Quick Installation Guide
• GW0048S-21 - 48 FXS HD Gateway, RJ21, 50 PIN
• GW0072S-21 - 72 FXS HD Gateway, RJ21, 50 PIN
• GW0096S-21 - 96 FXS HD Gateway, RJ21, 50 PIN
• GW0048S-45 - 48 FXS HD Gateway, RJ45
• GW0072S-45 - 72 FXS HD Gateway, RJ45
• GW0096S-45 - 96 FXS HD Gateway, RJ45
1
Product Model & Number of Ports
Model
GW0048S-21
GW0072S-21
GW0096S-21
GW0048S-45
GW0072S-45
GW0096S-45
PM1007 - HD FXS VoIP Gateways Getting Started Rev.01
Networks Ports
3
3
3
3
3
3
RJ21
2
3
4
-
-
-
RJ45
-
-
-
12
18
24
Advertisement
Table of Contents
Related Manuals for Xorcom GW0048S-21
Summary of Contents for Xorcom GW0048S-21
- Page 1 Quick Installation Guide • GW0048S-21 - 48 FXS HD Gateway, RJ21, 50 PIN • GW0072S-21 - 72 FXS HD Gateway, RJ21, 50 PIN • GW0096S-21 - 96 FXS HD Gateway, RJ21, 50 PIN • GW0048S-45 - 48 FXS HD Gateway, RJ45 •...
-
Page 2: Description Of Indicators
Description of Indicators Indicator Definition Status Description The gateway is powered on Power Indicator The gateway is powered off or there is no power supply Slow The gateway is running properly Flashing Running Fast Flashing SIP account is registered successfully Indicator The gateway is running improperly FXS port is currently occupied by a call... -
Page 3: Indicators & Interfaces
Indicators & Interfaces Note: Xorcom HD VoIP Gateways have a similar physical appearance except for the different number of ports. The AUX port on the front panel is a reserved interface. PM1007 - HD FXS VoIP Gateways Getting Started Rev.01... -
Page 4: Installation Notes
• Power supply: the power adapter of the gateway accepts 100-240V AC power supply. Please ensure safe and stable power supply (Xorcom HD VoIP Gateway supports a dual 220v power supply or dual 48v power supply). •... - Page 5 RJ45 & RJ21 Wire Sequence • RJ45 Wire Sequence Xorcom HD VoIP Gateways support RJ45 Interfaces for FXS connections. One RJ45 cable can be split into four pairs of RJ11 interfaces. The outlook wire sequence of RJ45 cable is shown as follows: Orange &...
- Page 6 Call No. Colour White Blue White Orange White Green White Brown White Slate PIN No. Call No. Colour Blue Orange Green Brown Slate PIN No. Call No. Colour Black Blue Black Orange Black Green Black Brown Black Slate PIN No. Call No.
- Page 7 Double-click ‘Internet Protocol Version 4 (TCP/IPv4)’. Select ‘Use the following IP address’, and then enter an available IP address ‘192.168.11.XXX’ which is at the same network segment with ‘192.168.11.1’. Log in Web Management System Enter the gateway's IP address in the browser (The default IP is 192.168.11.1). Enter the administrator’s username and password to access the Web GUI.
- Page 8 Configure Gateway 1. Configure SIP Server Log in the Web Management System of the gateway, and then click SIP Server in the navigation tree and then enter the address of the SIP server which is to be registered. Click Save in the last. 2.
- Page 9 More Details This document only provides instructions for quick installation and basic configuration, for detailed configuration and parameter explanation, please refer to user manual or ask for online technical support at https://www.xorcom.com PM1007 - HD FXS VoIP Gateways Getting Started Rev.01...
