming by PC - CM PR via USB. Connect the module to the device using the power and data cable. Connect the PC to the CM PR using the USB cable. 6.- Execute the PC programming SW. Important note: Connect the FA 524 power supply or the CM PR...
  • Page 7 CM 8SH TC/IP USER MANUAL In the case of LAN, we will select the equipment and connect by pressing: • ID: We will enter the MAC of the corresponding power supply. • KEY: we will enter the CM Key, if there is one. If not "0". •...
  • Page 8 CM 8SH TC/IP USER MANUAL The main screen of the "CM Management" allows you to easily identify the different modules connected to the power supply, as can be seen in the following screen: Power supply and header manager (red). Identification of a module with an input card (green) and an output card (blue).
  • Page 9 CM 8SH TC/IP USER MANUAL 6. IP exit card. Selected Program Pool configured entries. Input Card: This part of the menu will set up the input card. By selecting A, B, C, D, E, F, G or H we will select the demodulator we want to configure: On: Click on the "Check"...
  • Page 10 CM 8SH TC/IP USER MANUAL The four inputs are then configured. For each of them: Mode: the LNB type will be chosen between Legacy, SatCR, dCSS. User Band: Choose if you are configuring a Unicable LNB. LNB Frq.: configure 22KHz ON/OFF, Polarity VERT/HOR and DiSEqC A/B/C/D Switch. At last: Flow: maximum throughput in Mbps that will enter the modulator board.
  • Page 11 CM 8SH TC/IP USER MANUAL Depending on which column you select the service in, it will appear in one or the other output MUX. RF Output Card: Once the services in the pool have been selected and assigned to an output MUX, we will be able to configure: 1.- We will configure, if necessary, the different parameters of the NIT (Network Information Table).
  • Page 12 CM 8SH TC/IP USER MANUAL MAC Address: MAC address of the module. IP Address, mask and gateway: IP address, subnet mask, and gateway that can be set for the module. DHCP: In case the protocol for automatic obtaining of network parameters is activated, the rest of the IP values will be disabled.
  • Page 13 CM 8SH TC/IP USER MANUAL It is recommended that the IPs be different for each stream, and the port above 50000, but they can be the same. B.W.: The image shows the total output bit rate of all the services added. Remote management of the headend: The CM header can be managed remotely.
